- Page 1 AD-4545 Service Manual American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447 E-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450331 - 1...
- Page 2 POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de tout autre appareil. IMPORTANT American Dryer Corporation AD-4545 450331 - 1...
-
Page 3: Table Of Contents
IMPORTANT You must disconnect and lockout the electric supply and the gas supply or the steam supply before any covers or guards are removed from the machine to allow access for cleaning, adjusting, installation, or testing of any equipment per OSHA standards. Please observe all safety precautions displayed on the equipment and/or specified in the installation manual included with the... -
Page 4: Parts Locations And Removal
Parts Locations and Removal ________ NOTE: Disconnect power to the machine at all times before removing or installing any components! Computer Panel Assembly Removal: Remove the four screws holding the computer panel to the dryer. Lift up on the panel and pull out the computer panel assembly. -
Page 5: Door Switch Removal
Door Switch Removal: Open the main door. Remove the two Phillips head screws attaching the door switch housing to the front panel. Disconnect the two wires on the door switch. Remove the two Phillips head screws (and associated nuts and star washers) holding the door switch to the door switch housing. -
Page 6: Burner Hi-Limit Removal
Burner Hi-Limit Removal: Remove top or bottom back guard panel. Remove the two red wires on the burner hi-limit switch. Remove the two screws holding the burner hi-limit switch to the dryer. Remove the hi-limit switch. Idler Arm Removal: Loosen the two 9/16” bolts holding the idler arm to the machine. -
Page 7: Sail Switch Removal
Sail Switch Removal: Remove the back guard. As shown in picture remove the two hex head screws. The sail switch box assembly will now come apart in two pieces. Remove the screws/nuts associated with the sail switch and remove it from the bracket. 450331 - 1 Ignitor Probe Assembly Removal: Remove the back guard, disconnect the orange boot from... -
Page 8: Rotation Sensor Removal
Rotation Sensor Removal: Remove the bottom nut on the rotation sensor. Lift the rotation sensor up and through the hole in the bearing box. Disconnect the rotation sensor two pin connector. Remove from the machine. Basket/Tumbler Support Removal: Remove lint screen assembly (refer to instructions). Remove front panel assembly (follow “To Replace Front Panel Assembly”). -
Page 9: Tumbler Alignment (Lateral)
Replace back guard. 10. Reconnect power to dryer. Tumbler Alignment (Lateral) Discontinue power to the dryer. Remove back guard. Loosen the two hex head bolts, (one turn is enough), that holds the pillow block bearing to the bearing box. Back off the two jam nuts on the side adjustment bolts. Now rotate the tumbler from the front of the dryer, checking the space between the tumbler and the front panel. - Page 10 ADC Part No. 450331 1 - 09/12/08 - 0...
