G919730P_01-07.qxd
1/12/07
3:38 PM
Page 1
MkII
Concept 650
O O w w n n e e r r ' ' s s G G u u i i d d e e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Concept 650MkII and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Clifford Concept 650MkII

Summary of Contents for Clifford Concept 650MkII

  • Page 1 G919730P_01-07.qxd 1/12/07 3:38 PM Page 1 MkII Concept 650 O O w w n n e e r r ’ ’ s s G G u u i i d d e e...

  • Page 2: Limited Lifetime Consumer Warranty

    G919730P_01-07.qxd 1/12/07 3:38 PM Page i limited lifetime consumer warranty Directed Electronics ("Directed") promises to the original purchaser to repair or replace with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the lifetime of the vehicle provided the following conditions are met: the unit was professionally installed and serviced by an authorised Directed dealer;...
  • Page 3 Type of alarm installed Year, make, model and colour of the vehicle Vehicle registration number Vehicle identification number All security options installed on the vehicle trademarks and copyrights Bitwriter ® , Clifford ® , Code-Hopping ™ , Directed ® , Doubleguard ®...

  • Page 4: Table Of Contents

    G919730P_01-07.qxd 1/12/07 3:38 PM Page 1 contents limited lifetime warranty ..i high frequency ....18 what is included ... . .3 smart power up II .
  • Page 5 G919730P_01-07.qxd 1/12/07 3:38 PM Page 2 security & convenience ..37 health check ....39...

  • Page 6: What Is Included

    : : Your system MUST be installed by an Authorised dealer in accor- dance with the instructions we supply them. The Clifford Concept 650 MkII system is designed to be installed in any petrol or common rail diesel vehicle with a 12-volt battery.

  • Page 7: System Maintenance

    G919730P_01-07.qxd 1/12/07 3:38 PM Page 4 n n o o t t e e : : The Installation Certificate must be completed by your installer at the authorised dealer. Other than the remote controls, this system has no user-serviceable parts. Your authorised dealer can correct any system wiring problems and, if needed, can return any malfunctioning compo- nent to Directed Electronics for repair/replacement under the terms of the Limited Lifetime Warranty printed at the beginning of this guide.

  • Page 8: Transmitter Configurations

    : : This manual describes the features and accessories that are included with your system along with information about compatible Clifford accessories that are not included. For a list of included acces- sories, please refer to the What Is Included section of this manual.

  • Page 9: Transmitter Functions

    G919730P_01-07.qxd 1/12/07 3:38 PM Page 6 transmitter functions This system uses computer-based code learning to learn the transmitter buttons. This makes it possible to assign any transmitter button to any system function. The transmitter initially comes programmed with stan- dard configuration, but may also be customised using the CliffNet Wizard PC program.
  • Page 10 G919730P_01-07.qxd 1/12/07 3:38 PM Page 7 Button, then Button Accessory C output is controlled by these buttons. Button twice, then Button These buttons activate/deactivate remote valet. Button twice, then Button These buttons disable the sensors. Button twice, then Button These buttons enter safe start mode for manual transmission vehicles and activate Autostart mode.

  • Page 11: Using Your System

    G919730P_01-07.qxd 1/12/07 3:38 PM Page 8 using your system The buttons used in the instructions in this manual correspond to the standard transmitter configuration. If your transmitter has been custom configured, the icons on your transmitter buttons may not correspond to the indicated functions.

  • Page 12: Disarming

    G919730P_01-07.qxd 1/12/07 3:38 PM Page 9 not chirp. The early chirps provide you with a 25-second warning prior to arming. n n o o t t e e : : If any protected entry point (a door or a switch-protected boot or bonnet) is open, the system will not passively arm.

  • Page 13: Disarming Without A Transmitter

    G919730P_01-07.qxd 1/12/07 3:38 PM Page 10 disarming without a transmitter This feature allows you to disarm the system without the transmitter should it be lost, damaged, or disabled. In order to disarm without a transmitter, you must have the vehicle’s ignition key, know where the PlainView 2 Valet switch is located, and have the PIN code.

  • Page 14: Transmitter Sensor Disable

    G919730P_01-07.qxd 1/12/07 3:38 PM Page 11 transmitter sensor disable To temporarily disable a sensor input, arm the system, press twice and then . The lights will flash four times and all warn away trig- ger zones one, two, three, and eight are bypassed. Press the buttons again;...

