Phaze
Installation Guide
For Model:
PHA52
net weight of 3 blades fan: 15.21 lb (6.9 kg)
net weight of 4 blades fan: 16.53 lb (7.5 kg)
net weight of 5 blades fan: 17.64 lb (8 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 2
Unpacking Your Fan. pg. 3
Parts Inventory. pg. 3
Installation Preparation. pg. 4
Hanging Bracket Installation. pg. 4
Fan Assembly. pgs. 5 - 7
Wiring. pg. 8
Canopy Assembly. pg. 8
Light Kit Assembly. pg. 9
Testing Your Fan. pg. 9
Troubleshooting. pg. 10
Parts Replacement. pg. 10
Warranty. pg. 10
page 1
PRINTED IN CHINA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Craftmade Phaze PHA52BNK5
Summary of Contents for Craftmade Phaze PHA52BNK5
-
Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Phaze Installation Guide For Model: PHA52 Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 3 Parts Inventory. pg. 3 Installation Preparation. pg. 4 Hanging Bracket Installation. pg. 4 Fan Assembly. -
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS. -
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. -
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that inches the hanging location allows the blades a clearance 7 feet (76cm) of 7ft. (2.13m) from the floor and 30in. (76cm) from (2.13m) any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft. -
Page 5: Fan Assembly. Pgs
5. Fan Assembly. Remove 6 screws and washers from yoke plate (located on top plate on top of motor housing) and set aside. Lift yoke plate and top plate to remove from motor housing and set yoke plate aside. Locate blade attachment screws/washers in hardware pack. - Page 6 5. Fan Assembly. (cont.) set screw stop pin Remove hanging ball from downrod provided by loosening set screw on hanging ball. Remove pin and clip. Lower hanging ball and remove stop pin. hanging ball Slide hanging ball off of the downrod. [Refer to diagram 1.] clip Loosen yoke set screws and nuts at top of motor...
- Page 7 5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet box safety cable loop and able to support the fan, you are now ready to wood hang your fan. Grab the fan firmly with two hands. ceiling Slide downrod through opening in hanging bracket joist and let hanging ball rest on the hanging bracket.
-
Page 8: Wiring
6. Wiring. WARNING: Turn off circuit breakers to current fixture from breaker panel and be sure operating light switch is turned to the OFF position. ground white supply wire (green or bare) CAUTION: Be sure outlet box is properly grounded and black supply wire that a ground wire (GREEN or Bare) is present. -
Page 9: Light Kit Assembly
8. Light Kit Assembly. motor housing Install two 9 watt medium base LED bulbs (included). IMPORTANT: When replacing bulbs, please allow bulbs and shade to cool down before touching. Align grooves on shade with nodules on inside edge of light kit fitter and push up gently on shade. -
Page 10: Troubleshooting
Service at 1-800-486-4892 to arrange for return of fan. 1. Check wall switch to fan. Return fan, shipping prepaid, to Craftmade. We will repair 2. Verify that reverse switch is set completely in or ship you a replacement fan, and we will pay the return either direction.
