- Page 1 MODEL GWX-200 PARTS MANUAL Rev. 1.00A C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T A V E N U E GARDEN GROVE, CALIFORNIA 92841...
-
Page 2: Table Of Contents
ABLE OF ONTENTS GWX-200 ODEL 1. PARTS MANUAL ..................3 1.1. (P/N 4001.00) ....................3 NITIAL ARTS 1.2........................4 PTIONAL LARM 1.3......................5 XPLODED RAWINGS 1.3.1. Cabinet Assembly ........................5 1.3.2. GLX Door Assembly ....................... 6 1.3.3. Spray System Assembly ......................7 1.3.4. -
Page 3: Parts Manual
NOTE: CMA recommends that the initial parts kit be kept on hand as a back up supply of critical parts in the event your machine should require emergency service. All the parts included in this kit are unique to the GL-X glasswasher. MODEL GWX-200 PARTS MANUAL Rev. 1.00A Page... -
Page 4: Optional Sani Alarm
00435.00 Squeeze Tube, 8” 40126.10 #10 x 3/4" Sheet metal Screw 00521.00 Wire, 18 Gauge, Orange, 6 ft. 40127.00 Wall Anchors 00531.00 Wire, 18 Gauge, White, 6 ft. 00426.00 Y Hose Connector, 3/16” MODEL GWX-200 PARTS MANUAL Rev. 1.00A Page... -
Page 5: Exploded View Drawings
Liquid Level Switch 01572.64 GL-X Leg 03816.00 Nylon Retaining Washer 00941.00 10-32 X 5/8” Panhead Screw 03415.60 Chem. Tube Bulkhead 14506.50 Door Gasket 00912.00 ¼” SS Nut 14506.45 Gasket Bracket 00922.00 ¼” Lock Star Washer MODEL GWX-200 PARTS MANUAL Rev. 1.00A Page... -
Page 6: Glx Door Assembly
1/4"-20 x 5/8” Hex Head Bolt 04919.64 Door Support Rod 14518.00 Splash Guard 00557.80 Door Magnet 00924.00 1/4" SS Washer 00970.60 6 32 x 1/2" Flathead Screw 00605.00 Door Handle Button 14558.61 Door Magnet Holder MODEL GWX-200 PARTS MANUAL Rev. 1.00A Page... -
Page 7: Spray System Assembly
00929.00 1/4"-20 x 3/4" Truss Head Bolt 04306.00 Square Manifold Gasket 04305.10 Red Silicon Gasket 04303.00 Spray Arm Bearing 00304.03 Spray Arm “B” Series 00308.50 Spray Arm End Plug 04304.64 GWX-200 Spray Manifold MODEL GWX-200 PARTS MANUAL Rev. 1.00A Page... -
Page 8: S/S Pump Assembly
00914.70 Socket Head Screw 10 mm 50302.10 1" MPT x 1" Barb Brass 00208.21 Slip Joint Nut Friction Ring 04206.75 SS Pump Cover Item not shown are the same as #20 in old assembly MODEL GWX-200 PARTS MANUAL Rev.1.00A Page... -
Page 9: Plumbing System Assembly (Effective August 2012)
03603.10 JE ½” Solenoid Valve 50302.20 3/4" F X 1" Barb Plastic Fitting 00738.10 JE Solenoid Coil 05007.42 GWX-200 Motor’s Water Breathing Line 03603.20 1/2” Water Solenoid Bonnet 05007.40 GWX-200 Vaccum Breaker Water Line 13629.00 Nipple SS 1/2 x Close 03624.00... -
Page 10: Plumbing System Assembly
Transfer Hose 1" Reinforced 2 ft 00743.11 ^1/2 Tee F x F x F SS 03101.00 Hose Clamp # 16 1" 15925.00 GWX-200 Inlet Baffle 00798.00 SS Braded Hose 20 " 00721.00 1/2" Jamb Nut MODEL GWX-200 PARTS MANUAL Rev. 1.00A Page... -
Page 11: Drain System Assembly
Pump Hose 6.5” 03101.00 1” Hose Clamp #16 04113.00 Drain Valve 03108.51 1” Goose Neck Drain Hose 04110.00 Drain Sump Screen 50302.06 1” MIP X 1” Barb PVC 03109.00 Drain Hose 90 deg. 1” I.D. MODEL GWX-200 PARTS MANUAL Rev. 1.00A Page... -
Page 12: Control Box
Start/Fill Rocker Switch 00965.00 6-32 Nylon Lock Nut 15524.00 Power Rocker Switch 00470.10 Toggle Switch Rubber Boot 03202.66 Thermister 03485.00 Switch Guard (Undercounter Units) 00438.00 Snap bushing, Universal 06231.58 WD-200 Drawer Label (Front) MODEL GWX-200 PARTS MANUAL Rev. 1.00A Page... -
Page 13: Control Panel
Parts Manual 1.3.9. Control Panel ITEM DESCRIPTION REQ’D 06231.57 GWD-200 Drawer Label (back) 00556.10 Reed Switch 00421.40 Start/Fill Rocker Switch 03705.82 Sponge Strip 03485.10 Switch Guard 15904.62 Control Drawer MODEL GWX-200 PARTS MANUAL Rev.1.00A Page... -
Page 14: Power Box
10-32 Nylon Lock Nut 13525.00 8-32 x 1” Pan Head Screw 15914.82 GL-X Peri-Pump Mount 00927.00 8-32 Nylon Lock Nut 03475.00 Primer Switches* 00941.00 10-32 Pan Head Screw 03476.00 Rubber Boots 03801.00 10-32 Nylon Lock Nut MODEL GWX-200 PARTS MANUAL Rev.1.00A Page... -
Page 15: Peristaltic Pump Assembly
00415.00 Complete Peristaltic Pump 00458.00 Squeeze Tube – Black Detergent 03415.60 Bulk Head For Sanitizer 02257.00 Squeeze Tube 8" Norprene 02257.30 24” Squeeze Tube 00419.00 Peristaltic Rotor Assembly *Item 16 includes items 1-4, 6-10. MODEL GWX-200 PARTS MANUAL Rev.1.00A Page... -
Page 16: Drain Valve
Drain Seal Bearing (White Washer) 04103.13 Drain Valve Housing Cover 04113.18 Valve Cover Screw 04103.16 Drain Valve Hinge/Seal 04103.15 Drain Valve Housing Gasket 04113.12 Drain Valve Housing 04103.18 #8 X 5/8 Self Threading Screw MODEL GWX-200 PARTS MANUAL Rev.1.00A Page... -
Page 17: Heater Assembly
Parts Manual 1.3.13. Heater Assembly ITEM DESCRIPTION REQ’D 15920.64 GL-X Heater Box 15417.30 1250 Watt Heater 04109.11 Sump Heater 13417.92 Thermostat MODEL GWX-200 PARTS MANUAL Rev. 1.00A Page...
