Page 2
REVISION SHEET Sheet 1 of 10 Be sure to check the contents before utilizing the specification. This specification has the history shown below. Revisions Design Section Sheet Rev. No. Rev. Document Date WRT CHK Sheet Rev. Sheet Rev. Sheet Rev. ENACTMENT T.Endo Fukuda...
Page 3
REVISION SHEET Sheet 2 of 10 Be sure to check the contents before utilizing the specification. This specification has the history shown below. Revisions Design Section Sheet Rev. No. Rev. Document Date WRT CHK Sheet Rev. Sheet Rev. Sheet Rev. ENACTMENT 53-1 CHANGE...
Page 4
REVISION SHEET Sheet 3 of 10 Be sure to check the contents before utilizing the specification. This specification has the history shown below. Revisions Design Section Sheet Rev. No. Rev. Document Date WRT CHK Sheet Rev. Sheet Rev. Sheet Rev. ENACTMENT App.20 CHANGE...
Page 5
REVISION SHEET Sheet 4 of 10 REV. SHEET CHANGED CONTENTS DATE ùOptional Magnetic lnk Character Recognition (MICR) reader .. General Descriptio [Addition] Section 1.8, Paper - 4) c) Check paper (only when the printer is used with the MICR reader) [Addition] Section 1.8, Paper - 7) Notes on using the MICR reader [Addition]...
Page 6
REVISION SHEET Sheet 5 of 10 REV. SHEET CHANGED CONTENTS DATE Section 5.3, Customer Display DM-D202 and DM-D101 ® DM-D202II and DM-D101II [Change] Bit 3: Bit 3 is not transmitted ... ® Becomes 0 ... [Correction] DLE ENQ n - [Note] ù...
Page 7
REVISION SHEET Sheet 6 of 10 REV. SHEET CHANGED CONTENTS DATE 2.1.2 IEEE-P1284 ... ® IEEE 1284 [Correction] 3) The IEEE P1284... to change. [Deleted] 17-4 7) ...by changing ...switch2.) [Deleted] Table 2.1.5 [Deleted] 35-1 (*) Effective ... the printer [Deleted] I/F pin25 reset signal ®...
Page 8
REVISION SHEET Sheet 7 of 10 REV. SHEET CHANGED CONTENTS DATE 1.5 Auto Cutter Full cut/partial cut: ... ® Partial cut: ... [Correction] 17-5 2.1.4 Reception of status from the printer through the bidirectional parallel interface First Status in Example [Correction] 2.2.3 Drawer kick-out connector (modular connector) The host ...
Page 9
REVISION SHEET Sheet 8 of 10 REV. SHEET CHANGED CONTENTS DATE :Turn on/off parallel printing mode for receipt and journal ® ESC z Turn parallel printing mode on/off for receipt and journal :Turn on/off upside-down printing mode ® ESC { Turn upside-down printing mode on/off GS * :Define down-loaded bit-image ®...
Page 10
REVISION SHEET Sheet 9 of 10 REV. SHEET CHANGED CONTENTS DATE ESC * m n ® ESC * m n [d] n +256´n d1...dk [Correction] ® [Format] <1B>H<2A>H< m><n ><n >[<d>]n +256´n <1B>H<2A>H< m><n ><n >d1...dk [Correction] ´ 256 [Range] k = n ùDivide the number...is n + 256 ´...
Page 11
REVISION SHEET Sheet 10 of 10 REV. SHEET CHANGED CONTENTS DATE FS a 0 n 97-100 bit 4 and 5 is newly assigned. Descriptions for bit 4 and 5 is added. [Addition] TITLE TM-U950/U950P Specification (STANDARD)
1) This specification shall apply only to the product(s) identified herein. 2) This specification may be modified by SEIKO EPSON CORPORATION without any notice. It is necessary for "the customer" to inquire from SEIKO EPSON CORPORATION for the latest specification.
Page 15
4. CASE SPECIFICATIONS 4.1 External Dimensions and Weight...................45 4.2 Color ..........................45 4.3 External Appearance .....................45 4.4 Note ..........................45 5. OPTIONS 5.1 Standard Accessories....................46 5.2 Options ..........................46 5.3 Customer Display ......................46 6. COMMANDS 6.1 Command Notation ......................47 6.2 Control Commands ......................48 ..........................48 ..........................48 ..........................48...
Page 16
ESC G n ..........................64 ESC J n ..........................65 ESC K n ..........................65 ESC R n ..........................66 ESC U n ..........................67 ESC \ nL nH ........................67 ESC a n ..........................68 ESC c 0 n ..........................69 ESC c 1 n ..........................70 ESC c 3 n ........................70-1 ESC c 4 n ........................771 ESC c 5 n ..........................72 ESC d n ..........................72...
Page 17
6.3 Ignored Commands.......................94 6.4 MICR Control Commands (when the printer is used with the MICR reader) ....95 DLE EOT BS n ........................95 FS a 0 n ..........................97 FS a 1 ..........................101 FS a 2 ..........................102 FS b ..........................103 FS c ..........................104 APPENDIX A: MISCELLANEOUS NOTES...............APP.1 APPENDIX B: TRANSMIT STATUS IDENTIFICATION ...........APP.2 APPENDIX C: CONFIGURING THE SPACE PAGE............APP.3...
