IBM CoNSoLe SwITCh
Decision Maker's Guide
Global Console Manager
Local Console Manager
1X8 Console Switch
2X16 Console Switch
Last updated October 2005
No solution built with IBM
Contents
the products are brought together using the right KVM switching options.
KVM switching solutions provide access and control of multiple servers
2
from a central console. These switches eliminate extra keyboards, monitors
3
and mice, allowing businesses to save critical space in their data centers.
4
IBM console switch solutions are designed to accommodate the full line of
5
xSeries server products, providing centralized control and management of
6
rack-optimized servers.
6
7
IBM now offers a new family of KVM switches. The Global Console
8
Manager appliances offer a choice of either the 2x16 (GCM2) or 4x16
(GCM4) for remote and local access. Additionally, there is the Local 2x8
9
Console Manager (LCM2) as well as the 1x8 Console Switch and the
2x16 Console Switch for local connectivity. They are all designed to offer
flexibility and scalability in managing a data center environment, as well as
dramatically reducing cable clutter at the rack.
Compelling reasons to buy a KVM solution from IBM:
• IBM KVM products have an intuitive graphical user interface (GUI)
that makes switching between connected systems simple and easy.
• IBM KVM products have been tested by IBM under the IBM
ServerProven® program and approved for operation with xSeries
servers, helping speed deployment while maximizing manageability
and control.
• As with all IBM KVM products, these KVM options are backed by
acclaimed IBM service and support and include a three-year limited
warranty** when installed in an IBM rack or used with IBM servers.
Server® xSeries® servers is complete until
