NOTE:
This manual pertains to both clam grill and flat grill models. The reader/operator must interpret its contents to applicable needs. However,
if there is any question of interpretation of any literature pertaining to Garland grills, please contact our Customer Service Department at
one of the phone numbers listed above.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE
VAPORS OR LIQUIDS IN THE VICINITY OF THIS OR ANY
OTHER APPLIANCE.
KEEP APPLIANCE AREA FREE AND CLEAR FROM COMBUSTIBLES!
PLEASE READ ALL SECTIONS OF THIS MANUAL AND RETAIN FOR FUTURE REFERENCE.
THIS PRODUCT HAS BEEN CERTIFIED AS COMMERCIAL COOKING EQUIPMENT AND MUST BE INSTALLED BY PROFESSIONAL
PERSONNEL AS SPECIFIED.
ALL BURNER ADJUSTEMENTS AND SETTINGS MUST BE MADE BY A QUALIFIED GAS TECHNICIAN.
NOTE:
Unit must be installed with no less than six inches (6") clearance from combustible construction at both sides and
rear.
FOR YOUR SAFETY:
Post in a prominent location, instructions to be followed in the event the user smells gas. This information shall be
obtained by consulting your local gas supplier.
CAUTION: THIS EQUIPMENT MUST ONLY BE OPERATED UNDER AN APPROVED HOOD SYSTEM
THIS EQUIPMENT "MUST" BE INSTALLED AND COMMISSIONED BY A PROFESSIONAL
FACTORY TRAINED TECHNICIAN
Part # 1382684 Rev. 4
CE Configuration
GRILLS
MODEL MWG-9501
MODEL MWGH-9501
MODEL MWGF-9501
MODEL MWGFH-9501
MODEL MWGL-9501
MODEL MWGR-9501
OPERATIONS MANUAL
MANUFACTURED EXCLUSIVELY FOR
McDONALD'S
GARLAND COMMERCIAL INDUSTRIES, INC.
185 EAST SOUTH STREET
FREELAND, PENNSYLVANIA 18224
TOLL FREE: (800) 446-8367
PHONE: (570) 636-1000
FAX: (570) 636-9874
E-mail: clamshell@garland-group.com
®
BY
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN CAUSE PROPERTY
DAMAGE, INJURY OR DEATH. READ THE INSTALLATION,
OPERATING AND MAINTENANCE INSTRUCTIONS
THOROUGHLY BEFORE INSTALLING OR SERVICING THIS
EQUIPMENT.
0049
WARNING:
Printed in the U.S.A.
(03/99)