7,000,000 characters (*): when one character consists of 18 dots 3) Ribbon cassette overall dimensions (refer to Figure 1.3.1) (All the numeric values are typical.) Figure 1.3.1 Ribbon Cassette Overall Dimensions SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Refer to Figure 1.4.1. NOTE: The stamp mechanism is a factory option. The stamp set should be supplied by the user. Figure 1.4.1 Stamp Overall Dimensions Figure 1.4.2 Stamp Set Overall Dimensions SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Adjusting screw (refer to APPENDIX D) 1.7 Journal Paper Take-up Device The printer is equipped with a take-up device so journal paper is automatically taken up by driving the journal paper feed motor. SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Ambient temperature (print mode) Original + 4 copies Approx. 20° to 40°C (68° to 104°F) (copy mode) Original + 1 to 3 copies 5 to 40°C (41° to 104°F) (copy mode) SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Page 23
ù Since the slip insertion sensor uses a photo sensor, do not use paper that has holes at the sensor position, or is translucent (refer to Figure 1.8.2). SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Page 24
MICR head. ù Let go off the check immediately as soon as the printer starts feeding it. Otherwise, the paper is not fed straight, causing paper jams and MICR reading errors. SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Page 25
Figure 1.8.1 Slip Paper Glued Area Figure 1.8.2 Slip Insertion Sensor Position Figure 1.8.3 Paper Holes and Low Reflection Prohibited Area SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
1.9 Printable Area 1) Paper roll Figure 1.9.1 Paper Roll Printable Area 2) Slip paper Figure 1.9.2 Slip Paper Printable Area SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Page 27
3 mm above the bottom of the printable area. (All the numeric values are typical.) Figure 1.9.3 U.S.A. Personal Check Printable Area SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
3) Distance from the auto-cutting position to the emergency cutter position: Approx. 11.0 mm (0.43") NOTE: The dimensions in Figure 1.10.1 do not allow for paper slack. Therefore, take this into account when using the stamp or cutter. SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
CE marking EN55022 EN50082-1 EN45501 (except for when connected to IM) Safety Standard: TšV 2) North America: EMI: FCC Class A Safety standards: UL1950-2TH-D3 C-UL 3) Japan: EMI: VCCI Class 1 SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
No external or internal damage should be found after the vibration test, and the unit should operate normally. 4) Impact resistance: When packed: Package: EPSON standard package Height: 50 cm (19.69") Directions: 1 corner, 3 edges, and 6 surfaces No external or internal damage should be found after the drop test, and the unit should operate normally.
´100 Recognition rating (%) = Total number of checks ù Check paper used for test is Epson standard check paper. ù Checks must be flat, without curls, folds, or wrinkles. 3) Notes on installation location Do not install the printer near any magnetic fields because this may cause MICR reading errors.
ù When the printer stops printing due to a paper-end (if enabled by ESC c 4) ù When an error has occurred 3) Interface connector terminal assignments and signal functions are described in Table 2.1.1. SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Page 33
4. During paper feeding using the BUSY paper feed switch. 5. When the printer stops printing BUSY due to a paper-end. 6. When an error has occurred. BUSY 7. When the receive buffer BUSY becomes full. SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Page 34
NOTES: ù The XON code is <11>H and the XOFF code is <13>H. ù In case Â, XON is not transmitted when the receive buffer is full. ù In case Å, XOFF is not transmitted when the receive buffer is full. SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Page 35
TTL level, according to the DC characteristics described above, the operation is not guaranteed and pin 6 cannot be controlled. · When pin 6 (DSR) and pin 25 (INIT) are open, the printer is operating. SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
(Nibble). In the Byte Mode, data transmissions are proceeded by making the eight-bits data lines bidirectional. The both modes fail to be proceeded concurrently with the Compatibility Mode, thereby causing half duplex transmission. For detail description, refer to APPENDIX J. SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD) 17-1...
Page 38
Input LOW current 12 mA VIL=0.8V Logic-H Signal Sender Characteristics Specifications Characteristics Symbol Conditions Output HIGH voltage 3.0 V 5.5 V Output LOW voltage 2.0 V While the power is OFF SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD) 17-3 17-2...
Page 39
¥ Data Processing Time tReply ACKNLG Pulse Width tACK 10ps BUSY Release Time tBUSY ¥ ACK Cycle Idle Time tNEXT * The printer latches data at a nStrobe ¯timing. SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD) 17-4 17-3...
Check the printer status using ESC v or ESC u after transmitting each line of data and use the 2K byte receive buffer. Transmit one line of data so that the receive buffer does not become full. SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD) 17-5 17-4...
0001 0000 0000 0000 0000 0000 0000 0000 Second First Status Third Status Fourth Status Status The latest ASB (Â) 0001 0000 0000 0000 0000 0011 0000 0000 Fourth Status SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD) 17-5...
