3. Orient the Right Upright (36) as shown, and at-
tach it to the Base (48) with two Upright Bolts
(27) and two Upright Star Washers (39); do not
tighten the Upright Bolts yet.
4. Set the Base (48) near the front of the treadmill,
with the Power Cord (13) on the Hood (1) as
shown.
Cut the small tie (not shown) holding the Upright
Wire (28) in a bundle.
See the inset drawing. Wrap the strap around
the Upright Wire (28) and secure the strap using
the included plastic tie. Then, pull the opposite
end of the strap until the end of the Upright Wire
is pulled through the Right Upright (36).
3
Bend
36
4
1
13
48
8
48
39
39
36
36
28
Tie
27
Strap
28
