3-7. PC Health Status

Shutdown Temperature
CPU Core Voltage
DDR Voltage
ATX +3.3V
ATX +5V
ATX +12V
Battery Voltage
System Temperature
CPU Temperature
CPU FAN Speed
↑↓:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
Shutdown Temperature:
This item sets the temperature that would shutdown the system automatically in order to prevent system
overheats.
All Voltages, Fans Speed and Thermal Monitoring:
These unchangeable items list the current status of the CPU and environment temperatures, fan speeds,
and system power voltage.
Frequency/Voltage Control:
This item enables you to set the clock speed and system bus for your system. The clock speed and system
bus are determined by the kind of processor you have installed in your system.
DIMM Voltage Adjust
CPU Clock
↑↓:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
DIMM Voltage Adjust:
This item adjusts the voltage delivered to the DIMM memory.
CPU Clock:
Use the CPU Host Clock to set the frontside bus frequency for the installed processor (Min 200 MHz,
Max 232 MHz).
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
F6: Fail-Safe Defaults
Phoenix – AwardBIOS CMOS Setup Utility
Frequency/Voltage Control
F6: Fail-Safe Defaults
Disabled
2.5V
3.3V
5.0V
+12V
2.60V
200MHz
Item Help
F7: Optimized Defaults
Item Help
F7: Optimized Defaults