This connector is used to connect the printer to an external power source. 1) Pin assignments: Refer to Table 2.2.1. 2) Model: Hosiden TCS7960-532010 or equivalent Table 2.2.1 Power Supply Connector Pin Assignments Pin Number Signal Name +24 VDC Shell Frame GND SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Outputs the waveforms in Figure 2.2.2 to the points A and B in Figure 2.2.3. t1 (ON time) and t2 (OFF time) are specified by ESC p. Figure 2.2.2 Drawer Kick-out Drive Signal Output Waveform SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Page 44
4. Be sure to use the printer power supply (connector pin 4) for the drawer power source. 5. The resistance of the drawer kick-out solenoid must not be less than that specified (24 W). Otherwise, an overcurrent could damage the solenoid. SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
2.2.4 Customer display connector (For RS-232 serial interface) 1) Model: Receptacle: MOLEX 52065-8845 or equivalent 2) Pin assignments Pin Number Signal name Direction Output Output Input Figure 2.2.4 DM-D Connector SHEET TITLE REVISION TM-U950/U950P EPSON Specification NEXT SHEET (STANDARD)
Page 46
* * * * - - - - SHEET TITLE REVISION NEXT SHEET...
Page 47
\ \ \ \ o o o o * * * * SHEET TITLE REVISION NEXT SHEET...
Page 128
£ £ Off/On Decimal Function Readable fonts. See the table below. Undefined Unreadable font is detected and terminated. Unreadable font is detected and exchanged with ‘?’. Terminal symbol is identified. Terminal symbol is not identified. Undefined Not used. Fixed to Off. Readable Fonts Decimal Font...
Page 130
Off/On Decimal Function Readable fonts. See the table below. Undefined Rereading possible. Rereading not possible. Reading normal. Reading not normal. Not used. Fixed to On. Not used. Fixed to Off. Readable Fonts Decimal Font E13B CMC7 Undefined Undefined Bits 0 and 1: Identified character fonts. When bit 5 is 1 (abnormal end), either bit 0 or 1 has no meaning.
Page 131
Bit 5: Under the following conditions, the printer sets bit 5=1 (abnormal end). ¬ ® ¯ ° ± MICR Decimal MICR Decimal Character Character MICR Decimal MICR Decimal Character Character MICR Decimal MICR Decimal Character Character...
Page 149
1) Host Requests Reverse Transfer. 2) Successful Negotiation to Another mode. 3) Peripheral Has Data To Send. nDataAvail = Low 4) Peripheral Has No Data To Send. nDataAvail = High 5) Host Goes To Idle. HostBusy = Low 6) Peripheral Has New Data. 7) Peripheral Has Data Send.
Page 150
J.1.2.3 Other phases Initialization phase: This phase includes both power-on initialization and host-driven interface reset. Negotiation phase: Signal handshaking to change the signaling method from Compatibility Mode to Nibble, Byte or other such modes. Power-on phase: This phase includes power-on initialization for both devices. Termination phase: A host-initiated transition phase in which the interface is changed from Nibble, Byte or other such Mode to Compatibility Mode.
Page 151
In this interface, the printer status after power-on sequence is available by checking Logic- HIGH. In 500 ms after Logic-HIGH exceeds High level (3.0 V) following the power-on sequence, all signals become active. The printer may be forcedly reset through the nInit signal. However, in either of the following conditions, the forced printer reset becomes inoperative and Low level pulses are ignored.
Page 153
J.2.4.1 Description Normally the printer starts with Compatibility Mode in which it is Centronics interface compliant. In an attempt to transit to Nibble/Byte Mode, the printer proceeds with negotiation in response to the host request. Negotiation is proceeded as follows. 1) The host sets 1284-Active high to allow the interface to go to the Negotiation Phase.
Page 154
J.2.4.3 Notes 1) The start of negotiation phase shall be defined with 1284-Active triggered. 2) The timing to start negotiation in the Compatibility Mode shall be in principle after nAck pulse has been developed following nStrobe. Upon detection of 1284-Active before or during the output of nAck after nStrobe , the interface enters the negotiation phase.
J.2.5.1 Nibble Mode 1) After negotiating to the Nibble Mode, the host will set HostBusy(nAutoFd) low to indicate it is ready to accept data from the printer (event 7). 2) The printer responds by placing the lower four bits on the Reverse channel data lines then sets PtrClk(nAck) low (event 8, event 9).
Page 156
12) Whenever the printer generates data for the host in the Reverse Idle phase, it sets PtrClk low to request an interrupt from the host (event 18). 13) Then, the printer sets PtrClk high (event 19). 14) The host responds to the interrupt requested by the printer by setting HostBusy(nAutoFd) high (event 20).
Page 157
10) When the printer has any additional data, the host is provided with three options as listed below. 1. To set HostBusy(nAutoFd) low, indicating that the host is ready to accept additional data. 2. To remain in the Host Busy Data Available phase. 3.
Page 158
Termination refers to the processing to return to the Compatibility Mode from either Nibble or Byte Mode. To terminate either the Nibble or Byte Mode, the host must take the following actions. • To set 1284-Active(nSelectIn) low. • To set HostBusy(nAutoFd) high (event 22). Termination is available in two types.