  • Page 15: Auxiliary Channel Bypass

    G919730P_01-07.qxd 1/12/07 3:38 PM Page 12 auxiliary channel bypass Alarm sensor input zones one, two, three, and eight will be bypassed while a pulsed or timed auxiliary Output is active. disarm/valet mode Entering your pin code using the PlainView 2 Valet switch allows you to disarm the system or enter valet mode without using the transmit- ter.

  • Page 16: Transmitter Valet Mode

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 13 3. After the last digit of the pin code is entered: a. To disarm the system: press and release b. To enter valet mode: Press and hold three seconds. The LED status indicator will illuminate continuously if you are entering Valet Mode and will turn off if you are exiting Valet Mode.

  • Page 17: One-Time Auto-Arming Bypass

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 14 one-time auto-arming bypass This will bypass the auto arm feature once only. With the key, turn the ignition on, then off within two seconds. The siren will chirp once to confirm auto arming bypass. The system will not auto arm.

  • Page 18: Multiple Event Total Recall

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 15 multiple event total recall This will report the last eight system triggers. Press and hold of the PlainView 2 Valet switch. While still holding , arm and disarm the system, then release the button. The LED will start to blink to indicate the most recent trigger and proceed down to the eighth trigger.

  • Page 19: Disarming Diagnostics

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 16 The security system will ignore the input that was active when the sys- tem was armed, until the input goes away. Three seconds later the sys- tem will monitor that input normally. For example, if your vehicle has the boot open, and you arm the system, you will hear Bypass Notification chirps.

  • Page 20: Table Of Zones

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 17 table of zones The zone number is the number of LED flashes used by the system to identify a specific input. The standard input assignments are listed below, along with spaces to write in any optional sensors or switches you have had installed.

  • Page 21: High Frequency

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 18 high frequency Your system transmits and receives at 433 MHz. This provides a cleaner spectrum with less interference and a more stable signal. smart power up II This security system will store its current state to non-volatile memory. If power is lost and then reconnected the system will recall the stored state from memory.

  • Page 22: Programming Options

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 19 Power Saver in Valet Mode: When the system enters Valet Mode the LED illuminates steadily. If the vehicle is not used (ignition is not turned on) for a period of one hour while the system is in Valet Mode, the LED will shut off.

  • Page 23: Cliffnet Wizard Installation Software Programming

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 20 feature only works if passive arming has been programmed. Reset the system to all factory defaults Entry delay feature off or on Add or remove remote controls. BlackJax* feature off or on. Change PIN code. Custom configure the remote control.

  • Page 24: Manual Programming Instructions

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 21 manual programming instructions It is a good idea to document changes by taking note of all feature changes made in programming mode. To enter the User Selectable Features programming: Ignition on - Turn the ignition to the run position or start the engine.

  • Page 25: User Selectable Features

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 22 gramming mode has been exited. user selectable features Off / On Off/On/Quiet Off/Ignition/RPM Off/On Off/On Off/Ignition Off/On Off/On Off/On This feature is only available with optional IntelliStart connected. This feature is only available with optional SmartWindows connected. 5-button remote only.
  • Page 26 G919730P_01-07.qxd 1/12/07 3:39 PM Page 23 Auto-learn new five-button remote controls to the system in the stan- dard button configuration. Once you have entered the feature, press on the transmitter until you hear a confirmation chirp. Press again until you hear two chirps indicating the new remote is learned. auto (passive) arm - on/off Off: The transmitter must be used to arm the system.

  • Page 27: User Selectable Features Descriptions - Column Two

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 24 auto unlock - ignition/off Off: The doors will not automatically unlock when the igni- tion is turned off Ignition: The doors will automatically unlock as soon as the ignition is turned off. auto (passive) arm and lock - on/off Off: The doors will not lock when the system passively arms.
  • Page 28 G919730P_01-07.qxd 1/12/07 3:39 PM Page 25 entry delay on/off On: If the system has passively armed, it will not trigger for 15 seconds after a door is opened allowing the user to enter the vehicle and disarm the system via the PlainView 2 Valet switch.

