190W. Therefore, this fan is equipped with a wattage limiting device. Installation Guide For Model: PU52OB5 Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation.
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
3. Installation Preparation. blade edge To prevent personal injury and damage, inches 7 feet (76cm) ensure that the hanging location allows the (2.13m) blades a clearance of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or 12ft - 20ft obstruction.
5. Fan Assembly. set screw hole set screw If you wish to extend the hanging length of stop pin your fan, you must remove the hanging ball from the 4½in. downrod provided to use with an extended downrod (sold separately). [If you wish to use the 4½in.
Page 6
5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet box and able to support the fan, you safety cable loop wood are now ready to hang your fan. Grab the fan ceiling firmly with two hands. Slide downrod joist through opening in hanging bracket and let wood screw...
6. Wiring. Modifications not approved by the party responsible for compliance could void the user's authority to operate the equipment. *NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide CAUTION: Be sure outlet box is properly grounded reasonable protection against harmful interference in a residential installation.
9. Light Kit Assembly. motor housing Remove 1 screw from motor plate on underside of motor housing and partially loosen the other 2 screws. Align slotted holes in center of fitter plate with loosened screws in motor plate, allowing molex connections from motor housing to come through hole in motor plate middle of fitter plate.
12. Remote Control Operation. HI button - turns fan to HIGH speed MED button - turns fan to MEDIUM speed LOW button - turns fan to LOW speed OFF button - turns fan OFF button - controls LIGHT function: turns light ON/OFF when tapped quickly.
Return fan, shipping prepaid, to 4. Verify that receiver is wired properly. Craftmade/Ellington. We will repair or ship you a 5. Verify that wall control is wired properly. replacement fan, and we will pay the return shipping cost.
