Technical Specifications - IBM Global console manager Decision Maker's Manual

Server Ports
Number
Cable Types
Connectors
Sync Types
Plug and Play
Video Resolution
Update Port
Number
Type
Connector
Local Port Sets
Number
Type
Connectors
Dimensions
height x width x Depth
weight
heat Dissipation
Airflow
Power Consumption
AC-input power
AC-input voltage rating
AC-input current rating
AC-input cable
AC-frequency
Temperature
humidity
Product Safety Standards
Last updated October 2005

Technical Specifications

8 (1x8 console switch), 16 (2x16 console switch)
USB and PS/2
RJ-45
Separate horizontal and vertical
DDC2B
Local Port Maximum 1280 x 1024 @ 75 hz
1
Serial RS-232
DB-9 Male
1 (1x8 console switch), 2 (2x16 console switch)
PS/2, VGA and ACI (ACI port available only for User A)
2 PS/2 MiniDIN 6, 1 hD15
4.45 cm x 43.18 cm x 27.94 cm 1 U form factor (1.75 in x 17.00 in x 11.00 in)
3.6 kg (8 lb) without cables
92 Btu/hr
8 CFM
12.5 watts
40 watts maximum
100 to 240 V ac Autosensing
0.5 A
18 AwG three-wire cable, with a three-lead IeC-320 receptacle on the power
supply end and a country or region dependent plug on the power resource end
50 - 60 hz
0° to 50° C (32° to 122° Fahrenheit) operating
-30° to 60° C (-22° to 140° Fahrenheit) transit
-20° to 60° C (-4° to 140° Fahrenheit) storage
20% to 80% noncondensing operating
5% to 95% noncondensing nonoperating
UL 60950-1, CSA C22.2 No. 60950-1, and eN 60950-1
12
