2.8 PC Health Status

CPU Shutdown Temperature
CPU Warning Temperature
FAN Fail Alarm Selectable
Shutdown When FAN Fail
CPU FanEQ Control
- CPU FanEQ Target Temp.
- CPU FanEQ Temp. Tolerance
- CPU FanEQ Start Control
- CPU FanEQ Stop Control
SYS FanEQ Control
- SYS FanEQ Reference Temp.
- SYS FanEQ Target Temp.
- SYS FanEQ Temp. Tolerance
- SYS FanEQ Start Control
- SYS FanEQ Stop Control
CPU Temperature
System Temperature
PWM Temperature
CPU FAN Speed
SYS FAN Speed
AUX1 FAN Speed
AUX2 FAN Speed
CPU Core Voltage
DDR2 Voltage
Hyper Transport Voltage
NB Voltage
ATX +12V
ATX +3.3V
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
CPU Shutdown Temperature
You can set the processor shutdown temperature here. If the processor temperature exceeds
the settings value, system will force to shutdown to protect the processor not overheat.
CPU Warning Temperature
This item lets you select the temperature at which you want the system to send out a warning
message to the PC speakers of when the temperature goes beyond either limit. You can select
the temperatures you want.
FAN Fail Alarm Selectable
This item selects the fan that will be monitored for malfunction.
Shutdown When FAN Fail
When set to [Enabled], the system will be shut down if the fan selected for monitoring is not
running.
CPU FANEQ Control
This item allows you to control the CPU fan speed. When set to [Enabled], the following items
become selectable.
- CPU FanEQ Target Temp.
This item sets the temperature mark for the "CPU FanEQ" function to take effect.
AN52S/AN52
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
90 ° C/194 ° F
80 ° C/176 ° F
Disabled
Disabled
Enabled
50 ° C/122 ° F
5 ° C/ 41 ° F
80%
50%
Enabled
System
35 ° C/ 95 ° F
5 ° C/ 41 ° F
70%
50%
42 ° C/107 ° F
30 ° C/100 ° F
42 ° C/107 ° F
3245 RPM
0 RPM
O RPM
O RPM
1.29 V
1.87 V
1.20 V
1.20 V
12.00 V
3.30 V
F6: Fail-Safe Defaults
Item Help
F7: Optimized Defaults
2-17
