INSTALLATION, OPERATING
& SERVICE INSTRUCTIONS
FOR THE GARLAND
ELECTRIC XPRESS GRILL,
MODELS XE24, XE36
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS OR LIQUIDS IN THE
VICINITY OF THIS OR ANY OTHER APPLIANCE.
PLEASE READ ALL SECTIONS OF THIS MANUAL AND RETAIN FOR FUTURE REFERENCE.
THIS PRODUCT HAS BEEN CERTIFIED AS COMMERCIAL COOKING EQUIPMENT AND MUST BE INSTALLED
BY PROFESSIONAL PERSONNEL AS SPECIFIED.
For Your Safety:
Post in a prominent location, instructions to be followed in the event the user smells gas. This information shall be
obtained by consulting your local gas supplier.
Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent using genuine
Garland replacement parts. Garland will have no obligation with respect to any product that has been improperly installed,
adjusted, operated or not maintained in accordance with national and local codes or installation instructions provided
with the product, or any product that has its serial number defaced, obliterated or removed, or which has been modified
or repaired using unauthorized parts or by unauthorized service agents. For a list of authorized service agents, please refer
to the Garland web site at http://www.garland-group.com. The information contained herein, (including design and parts
specifications), may be superseded and is subject to change without notice.
Continuous product improvement is a Garland policy, therefore design and specifications are subject to change without notice.
GARLAND COMMERCIAL INDUSTRIES
185 East South Street
Freeland, Pennsylvania 18224
Phone: (570) 636-1000
Fax: (570) 636-3903
Part # 4517125 (09/03)
Part # 4517125 (09/03)
ALTERATION, SERVICE OR MAINTENANCE CAN
CAUSE PROPERTY DAMAGE, INJURY OR DEATH.
MAINTENANCE INSTRUCTIONS THOROUGHLY
GARLAND COMMERCIAL RANGES,
LTD.
1177 Kamato Road, Mississauga, Ontario L4W 1X4
CANADA
Phone: 905-624-0260
Fax: 905-624-5669
WARNING:
IMPROPER INSTALLATION, ADJUSTMENT,
READ THE INSTALLATION, OPERATION AND
BEFORE INSTALLING OR SERVICING
THIS EQUIPMENT.
Enodis UK LTD.
Swallowfield Way, Hayes, Middlesex UB3 1DQ ENGLAND
Telephone: 081-561-0433
Fax: 081-848-0041
© 2003 Garland Commercial Industries, Inc.
Page 1

Advertisement

Table of Contents
loading

Related Manuals for Garland XE24

Summary of Contents for Garland XE24

  • Page 1 Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent using genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation instructions provided with the product, or any product that has its serial number defaced, obliterated or removed, or which has been modified...

  • Page 2: Introduction

    The Garland Xpress Grill provides a method for efficient two-sided cooking, while accommodating a variety of products. The unit will also serve as a flat grill, and meets all standards for safety, efficiency, and cleanliness. Standard Features: • Stainless steel front, top & sides •...

  • Page 3: Table Of Contents

    System Info To View Recovery Time - Upper Platen: ... 19 To View Recovery Time - Grill: ... 19 To View the Garland Part Number: ...20 To View the Flash Number: ...20 To View the Software Number: ...20 To View the Download Number: ...20 System Setup To Change temperature Units, (°F or °C): ...21...

  • Page 4: Dimensions & Specifications, Xe18

    DIMENSIONS AND SPECIFICATIONS, MODEL XE24 11-1/2" (292mm) HEATER (2 PLACES) 24" (610mm) GRILL PLATE DEPTH GRILL PLATE WIDTH INLET Loading kW Per Phase Model 208/220/240V 3-Phase 3.67 XE24 1.84 5.51 * TB1 and TB2 are for dual supply units for the USA only.

  • Page 5: Dimensions & Specifications, Xe24

    GRILL PLATE WIDTH (1021mm) (918mm) Loading kW Per Phase Model 208/220/240V 3-Phase 5.53 XE24 2.78 8.31 * TB1 and TB2 are for dual supply units for the USA only. CAN is for single supply units, typically used in Canada only.

