Technical Specifications - IBM Global console manager Decision Maker's Manual

Target device Ports
Number
Types
Connectors
Sync Types
Plug and Play
Video Resolution
Supported Cabling
Serial Port
Number
Cable type Serial
Connector
Network Connection
Number
Type ethernet:
Connector
Local Port
Number
Type
Connectors
USB Device Port
Number
Type
Dimensions
height x width x Depth
weight
Power Supply
heat dissipation
Airflow
Power consumption
AC-input power
AC-input voltage rate
AC-input current rating
AC-input cable
AC frequency
Ambient atmospheric condition ratings
Temperature
humidity
Safety and EMC approvals and markings
Last updated October 2005

Technical Specifications

16
VCo, KCo, and UCo
RJ-45
Separate horizontal and vertical
DDC2B
640 x 480 @ 60 hz (Local Port and Remote Port Minimum)
800 x 600 @ 75 hz
960 x 700 @ 75 hz
1024 x 768 @ 75 hz
1280 x 1024 @ 75 hz (Remote Port Maximum using a VCo)
4-pair UTP Cat5 or Cat6, 10 meters maximum length
1
RS-232
DB9 female
1
Ieee 802.3 2002 edition - 10BASe-T, 100BASe-T, 1000BASeT
RJ-45
1
USB, PS/2, and VGA
PS/2 miniDIN, 15 pin D, RJ-45
4
USB 2.0
1.72 in. x 17.00 in. x 10.98 in.; 1-U form factor
(4.37 cm x 43.18 cm x 27.98 cm)
7.3 lbs (3.31 kg) without cables
92 BTU/hr
8 CFM
12.5 watts
40 watts maximum
100 to 240 V ac Autosensing
0.5 A
18 AwG three-wire cable, with a three-lead IeC-320 receptacle on the power
supply end and a country-dependent connector on the power resource end
50 to 60 hz Autosensing
0° to 50° Celsius (32° to 122° Fahrenheit) operating
-20° to 60° Celsius (-4° to 140° Fahrenheit) nonoperating
20 to 80% noncondensing operating
5 to 95% noncondensing nonoperating
UL, FCC, cUL, ICeS, Ce, N, GS, IRAM, GoST, VCCI, MIC, C-Tick
5
