- Page 2 Automatically or manually adjustable memory depth C omponent tester for capacitors, inductors and semiconductors Elektronik Product of the Year The HMO3000 series is future-proof 2012 300 MHz | 400 MHz >>> 500 MHz due to bandwidth upgrade option HMO1024 No. 1 in Category...
-
Page 3: Serial Bus Analysis
HOO10 | HOO11 | HOO12 Serial Bus Analysis for all HMO Series Oscilloscopes HOO10 Hardware accelerated triggering and decoding in real-time Analysis of I C, SPI and UART/RS-232 signals on analog and logic channels. Display data in ASCII, binary, decimal or hexadecimal format Two buses can be analyzed at the same time. Powerful trigger to isolate specific data packages Detailed oom also available for serial bus analysis HOO11 Analysis of I C, SPI and UART/RS-232 signals on all analog channels. Color-coded display of decoded bus signals Only one bus available for analysis. Directly export analyzed data to USB flash drive A dd serial bus options to all HMO oscilloscopes with software licence HOO12 Analysis of CAN and LIN signals on analog and logic channels for two buses. keys at any time HO3508 | HO3516 Logic Probe L ogic probe HO3508 fits to all HMO series oscilloscopes (also available as double pack HO3516) No hardware lock to a specific device... -
Page 4: Carrying Case
EMC Precompliance Set 1 GHz | 3 GHz HO3011 Preamplifier for HMS Series Spectrum Analyzers The EMI precompliance sets EMC-PCS1/EMC-PCS3 include all necessary instruments to measure typical EMI problems. These sets contain a spec- trum analyzer (HMS1000/HMS3000), the HM6050-2 LISN, a probe set (HZ530/ HZ540) and the HMExplorer software for automated measurements. HMS1000 T he built-in preamplifier option can be unlocked via software licence at any time (not available for HMS1000E) D ANL: -135 dBm (100 Hz RBW) HM6050-2 Two-Line V-Network (LISN) HZ530 HM6050-2 HZ530 Near Field Probe Set 1 GHz Three active broadband probes, designed for 50 Ω inputs of HMS series, powered either by the analyzer or by batteries: E-field probe H-field probe High impedance probe... - Page 5 HMP Series Programmable High-Performance Power Supplies HMP4040 | HMP4030 - Four/Three-Channel Models HMP2030 | HMP2020 - Three/Two-Channel Models Low residual ripple due to linear post-regulators PC software (free of charge) to easily create user-defined waveforms Real-time voltage, current and watt values Independently adjustable over-voltage protection (OVP) for each channel H igh setting and read-back resolution: 1 mV and 0.1 / 0.2 / 1.0 mA Advanced parallel- and serial operation through V/I tracking (current output and model dependent) Front connectors: 4 mm safety sockets FuseLink (electronic fuses) freely combinable for all channels Rear connectors for all channels including SENSE FuseDelay tuneable up to 250 ms RS-232/USB dual interface, remote control via SCPI based commands EasyArb function directly programmable at the device HMP series HMP4040 HMP4030 HMP2030 HMP2020 model overview: 1 x 0 V to 32 V / 0 A to10 A, Output values 4 x 0 V to 32 V / 0 A to 10 A 3 x 0 V to 32 V / 0 A to 10 A 3 x 0 V to 32 V / 0 A to 5 A...
- Page 6 HMF Arbitrary Function Generator Frequency range: 10 μ Hz to 25 M Hz /50 MHz Triangle waveforms up to 10MHz Output voltage: 5 mV to 10 V (at 50Ω) W aveform modes: sine, square, triangle/ramp, pulse and arbitrary waveforms (incl. predefined waveforms as white/pink noise, sine cardinal, exponential rise/fall, et al.) Modulation modes: AM, FM, pulse, PWM, FSK (internal and external) Arbitrary waveform generator: 250 MSa/s, 14 bit, 256 kPts PC software (free of charge) to easily create user-defined waveforms Oscillographic signal display in real-time HMF2525 | HMF2550 - 25 MHz /50 MHz Models F ront USB connector to easily save and recall waveforms and settings R S-232/USB dual interface for remote control Fanless design HM8134-3 | HM8135 RF- Synthesizer Frequency range: 1 Hz to 1.2 GHz /3 GHz High dynamic output power: -127 dBm /-135 dBm to +13 dBm...
- Page 7 HM8040-3 multimeter HM8012 In many years of practical application the HAMEG modular system series 8000 has proven its value to the cus- tomer. The advantages of this modular system have been demonstrated by several 100,000 modules sold. The unexcelled price-performance ratio and the enormous flexibility of the plug-in system allow you to adapt your measurement setups quickly and cost effectively to changing requirements.
- Page 8 Inputs (CAT III): 2 safety (for HMP4030, HMP4040) case height 125 mm c onnectors *plus excess of the instrument HAMEG OSCILLOSCOPES ARE GREAT VALUE IN .SCOPE-OF-THE-ART. TEST & MEASUREMENT HAMEG Instruments GmbH | Industriestr. 6 | D-63533 Mainhausen | Germany Phone: +49 (0) 61 82 80 00 | info@hameg.com | www.hameg.com | blog.hameg.com...
