- Page 1 User Manual FPM-8192V/8232V 19”/23” Marine Grade Monitors...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
-
Page 3: Declaration Of Conformity
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information. -
Page 4: Technical Support And Assistance
Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –... -
Page 5: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. - Page 6 FPM-8192V/8232V User Manual...
-
Page 7: Table Of Contents
Audio Item Menu (Optional) ............25 Figure 3.14Audio Item Menu ............25 3.7.7 Reset Item Menu................. 26 Figure 3.15Reset Item Menu ............26 Appendix A Cleaning the Monitor ......27 Cleaning the Monitor ................28 Appendix B Troubleshooting ........29 Disclaimer ....................30 FPM-8192V/8232V User Manual... - Page 8 Environment: Outdoor Readability Measure....... 38 Caution on Handling Transflective LCD..........38 E.4.1 Operation & Storage Temperature Caution ........ 38 E.4.2 Contrast Ratio to Ambient Light Caution ........38 E.4.3 Protection Glass Selection............38 Touchscreen Selection ................39 FPM-8192V/8232V User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information... -
Page 10: Introduction
The display can accept multi-video inputs as DVI, VGA, S-Video or Composite for example. From 10.4 inch to 23.1 inch displays, our outstanding scaling board design also support PIP (picture in picture) function for special marine applications. FPM-8192V/8232V User Manual... -
Page 11: Basic Construction Of Marine Bridge System Display
For different panel characteris- tics, mechanical design, and electronic component, we can make it for you. Approved Marine Displays Advantech’s Marine Bridge System Display design are all followed IEC-60945 Mari- time Navigation and Radio-communication Equipment and Systems require- ments. -
Page 12: Touchscreen Solution (Optional)
Touchpoint density is based on controller resolution of 4096 x 4096 Touch Activation Force Typically less than 4 ounces (113 grams) Light Transmission HL products: 80% +/–5% at 550 nm wavelength Enhanced products: 60% +/–5% at 550 nm wavelength FPM-8192V/8232V User Manual... -
Page 13: Securetouch Surface Wave Touchscreen (Optional 2)
Touchpoint density is based on controller resolution of 4096 x 4096, plus 255 levels corresponding to touch pressure Touch Activation Force Typically 2 to 3 ounces (55 to 85 grams) Light Transmission Up to 90% per ASTM D1003-92 FPM-8192V/8232V User Manual... - Page 14 FPM-8192V/8232V User Manual...
-
Page 15: Chapter 2 Installation
Chapter Installation... -
Page 16: General Installation
Check the mechanical and mounting concept as below first. The fixture cut-out dimension and mounting holes based on drawing. Put the marine product on the fixture (console) from the front, and screw by four M6 x 30 mm black bolts with nuts. FPM-8192V/8232V User Manual... - Page 17 Use M4x 15mm bolts to drill through the fixture into the mounting holes on the rear side of IP65 front bezel.(The quantity of mounting screws based on draw- ing) Check the finished mounting concept. FPM-8192V/8232V User Manual...
- Page 18 Note! VESA and wall mount with mounting kit by special request. FPM-8192V/8232V User Manual...
-
Page 19: Installation Notice
These cables including RGB, DVI, RS232, LAN, and USB cable should be connected inside the area as marked below. For DC power connection, please make sure the power cable is tightly connected by two screws of the terminal block. FPM-8192V/8232V User Manual... - Page 20 FPM-8192V/8232V User Manual...
-
Page 21: Chapter 3 Operating The Lcd Display
Chapter Operating the LCD Display... -
Page 22: Osd User Controls
And the LED turns to red light when the TFT LCD display going to sleep. Refer to the OSD Single Key Function as below and understand how to use the dis- play functions step by step. Single Key Function SOURC AUTO FPM-8192V/8232V User Manual... -
Page 23: Pip (Picture In Picture) Function
Main Display. When OSD Menu is enabled, it moves right when navigating the Menu and Sub Menu and increments a slider bar. OSD Menu Function After the power on, press” ” to enter OSD Menu. FPM-8192V/8232V User Manual... -
Page 24: Figure 3.2 Osd Menu
” to exit. 3. Press “ ” (Up) and “ ” (Down) to select the sub-function. 4. When enter to each sub-function, press “ ” (Left) and “ ” (Right) to decrease / increase the bar value. FPM-8192V/8232V User Manual... -
Page 25: Display Item Menu
Adjust brightness only used in brightness knob. Adjustment is no response here. Composite S- Contrast Video Press “ ” / “ ” to adjust contrast. Note! The Brightness control from OSD is removed for dimming knob tuning. FPM-8192V/8232V User Manual... -
Page 26: Image Item Menu
Image Item Menu Figure 3.4 Image Item Menu (VGA) Figure 3.5 Image Item Menu (DVI) FPM-8192V/8232V User Manual... -
Page 27: Figure 3.6 Image Item Menu (Composite, S-Video)
