Cabinetry
Component Cooktop _vstem
Tools &
Materials
Required
(Not stq)plied)
Cutout
Information
• Carpenter's square
• Measuring tape
• Saw
• #2 Phillips head screwdriver bit socket
• Phillips screwdriver
• 1/4" nutdriver
• 5/16" nutdriver
• 7/16" and 5/16" socket and ratchet wrench
• Pencil
• Scissors
• Level
• Hole saw
• 6" 90 ° elbow
• Duct work to suit the installation.
For Gas Components:
• Pipe wrench
• Gas line to reach installation location
• Gas resistant pipe joint sealant.
• Manual gas line shut-off valve
• 3/4" NPT x 3/4" I.D. or 1/2" NPTx 1/2"
I.D. flare union adapter
• 1/2" NPTx 3/4" I.D. or 1/2" I.D. flare union
adapter
• 5 foot AGA certified flexible metal appliance
connector 3/4" x 1/2" I.D. to match gas
supply line.
-If required by local codes, use solid pipe
with fttings.
NOTE: Usenew flexible line, DONOT useold,
previouslyusedflexible line,
4" Minimum Between Cutouts
Front to Back Orientation
• Minimum clearance is
4"
between cooktops
in separate cutouts. This clearance does not
apply when multiple component cooktops
are installed in one cutout.
4"Minimum Between Cutouts
Side to Side Orientation
NOTE: Donot installa downdraftvent in a sideto side
orientationbehinda gasor halogencomponent, T his
wouldrequirethe userto reachovera heatedsurface
to accessthe control,
Find Dimension A in chart below and on the
following page.
1-3/4"Min.
to Side Wall
(2-3/4"
for Gas)
1-7/8" Min. to
RearWall (2-7/8"for !las)
T
19-1/2"
,, A _.
2-1/2" Min.
1-3/4"Min.
to Side Wall
'_ (2-3/4"
for Gas)
Front to Back Orientation
Cut the opening as shown above. Measure
carefully when cutting countertop, making
sure sides are parallel and fl'ont and rear cuts
are perpendicular to sides.
• The front and rear of the opening must cleat"
support rails of the cabinet.
• The cutout depth (front to back) is 19-1/2"
for all components.
1-7/8" Min.
to Side Wall
(2-7/8"
for Gas)
1-3/4" Min. to RearWall
(2-314" for gas)
A
, , 1-7/8"Min.
:to Side Wall
_19-1/2'" • ,_
(2-7/8"
for Gas)
2-1/2" Min.
Side to Side Orientation
Halogen
Gas
Updraft grill
Downdraft Grill
Downdraft Vent
A
14-1/2"
14-1/2"
154/8"
204/4"
5-1/8"
