Now Start...
With dryer in laundry area.
Excessive Weight Hazard
Use two or more people to move end
install dryer.
Failureto do se can result in beck or
other injury.
3-prong,
ground-type
gas supply line
gas shutoff valve
l
a Take tape off front corners of
dryer. Open dryer and remove the
literature and parts packages. Wipe
the interior of the drum thoroughly
with a damp cloth.
mTake two of the cardboard
corners from the carton and place
them on the floor in back of the dryer.
Firmly grasp the body of the dryer
and genfiy lay it on its back on the
cardboard
corners.
wWith one of the legs in hand,
check the ridges for a diamond
marking. That's how far the leg is
supposed to go into the hole.
i Start to screw the leveling legs
into the holes by hand. (Use a small
amount of liquid detergent to
lubricate the screw threads so it is
easier to turn the legs.) Use a 1-inch
wrench or socket wrench to finish
turning the legs until you reach the
diamond mark.
Now stand the dryer up,
Slide dryer onto cardboard or
hardboard before moving across floor
to avoid damaging floor covering,
m Remove
the service door of the
meter
case, Lift
the service door
up at the back
and remove,
install money-
accepting
device,
(Refer to
manufaturer's
instructions
for proper
installation.)
For dryers using coin slides, use
adapter
kit supplied
with dryer.
Replace
the meter
case service door.
Put the coin vault with lock and key
the meter case opening,
• Move
dryer close to final
position.
Remove
cardboard
or
hardboard
from under dryer.
• Remove red cap from gas pipe.
Carefully
move dryer into final
position.
Place level on top of the
dryer, first side to side; then front to
back,
If the dryer is not level, adjust
the legs of the dryer up or down
until
the dryer is level.
• Connect
gas supply to dryer.
Use pipe-joint
compound
resistant to
the action
of L.P, gas for gas
connections,
if flexible metal
tubing
is
used, be certain
there are no kinks,
If necessary
for service,
open the toe
panel,
use a putty knife to press on
the toe panel
lock located
at the
center
top of the toe panel
Pull
downward
on the toe panel
to open.
Toe panel
Is hinged
at the bottom.
9m
Open
the shutoff valve in the
gas supply line.
lOre
Use a non-corrosive leak
detection
fluid to check
for leaks.
Bubbles around
connections
will
indicate
a leak, NEVER lEST FOR GAS
LEAKS WITH A FLAME. If a leak
appears,
shut off gas valve controls
and adjust connections.
Then check
connections
again.
Close toe panel
All connections
must be wrench-
tightened.
1.
TO exhaust dryer, see Exhaust
requirements,
Pages 3-4. Connect
exhaust
vent system to dryer exhaust
outlet
and exhaust
hood using 4"
(10.2 cm) clamps,
Use caulking
to
seal exterior wall opening
around
exhaust
hood.
2.
Carefully
move
dryer into
final position.
Place level on top of
the dryer, first side to side; then front
to back.
If the dryer is not level, adjust
the legs of the dryer up or down until
the dryer is level.
3
• Plug power
supply cord
Into
grounded
outlet.
4
• Check dryer operation
(some
accumulated
time may be on the
timer due to factory
testing).
Insert coins in slide and press slide in
slowly. (Operating
time win
accumulate
per number
of coins and
1ype of timing cam used.) Push
START/RESTARTbutton.
Using a full
heat cycle
(not the air cycle),
let the
dryer run for at least five minutes.
Dryer will stop when time is used up.
Note: Dryer door must be closed for
dryer to operate.
When door is open,
dryer stops, but fimer continues
to run.
To restart dryer, close door and bush
START/RESTARTbutton.
5
• ff fhe burner does not ignite
and you can feel no heat inside 1he
dryer, shut off dryer for five minutes.
Check
that all supply valve controls
are in "ON" position
and that the
elecfrical
cord is plugged
in. Repeat
five-minute
test,
6•
If drying time is too long,
make sure lint screen is clean.