“ to select the Noise Reduction for Off, Low, Mid, and High mode. Sharpness The Sharpness of the image may be optimized by using “ ” / “ ” to change the value of the slider bar. FPM-8192V/8232V User Manual... -
Page 28: Position Item Menu
The only button available is “SELECT”. Note this may change the values of Phase and Clock, and there is no ‘undo’ feature. 3.7.1 Position Item Menu Figure 3.7 Position Item Menu (VGA) Figure 3.8 Position Item Menu (DVI, Composite, S-Video) FPM-8192V/8232V User Manual... -
Page 29: Color Item Menu
” to change the vertical position value. Horizontal Move the screen left or right by using “ ” / “ ” to change the horizontal position value. 3.7.2 Color Item Menu Figure 3.9 Color Item Menu (VGA) FPM-8192V/8232V User Manual... -
Page 30: Figure 3.10Color Item Menu (Dvi, Composite, S-Video)
Press “ ” / “ ” to adjust the Red color to obtain the ness desired color settings. White Balance VGA Only When in “VGA” mode, press “Select” to adjust White Bal- ance for the display setting. FPM-8192V/8232V User Manual... -
Page 31: Pip Control Item Menu
Each input is scaled down to fit the window. Note! For PIP mode: Note that the PIP screen can have any position on the screen. This can be achieved by adjusting both Horizontal and Vertical positions. FPM-8192V/8232V User Manual... -
Page 32: Main Display Item Menu
Press “ ” and “ ” to select the Main Display main source, including VGA, DVI, Composite, and S-Video mode. Press “ ” to choose “Select”. 3.7.5 PIP Display Item Menu Figure 3.13 PIP Display Item Menu FPM-8192V/8232V User Manual... -
Page 33: Audio Item Menu (Optional)
Bass To configure the bass, use “ ” / “ ” to change the bass value. Mute To turn mute off/on, select either On/Off for Mute. By default, mute is set to No, or turned off. FPM-8192V/8232V User Manual... -
Page 34: Reset Item Menu
Item. Use “ ” / “ ” to select the “Yes” option, and press Composite S- Video “ ”. WARNING: All user adjustments will be lost. Press “EXIT“ )to return to the Main Menu without making changes. FPM-8192V/8232V User Manual... -
Page 35: Appendix A Cleaning The Monitor
Appendix Cleaning the Monitor... -
Page 36: Cleaning The Monitor
If it is still not clean enough, apply a small amount of non-ammonia, non-alcohol based glass cleaner onto a clean, soft, lint-free cloth, and wipe the screen. Don’t use water or oil directly on the monitor. If droplets are allowed to drop on the monitor permanent staining or discoloration may occur. FPM-8192V/8232V User Manual... - Page 37 Appendix Troubleshooting...
-
Page 38: Appendix B Troubleshooting
Check if the signal timing of the computer system is within the speci- fication of monitor. If you are unable to correct the fault by using this chart, stop using your monitor and contact your distributor or dealer for further assistance. FPM-8192V/8232V User Manual... -
Page 39: Appendix C Supported Modes
Appendix Supported Modes... -
Page 40: Graphics
1280 x 720 x 50P (HDTV) 720P 1280 x 720 x 60P (HDTV) 1080I 1920 x 1080 x 50I (HDTV) 1080P 1920 x 1080 x 60I Not all modes will be supported, due to different panel brands FPM-8192V/8232V User Manual... -
Page 41: Rs-232 Command Code (Optional)
Appendix RS-232 Command Code (Optional) -
Page 42: Rs-232 Command Code
Par1: 0x04 length (cannot be modified by user) Par2: 0x12 inquiry code (cannot be modified by user) Par3: 0x02 command code (can be modified by user) Par4: 0xE8 check sum (cannot be modified by user) FPM-8192V/8232V User Manual... -
Page 43: Appendix E Transflective Display (Optional)
Appendix Transflective Display (Optional) -
Page 44: Transflective Display
30,000 30,000 30,000 30,000 80,000 80,000 80,000 80,000 80,000 80,000 432.7 437.5 312.5 Brightness gain (nit) 1,180 1,150 1,320 1.20% 1.20% 0.83% 0.50% 0.70% Reflectance(net)(%) 1.15% 1.15% 0.98% 0.70% 0.65% 0.68% 1.16% 1.10% 0.90% 0.45% 0.40% 0.45% FPM-8192V/8232V User Manual... -
Page 45: Transflective Brightness Testing
Panel B 210 0.67(test 20,000 nit nits:20,000 ) **Our Labs ambient light is just for 10,000 nits, 20,000nit, 30,000nit, 40,000 nit or more ambient light value can be calculated by formula to estimate the brightness level of LCD panel FPM-8192V/8232V User Manual... -
Page 46: Environment: Outdoor Readability Measure
0.6%, so that the sunlight read- ability performance can work very well. Suggestion: Select an appropriate glass if you need to built-in protection glass. In addition, please feel free to inquire us for any protection glass information. FPM-8192V/8232V User Manual... -
Page 47: Touchscreen Selection
Since our technology is based on transflective principle, the glass or sensor will reduce the sunlight reflect out. It would have problem to use high reflectance sensor or glass on transflective LCD. Suggestion: ELO SAW and IR touch are recommended for touch screen solution on transflective LCD. FPM-8192V/8232V User Manual... - Page 48 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2007...