  • Page 6: Safety Precautions

    • DO NOT operate the Xpress grill unless all service and access panels are in place and fastened properly. The Garland Xpress Grill is a semi-automatic cooking appliance. The upper platen is lowered automatically, following the manual, two-handed initiation of the cooking cycle, and the upper platen is raised automatically upon completion of the cooking cycle.

  • Page 7: Installation

    IMPORTANT: Rating plates for this appliance are located in two places: 1) inside back panel on left side, 2) under front control panel on center. This equipment must be installed by a competent factory trained, certified, licensed and / or authorized service or installation person.

  • Page 8: Grill Controls

    CANCEL/ RAISE PLATEN BUTTON BUTTON MASTER POWER SWITCH Master Power Switch: Controls power to the grill and must be turned “ON” to start operation. The controller display will be active when the switch is “ON”. Indicator Lights: There are two, (2), indicator lights, indicating the temperature status of each control’s heat zones;...

  • Page 9: Power Button

    Power Button: After the main power switch is turned on, this button will put the control into cook mode. If pressed again, the control will go back to displaying “OFF.” Program Button: The primary function is to access Programming and Calibration of the grill.

  • Page 10: Operation

    Installing Release Material: Slide release material rod through hemmed end of the release material sheet. Hook release material rod on brackets located at the rear of the upper plate RELEASE MATERIAL HOOK RELEASE RELEASE MATERIAL SHEET MATERIAL ROD REAR OF GRILL Holding the bottom of the release material sheet in place, gently pull the sheet toward the front of the platen.

  • Page 11: Lighting Instructions

    To Cook in Two-Sided Mode: 1. Select a menu item by pressing the desired menu item is displayed. Press the Gap Setting Number desired for the selected item, (Gap Buttons 1-5, or hold for 6-10). The display may read either “TOO COOL” or “TOO HOT,” (alternating with the ‘MENU ITEM’), until the grill attains the set temperature range for that menu item, then the “MENU ITEM,”...

  • Page 12: Enter Standby Mode

    buttons at the same time, starting the cooking time countdown. NOTE: If the display reads either “TOO COOL” or “TOO HOT” the controller will not initiate a cooking sequence. 3. Perform the required functions as they are displayed, i.e.; sear, turn. To cancel the audible alerts, press the BLACK button.

  • Page 13: Cleaning & Maintenance

    PLATEN SET: This function allows the platen to be moved up or down once it is parallel to the grill surface. Values range from –160 to +160. EXTENDED TIME: This option will add 6, 4 and 2 seconds to the time of the next three cooks respectively if the grill has had no activity for 5 minutes.

  • Page 14: Platen Zeroing

    CLEANING AND MAINTENANCE continued 7. Remove the release sheet locking clips and bars. 8. Scrape only the lower grill surface with a grill scraper, and squeegee any residue into the grease troughs with a grill squeegee. Caution: Do not scrape or otherwise scratch the upper platens.
  • Page 15 CLEANING AND MAINTENANCE continued 6. Allow time for grill to heat and turn ready. Press both the Cancel (Green) and Standby (Black) buttons simultaneously to lower the upper platen. Press the Cancel (Green) button to raise the platen. Now, press both the Cancel (Green) and (Black) Buttons to re-lower the platen.

  • Page 16: Programming

    PROGRAMMING Programming Modes/Menu Sequence: Page 16 Part # 4517125 (09/03)
  • Page 17 PROGRAMMING continued Part # 4517125 (09/03) Page 17...

  • Page 18: Menu Items

    Menu Items... To Change the Cook Time of a Product: 1. Press and hold for three, (3) seconds. “ENTER CODE” will be displayed. 2. Using the Gap Setting buttons, enter the code, (1251). “ENTER CODE **** ” will be displayed. 3.

