BIOS Setup
Chapter 3. BIOS Setup
This motherboard provides a programmable EEPROM that you can update the BIOS utility. The BIOS
(Basic Input/Output System) is a program that deals with the basic level of communication between
processor and peripherals. Use the BIOS Setup program only when installing motherboard, reconfiguring
system, or prompted to "Run Setup". This chapter explains the Setup Utility of BIOS utility.
After powering up the system, the BIOS message appears on the screen, the memory count begins, and
then the following message appears on the screen:
If this message disappears before you respond, restart the system by pressing <Ctrl> + <Alt> + <Del>
keys, or by pressing the Reset button on computer chassis. Only when it failed by these two methods can
you restart the system by powering it off and then back on.
After pressing <Del> key, the main menu screen appears.
► Standard CMOS Features
► Advanced BIOS Features
► Advanced Chipset Features
► Advanced Chipset Features
► Power Management Setup
► PnP/PCI Configurations
► PC Health Status
Esc : Quit
F10 : Save & Exit Setup
NOTE: In order to increase system stability and performance, our engineering staffs are constantly
improving the BIOS menu. The BIOS setup screens and descriptions illustrated in this manual are for
your reference only, and may not completely match with what you see on your screen.
PRESS DEL TO ENTER SETUP
Phoenix – AwardBIOS CMOS Setup Utility
Time, Date, Hard Disk Type
► Frequency/Voltage Control
Load Fail-Safe Defaults
Load Optimized Defaults
Set User Password
Save & Exit Setup
Exit Without Saving
↑ ↓ → ← : Select Item
6A7L1A1Z
3-1
User's Manual
