How to select a program
• 6 programs can be selected by the kind of the laundry.
• By pressing the program (
Whites Rapid Delicate Wool Synthetic] can be
selected.
C
S
W
W
R
D
P
y)
(Program)
Child-Lock
• Once Child-Lock is set, all buttons are inoperable
during operation.
• The Child-Lock system can be set at any time
even including during Power Off, on Pause and
operation. It is automatically cancelled when an
operational error occur and when the cycle ends.
• When power is off, the LED indicates
During operation, or when the program paused the
LED Will indicate
) button, [Coloreds
P
i
Door lock
only.
and the remaining time.

Error display

• The display blinks if there is an error.
• no inlet
: Trouble with water supply.
• imbalance : The laundry is tilted to one side.
• no drain
: The drain filter is clogged or the drain
pump is out of order.
(Power)
(Start/Pause)
(Door open)
Door lock display
• It shows whether the door
can be open or not during the
washing cycle.
• If the lamp is off, the door
can be opened.
11
Power button
• By pressing the button, it
repeats turning on and off.
• Press the button to cancel
the time delay.
• It turns off in 8 sec. after the
program is finished.
Start/Pause button
• Use the button to start or
pause wash cycle.
• The power turns off
automatically in 4 minutes
after the pause button is
pressed.
• Press the button to change
the program.
How to open the door
• Use the button to add the
laundry.
• Press the button to open
the door.
• Only operates when the
power plug is connected to
220-240V~ outlet.