  • Page 19: To Change A Product Name

    5. Use to choose the desired Menu Item. 6. Press four, (4) times to display “(MENU ITEM) GRILL TEMP XXX” displayed in °F or °C. 7. Use to change the set temperature to the desired value. 8. Press to save the changes. 9.

  • Page 20: To View The Garland Part Number

    (1) time to display “PROGRAMMING MODE SYSTEM INFO.” 5. Press three, (3), times to view the Garland Part Number for the grill. “GARLAND PART # X…X” will be displayed. (number varies by grill). 6. Press to return to “PROGRAMMING MODE SYSTEM INFO”.

  • Page 21: System Setup

    System Setup To Change temperature Units, (°F or °C): 1. Press and hold for three, (3) seconds. “ENTER CODE” will be displayed. 2. Using the Gap Setting buttons, enter the code, (1251). “ENTER CODE **** ” will be displayed. 3. Press to enter the Programming Mode.

  • Page 22: To Change Probe Calibration - Grill

    6. Use to change the Probe Calibration to the correct temperature measured with a pyrometer.* SEE CALIBRATION REQUIREMENTS 7. Press to save the changes. 8. Press to return to “PROGRAMMING MODE SYSTEM SETUP” 9. Press again to exit. To Change Probe Calibration - Grill: 1.

  • Page 23: To Change Control Type

    6. Use to change the Instant on Time to the desired value. 7. Press to save the changes. 8. Press to return to “PROGRAMMING MODE MENU ITEMS” 9. Press again to exit. To Change Control Type: 1. Press and hold for three, (3) seconds.

  • Page 24: To Change The Alarm Mode

    3. Press to enter the Programming Mode. “PROGRAMMING MODE MENU ITEMS” will be displayed. 4. Press two, (2) times. “PROGRAMMING MODE SYSTEM SETUP” will be displayed. 5. Press eleven, (11) times. “START DELAY YES (or NO)” will be displayed. 6. Use to turn Start Delay on or off.

  • Page 25: To Perform Limit Switch Test

    8. Press to return to “PROGRAMMING MODE SERVICE MODE” 9. Press again to exit. To Perform Limit Switch Test: 1. Press and hold for three, (3) seconds. “ENTER CODE” will be displayed. 2. Using the Gap Setting buttons, enter the code, (1251). “ENTER CODE **** ” will be displayed.

  • Page 26: Calibration

    Bi-Weekly Calibration: Tools: Digital Pyrometer with Surface Probe Warning: PERSONAL INJURY FROM BURNS MAY RESULT WHEN COMING IN CONTACT WITH HOT COOKING SURFACES. NOTE: Calibration of grills is done with release material sheets installed. NOTE: CALIBRATION REQUIREMENTS The control software will beep to the user when it is appropriate to calibrate.

  • Page 27: Probe Locations

    Each upper platen has one thermocouple probe in the center. 11.5" 5.75" 22.5" 11.25" GRILL PLATE 24" 12" 6.09" 24" MODEL XE24 Part # 4517125 (09/03) CALIBRATION continued 11.5" 5.75" 22.5" 11.25" PLATEN (2 PLACES) 24"...

  • Page 28: Troubleshooting

    NOTE: WE STRONGLY SUGGEST THAT ANY INSTALLATION, MAINTENANCE AND REPAIRS SHOULD BE PERFORMED BY YOUR LOCAL GARLAND AUTHORIZED SERVICE AGENCY. PROBE ERROR: ...occurs when the probe is open or not connected. The control will turn the heat off. If the fault is in the platen the grill can still be used with recipes that do not call from the platen.

  • Page 29: Wiring Diagrams

    WIRING DIAGRAMS Part # 4517125 (09/03) Page 29...
  • Page 30 1333W Page 30 WIRING DIAGRAMS ACTUATOR 1333W 120V 240V YELLOW GRIDDLE GRIDDLE YELL PLATEN PLATEN Part # 4517125 (09/03)
  • Page 31 Part # 4517125 (09/03) Page 31...
