READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Supreme Air 62 Installation Guide For Model: SUA62 Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly.
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS.
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches 7 feet that the hanging location allows the blades a (2.13m) (76cm) clearance of 7 feet (2.13m) from the floor and 30in. (76 cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft.
5. Fan Assembly. stabilization plate Remove blade arm screws and lock washers from underside of motor in order to remove blue motor stabilization plate. (Blue motor stabilization plate may be discarded once removed but save blade arm screws and lock washers to secure blade arms). [Refer diagram 1 to diagram 1.] Remove hanging ball from downrod provided by...
Page 6
5. Fan Assembly. (cont.) Thread safety cable and wires through hanging ball and then slide hanging ball over downrod--the top set screw hole of the downrod should be noted as having a set screw hole; use this hole when setting the set screw. stop pin Insert stop pin into top of downrod and raise hanging ball...
6. Wiring. white supply wire WARNING: Turn off circuit breakers to current fixture ground from breaker panel and be sure switch is turned to the (green or bare) black supply wire OFF position. CAUTION: Be sure outlet box is properly grounded and that a ground wire (GREEN or Bare) is present.
8. Blade Assembly. motor housing WARNING: To reduce the risk of serious bodily injury, DO NOT use power tools to assemble the blades. If overtightened, blades may crack and break. Time Saver: Washers for blade screws can be blade attachment set on each blade screw prior to installing screws and washers blades.
10. Testing Your Fan. It is recommended that you test fan before finalizing installation. Restore power from circuit box and light switch (if applicable). Test fan motor housing speeds with the pull chain. Start at the OFF position (no blade movement). First pull will set the fan to HI.
Service at 1-800-486-4892 to arrange for return of fan. 1. Check wall switch to fan. Return fan, shipping prepaid, to Craftmade. We will repair 2. Verify that reverse switch is set completely in or ship you a replacement fan, and we will pay the return shipping cost.
Page 11
LEER ESTAS INSTRUCCIONES Y GUARDARLAS PARA UTILIZACION FUTURA Supreme Air 62 Guía de instalación Para modelo: SUA62 Índice de materias: Sugerencias de seguridad. Pág. 1 Desempaquetado del ventilador. Pág. 2 Inventario de piezas. Pág. 2 Preparación para la instalación. Pág. 3 Instalación del soporte de montaje.
Page 12
SUGERENCIAS DE SEGURIDAD. ADVERTENCIA: para evitar la posibilidad de una descarga eléctrica, desconectar la corriente en la caja de fusibles principal o el interruptor protector antes de iniciar la instalación del ventilador o antes de repararlo o instalar accesorios. LEER TODAS LAS INSTRUCCIONES E INFORMACION DE SEGURIDAD CUIDADOSAMENTE ANTES DE INSTALAR SU VENTILADOR Y GUARDAR ESTAS INSTRUCCIONES.
Page 13
1. Desempaquetado del ventilador. Abrir el empaque cuidadosamente. Sacar los artículos del embalaje. Sacar el motor y ponerlo en una alfombra o en el embalaje para evitar rayar el acabado. Guardar la caja de cartón o el empaquetamiento original en caso de que tenga que mandar el ventilador para alguna reparación.
Page 14
3. Preparación para la instalación. borde del aspa 76cm Para prevenir daño corporal y otros daños, estar seguro de que el lugar en donde va a colgar el ventilador le permite 2,13m pulg.) un espacio libre de 2,13m (7 pies) entre las puntas de las (7 pies) aspas y el piso y 76cm (30 pulg.) entre las aspas y cualquier pared u otra obstrucción.
Page 15
placa de 5. Ensamblaje del ventilador. estabilización Sacar los tornillos para los brazos para las aspas y las arandelas de seguridad del lado inferior del motor para así quitar la placa de estabilización del motor de color azul. (La placa de estabilización del motor de color azul se puede desechar una vez quitada pero guardar los tornillos para los brazos para las aspas y diagrama 1...
Page 16
5. Ensamblaje del ventilador. (cont.) Pasar los cables y el cable de seguridad por la bola que sirve para colgar y luego deslizar la bola que sirve para agujero para el colgar sobre el tubo--la parte de arriba del tubo debe tornillo de fijación tener el agujero para el tornillo de fijación en ese extremo;...
Page 17
6. Instalación eléctrica. ADVERTENCIA: apagar los cortacircuitos en el panel de electricidad que suplen corriente a la caja de salida y alambre conductor blanco asegurarse de que el interruptor de luz esté APAGADO. toma de tierra (verde o pelada) PRECAUCION: asegurarse de que la caja de salida esté alambre conductor negro conectada a tierra como es debido y que exista un conductor a tierra (VERDE o...
Page 18
8. Colocación de las aspas. bastidor del motor ADVERTENCIA: para reducir el riesgo de lesiones corporales graves, NO utilizar herramientas eléctricas para ensamblar las aspas. Si aprieta demasiado los tornillos, las aspas podrían agrietarse y quebrarse. Para ahorrar tiempo: se pueden poner las arandelas en los tornillos que son para las aspas antes de colocar las tornillos y arandelas aspas.
Page 19
10. Verificación del funcionamiento del ventilador. Se le recomienda poner el ventilador a prueba antes de terminar la instalación. Regresar la corriente de bastidor del motor electricidad en el cortacircuitos y encender el interruptor de la luz en la pared (si se aplica). Verificar las velocidades del ventilador con la cadena de encendido.
Page 20
Problema: el ventilador se tambalea. y Craftmade pagará los gastos de envío de regreso. Soluciones: GARANTIA LIMITADA DE 6 AÑOS hasta DE POR VIDA: CRAFTMADE reparará el ventilador, sin costo al 1.
