Preface
Notebook Computer
D400S/D410S
Service Manual
I

Advertisement

Table of Contents
loading

Related Manuals for Clevo D400S

Summary of Contents for Clevo D400S

  • Page 1 Preface Notebook Computer D400S/D410S Service Manual...
  • Page 2 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 3 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the D400S/D410S series notebook PC.
  • Page 4 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC.

  • Page 5: Table Of Contents

    Preface Contents Introduction ..........1-1 Mainboard Overview - Bottom (Key Parts) ......... 1-12 Mainboard Overview - Top (Connectors) ........1-13 Overview ..................1-1 Mainboard Overview - Bottom (Connectors) ....... 1-14 System Specifications ..............1-2 Disassembly ..........2-1 Processor ..................1-2 Core Logic ..................1-2 Overview ..................2-1 Structure ..................1-2 Maintenance Tools ................
  • Page 6 Preface Removing the LCD Front Panel Module ........2-30 M650 (Host/AGP) 1 of 4 ..............B-6 Removing the Inverter ..............2-31 M650 (Memory for DDR) 2 of 4 ............B-7 Removing the PC Video Camera Module ........2-32 M650 (& CRT Out) 3 of 4 ..............B-8 Removing the LCD Module ............2-33 M650 (Power) 4 of 4 ...............B-9 Part Lists ..........A-1...

  • Page 7: Introduction

    1: Introduction Overview This manual covers the information you need to service or upgrade the D400S/D410S series notebook computer. Infor- mation about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.

  • Page 8: System Specifications

    Introduction System Specifications Processor • Intel Pentium 4 Processor - (478-pin) FC-PGA2 package µ 0.13) 0.13 Micron Process Technology, 512KB L2 Cache & 400MHz FSB - 2.0/ 2.2/ 2.4/ 2.5 /2.6 GHz µ 0.13) 0.13 Micron Process Technology, 512KB L2 Cache & 533MHz FSB - 2.26/ 2.4/ 2.53/ 2.66/ 2.66/ 2.8 GHz Core Logic •...

  • Page 9: Display

    Introduction Display • High Performance 256-bit 3D engine • Advanced HW accelerator for DVD playback Video Memory • Fully Direct X 8.0 compliant graphics engine • Dual-View display monitor The system allocates or "shares" a portion of • CRT Resolution up to 2048 * 1536 system memory video use.

  • Page 10: Keyboard

    Introduction Keyboard • “Win Key” keyboard Interface • Built-in TouchPad (scrolling key functionality integrated) • Three USB 2.0 ports • One IEEE 1394 port • One S-Video jack for TV output • One serial port • One parallel port (LPT1), supporting ECP / EPP •...

  • Page 11: Power Management

    Introduction Power Management • Supports ACPI v1.0b • Supports Hibernate mode • Supports Standby mode • Supports battery low sleep • Supports resume from modem ring Power • Full range AC adapter • AC-Input 100~240V, 50~60Hz • DC Output 20V, 3.25A (90w) •...

  • Page 12: Optional

    Introduction Optional • DVD-ROM Drive • CD-RW Drive • Combination Drive • Software DVD player • Wireless LAN module • Bluetooth module • Video Camera Design Differences This manual refers to the two notebook designs pictured below. The designs vary slightly in external design. Photographs used throughout this manual are of Design I.

  • Page 13: External Locator - Top View

    Introduction External Locator - Top View Figure 2 Top View 1. Optional Built-in USB Camera 2. LCD 3. Built-In Microphone 4. LED Power & Communication Indicators 5. LED Status Indicators 6. Hot-Key buttons 7. Close Cover Switch 8. Power Button 9.

  • Page 14: External Locator - Front & Left Side Views

    Introduction External Locator - Front & Left Side Views Figure 3 Front View 1. LCD Latches 2. IEEE 1394 Port 3. S/PDIF Out Port 4. Microphone-In Jack 5. Headphone-Out Jack 6. Infrared Transceiver 7. Wireless LAN On/ Off Switch 8. Built-In Speakers Figure 4 Left Side View 1.

