Installation Guide
For Model:
SE68SPZ
E192641
net weight of fan: 32.01 lb (14.52 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE

Table of Contents:

Warranty. pg. 12
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE68SPZ and is the answer not in the manual?

Questions and answers

Related Manuals for Craftmade SE68SPZ

Summary of Contents for Craftmade SE68SPZ

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Model: SE68SPZ Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly. pgs. 4 - 5 Wiring.

  • Page 2: Safety Tips

    SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.

  • Page 4: Installation Preparation

    blade edge 3. Installation Preparation. To prevent personal injury and damage, ensure inches 7 feet (76 cm) that the hanging location allows the blades a (2.13m) clearance of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. 12ft.

  • Page 5: Fan Assembly. Pgs

    5. Fan Assembly. set screw set screw hole If you wish to extend the hanging length of your fan, you must remove the hanging ball from the 8in. stop pin downrod provided to use with an extended downrod (sold separately). [If you wish to use the 8in. downrod, please proceed to instructions following the dotted line below.] hanging ball...

  • Page 6: Wiring. Pgs

    5. Fan Assembly. (cont.) safety cable loop wood With the hanging bracket secured to the outlet box and ceiling able to support the fan, you are now ready to hang your joist fan. Grab the fan firmly with two hands. Slide downrod wood screw through opening in hanging bracket and let hanging and washer...

  • Page 7: Canopy Assembly

    6. Wiring. (cont.) IN ORDER TO WIRE WALL CONTROL, remove existing wall plate control wall switch. Wire the WALL CONTROL with wire outlet box connectors provided as shown in diagram at right. * Wrap each wire connector separately with electrical tape as an extra safety measure.

  • Page 8: Scroll Arm Assembly

    8. Scroll Arm Assembly. downrod scroll arm Remove 3 decorative screws from inside top of support decorative motor housing. Remove decorative screws from screws scroll arm support. motor housing Attach scroll arm to motor housing first. Align hole in larger end of one of the scroll arms with scroll arm scroll arm hole in top of motor housing--use decorative...

  • Page 9: Switch Housing Assembly

    10. Switch Housing Assembly. motor housing Remove 3 screws from outer edge of switch housing plate (save screws for later use). Remove 1 screw from fitter plate on underside of motor and partially loosen the other 2 screws. Align slotted holes in center of switch housing plate with loosened screws in fitter plate, allowing male plug from motor housing fitter...

  • Page 10: Automated Learning Process./Activating Code

    11. Automated Learning Process./Activating Code. CAUTION: The remote control transmitter can be TRANSMITTER programmed to multiple receivers or fans. If this is not (front) desired, turn wall switch off to any other programmable receiver or fan. L1 L1 L2 L2 This remote control transmitter is equipped with 16 code combinations to prevent possible interference from or to other remote units such as garage door...

  • Page 11: Wall Control Operation

    12. Wall Control Operation. ON/OFF slider switch - turns wall control ON or OFF HIGH button - turns fan to HIGH speed MED button - turns fan to MEDIUM speed LOW button - turns fan to LOW speed OFF button - turns fan OFF L1 button - turns lower light ON/OFF when pressed once;...

  • Page 12: Testing Your Fan

    14. Testing Your Fan. It is recommended that you test fan before finalizing installation. Locate ON/OFF slider switch on wall control and set to the ON position. Test light and dimmer functions with the L1 and L2 light buttons and then test fan speeds with different fan speed control buttons on the wall control.

  • Page 13: Troubleshooting

    6-YEAR to LIFETIME LIMITED WARRANTY: power and repeat instructions in the last paragraph CRAFTMADE/ELLINGTON will repair the fan, at no charge for of Section 11 (page 9). labor only to the original purchaser, if the fan motor fails to operate satisfactorily when failure results from normal use.
