- Page 1 User Manual FPM-5152G/5172G/ 5192G Series 15” XGA/17” SXGA/19” SXGA monitor with 18 ~ 32 V input voltage, resistive touchscreen and display port...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Consult the dealer or an experienced radio/TV technician for help. Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
- Page 4 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
-
Page 5: Table Of Contents
Contents Chapter Overview..........1 Introduction ....................2 Specifications .................... 2 1.2.1 General ..................2 1.2.2 Touchscreen ................. 2 LCD Specification..................3 Connectors....................3 Dimensions ....................4 Figure 1.1 FPM-5152G Dimension ..........4 Figure 1.2 FPM-5172G Dimension ..........5 Figure 1.3 FPM-5192G Dimension ..........6 Chapter System Setup ........7... - Page 6 FPM-5152G/5172G/5192G User Manual...
-
Page 7: Chapter 1 Overview
Chapter Overview This chapter includes: Introduction Specifications LCD Specification Power Consumption Connectors Dimensions... -
Page 8: Introduction
NEMA4/IP65. FPM-5152G/5172G/5192G is equipped with a touchscreen. With an 5-wire resistive type touchscreen, this monitor can be immediately transformed into a remote control system.The Advantech FPM-5152G/5172G/5192G is the ultimate HMI solution for your industrial applications. Specifications 1.2.1... -
Page 9: Lcd Specification
LCD Specification Specification 15” LCD 17” LCD 19” LCD Display type XGA TFT LCD SXGA TFT LCD SXGA TFT LCD Display size 15" 17" 19" 16.7 M 16.7 M Color 16.2M/262K (RGB 6bit+Hi-FRC data) (RGB 6bit+Hi-FRC data) Max. Resolution 1024 x 768 1280 x 1024 1280 x 1024 Viewing angle... -
Page 10: Dimensions
Dimensions Figure 1.1 FPM-5152G Dimension FPM-5152G/5172G/5192G User Manual... - Page 11 Figure 1.2 FPM-5172G Dimension FPM-5152G/5172G/5192G User Manual...
- Page 12 Figure 1.3 FPM-5192G Dimension FPM-5152G/5172G/5192G User Manual...
-
Page 13: Chapter 2 System Setup
Chapter System Setup This chapter includes: Wall Mounting Panel Mounting Rack Mounting Desktop Mounting Swing-Arm Mounting... -
Page 14: Monitor Installation
Monitor Installation Monitors of FPM-5152G/5172G/5192G series can be flexibly mounted, enabling them to be mounted on your desk or almost anywhere else. 2.1.1 Wall Mounting Users can directly install FPM-5152G/5172G/5192G on a wall through panel bracket.Refer to Figure 2.1 and following the steps below to install it: Screw the hook and wall-mounted brackets on the wall. -
Page 15: Panel Mounting
2.1.2 Panel Mounting Users can directly install FPM-5152G/5172G/5192G on a panel through additional panel bracket. Refer to Figure 2.2 and following the steps below to install it: Place the industrial monitor into 10pcs panel bracket. Fasten the screws to fix it. Figure 2.2 Panel Mounting FPM-5152G/5172G/5192G User Manual... -
Page 16: Rack Mounting
2.1.3 Rack Mounting If users need to install FPM-5152G/5172G/5192G on a rack, then ,FPM-5152G/ 5172G/5192G rack mounting kit must be purchased (Model: IPPC-6152A-RMKE (15”)/IPPC-6172A-RMKE(17”)/IPPC-6192A-RMKE(19”)).Screw the rack to the moni- tor firstly, then fix the monitor to the rack. Figure 2.3 FPM-5152G Rack Mounting Figure 2.4 FPM-5172G Rack Mounting FPM-5152G/5172G/5192G User Manual... -
Page 17: Desktop Mounting And Swing-Arm Mounting
Figure 2.5 FPM-5192G Rack Mounting 2.1.4 Desktop Mounting and Swing-Arm Mounting FPM-5152G/5172G/5192G monitors can also be mounted in other ways, such as desktop mounting and swing-arm mounting. 2.1.4.1 Desktop Mounting Users can directly install FPM-5152G/5172G/5192G on a desk through additional panel bracket. - Page 18 2.1.4.2 Swing-Arm Mounting (VESA Standard) The design of FPM-5152G/5172G/5192G conforms to VESA swing-arm mounting standard. Refer to Figure 2.7 to install it: This monitor supports 75 mm and 100 mm VESA dimensions. Figure 2.7 Swing-Arm Mounting FPM-5152G/5172G/5192G User Manual...
- Page 19 Appendix Touchscreen...
-
Page 20: Appendix A Touchscreen
Introduction FPM-5152G/5172G/5192G series' touchscreen uses advanced 5 wire resistive tech- nology. It provides more accurate sensing capacity than other techonologies.The touchscreen is specially designed for tough industrial environments, and has been approved to FCC Class B standards. Touchscreen Specifications(15”/17”/19”) A.2.1 Typical Optical Features Specification 15”... -
Page 21: Appendix Bosd Operation Keypad
Appendix OSD Operation Keypad... -
Page 22: Osd Operation Keypad Overview
OSD Operation Keypad Overview OSD Keypad has 3 buttons and 1 bi-colorLED indicator, which composed of OSD operation Keypad. B.1.1 OSD Button Descriptions Table B.1: OSD Button Descriptions Power Turn on/off monitor power Brightness Up Increase brightness Brightness Down Decrease brightness B.1.2 LED Function Descriptions Table B.2: LED Function Descriptions... - Page 23 FPM-5152G/5172G/5192G User Manual...
- Page 24 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2012...