  • Page 29: User Selectable Features Descriptions - Column Three

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 26 blackjax* on/off On: The system will enter BlackJax mode when triggered. Off: The system cannot enter BlackJax mode. user selectable features descriptions - column three The features in this column pertain to programming individual trans- mitter channels in custom configurations.
  • Page 30 G919730P_01-07.qxd 1/12/07 3:39 PM Page 27 accessory b output The transmitter channel programmed into this feature will activate the accessory output. silent mode The transmitter channel programmed into this feature will arm/disarm the system, but the siren will not chirp. remote valet The transmitter channel programmed into this feature will make the system enter/exit valet mode.

  • Page 31: Pin Programming

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 28 ters that have been lost, stolen, or incorrectly programmed into the system. After entering this feature press any button on the transmit- ter; the siren will chirp to indicate that all transmitters have been erased from memory. pin programming A PIN code can have one to four digits;...

  • Page 32: Ultrasecure Auto-Immobiliser

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 29 Press and release two times, and then press once. You will hear two chirps. Wait for two siren chirps after a five second pause or five seconds after the last digit has been entered if using less than four digit code number.

  • Page 33: Auto-Immobilisation Sequence

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 30 auto-immobilisation sequence Turn ignition off or disarm alarm After 30 seconds the systems Immobilisation circuits activate and engage the starter and ignition interrupt LED flashes at ½ normal speed Disarming auto-immobilisation To disarm auto-immobilisation when active, follow any of the sequences listed below.

  • Page 34: Blackjax* Feature

    3:39 PM Page 31 blackjax* feature Clifford's exclusive BlackJax feature provides a safe and effective means of recovering your vehicle after a carjacking by monitoring the door input, brakes, and engine speed. Simply get out of the vehicle and let the thief drive away.
  • Page 35 G919730P_01-07.qxd 1/12/07 3:39 PM Page 32 Press and release brake pedal. System sees the brake pedal pressed. System then begins monitoring the engine speed. System sees the engine speed at two times idle. BlackJax* begins 20 second countdown. After a 20 second countdown: 5 siren chirps as reminder to enter PIN code.

  • Page 36: Blackjax* Deactivation Sequence

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 33 blackjax* deactivation sequence To deactivate BlackJax turn the key on and then enter the PIN code at any time. bypass blackjax temporarily This feature allows you to easily bypass BlackJax activation when anoth- er person drives your vehicle that should not know your PIN code. (IE: valet parking, mechanic) Bypass BlackJax temporarily Turn ignition on.

  • Page 37: Blackjax* Off Warning Indicator

    G919730P_01-07.qxd 1/12/07 3:39 PM Page 34 Turn ignition off, siren chirps 3 times as confirmation of exit- ing programming. n n o o t t e e : : If ignition remains on after entering PIN code and no action for 10 seconds, unit will automatically exit programming mode without chirps.

  • Page 38: Glossary Of Terms

    For sensitivity adjustments for all sensors, please return to your installing Clifford dealer. glossary of terms Control Unit: The "brain" of your system. Usually hidden underneath the dash area of the vehicle.
  • Page 39 G919730P_01-07.qxd 1/12/07 3:39 PM Page 36 PlainView 2 Valet Switch : A small two-button switch mounted some- where inside the vehicle. It is used to override the alarm when a trans- mitter is lost or damaged, or to enter or exit Valet mode. Smart Self-Powered Siren : Noise generating device usually installed in the engine compartment of the vehicle.
  • Page 40 G919730P_01-07.qxd 1/12/07 3:39 PM Page 37 security & convenience expansions Here we have listed only some of the many expansion options avail- able. Please contact your dealer for a complete list of all the options available to you. Remote Boot Release : The button can operate a factory electric release for the vehicle’s boot or hatch.
  • Page 41 G919730P_01-07.qxd 1/12/07 3:39 PM Page 38...
  • Page 42 3:39 PM Page 39 health check Directed Electronics recommends you return to your installing Clifford dealer to have your system checked for correct operation. The first check is due one year after the installation date and at yearly intervals thereafter.
  • Page 43 G919730P_01-07.qxd 1/12/07 3:39 PM Page 40 Your factory set 4-digit PIN code is noted below. See Pin Programming Section of Guide for information on using your PIN code. place sticker here The company behind this system is Directed Electronics E&OE, specification is subject to change without notice. Some vehicles require optional parts/wiring and a few are incompatible with some features.