  • Page 15: External Locator - Right Side & Rear Views

    Introduction External Locator - Right Side & Rear Views Figure 5 Right Side View 1. Security Lock Slot Figure 6 Rear View 9 10 1. Vent 2. DC-In Jack 3. 2 * USB Ports 4. External Monitor (CRT) Port 5. Parallel Port 6.

  • Page 16: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 7 Bottom View 1. Vent/Fan Outlets 2. Battery Cover 3. Hard Disk Cover 4. Bluetooth Module Cover 5. CPU Heatsink Cover Note: The RAM and optional Wireless LAN module are lo- cated under the CPU Heatsink Cover 1 - 10 External Locator - Bottom View...

  • Page 17: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 8 Mainboard Top Key Parts 1. PC Card Assembly 2. Northbridge - SiS M650 3. Southbridge - SiS 4. LPC Super I/O NS PC87393 5. Flash ROM BIOS Mainboard Overview - Top (Key Parts) 1 - 11...

  • Page 18: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 9 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Memory Sockets (no memory installed) 3. SiS 302LV TV- Out Controller 4. LAN Controller RTL8100BL 5. CardBus ENE 1410 6. ALC202 - Audio Codec 7.

  • Page 19: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 10 Mainboard Top Connectors 1. Modem Cable Connector (CN1) 2. LCD and Inverter Connector (JLCD1) 3. Video Camera Module Connector (JCCD1) 4. Switch Board Connector (JSW1) 5. Fan Connector (JFAN1) 6. TouchPad Connector (JTP1) 7.

  • Page 20: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 11 Mainboard Bottom Connectors 1. Wireless LAN Connector (JWL1) 2. Fan Connector (JFAN2) 3. CD Connector (JCDROM1) 4. Hard Disk Connector (JHDD1) 5. Bluetooth Connector (JBT1) 6. Battery Connector (JBAT1) 7. Battery Connector (CN5) 1 - 14 Mainboard Overview - Bottom (Connectors)

  • Page 21: Disassembly

    Disassembly 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the D400S/D410S series notebook’s parts and sub- systems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). Component Parts We suggest you completely review any procedure before you take the computer apart.

  • Page 22: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 23: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 24: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Processor: 1. Remove the battery page 2 - 8 1.
  • Page 25 Disassembly To remove the TouchPad and Click Board: To remove the Modem: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.
  • Page 26 Disassembly To remove the Mainboard: To remove the Floppy Disk Drive Assembly: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.
  • Page 27 Disassembly To remove the LCD Front Panel Module: To remove the PC Video Camera Module: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.

  • Page 28: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. 2. Remove screws & (Figure 1a) from the battery cover , and remove the cover. 3. Carefully (use a small screwdriver) disconnect the battery cable at point (Figure 1b) 4.

  • Page 29: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.

  • Page 30: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting DDR 200/266/333MHz. The main memory can be expanded up to 1024MB. The SO-DIMM modules supported are 128Mb, 256Mb, and 512Mb. The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 31 Disassembly 5. Gently pull the two release latches ( & on the sides of the memory socket toward the sides of the computer. Figure 4 Removing/ Installing a RAM Module a. Pull release latches. b.Remove the module. 6. The module (Figure 4b) will pop-up, and you can remove it.

  • Page 32: Removing The Cd Device

    Disassembly Removing the CD Device The easy changeable CD device may be upgraded or changed. 1. Turn off the computer, remove the battery ( page 2 - 8 ) and turn it over. 2. Remove screws (Figure 5a) from the memory socket cover 3.
  • Page 33 Disassembly 4. Use a screwdriver to carefully push the CD device assembly out of the computer at point Figure 6 CD Device Removal Push the CD device out off the computer at point 5. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The screw holes should line up.

  • Page 34: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module page 2 - 8 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws (Figure 7a) from the Bluetooth module cover 3. Carefully lift up the Bluetooth module cover off the computer.

  • Page 35: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module page 2 - 8 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- nect it).

  • Page 36: Removing The Processor

    Disassembly Removing the Processor page 2 - 8 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- Figure 9 nect it).
  • Page 37 Disassembly 6. Use a screwdriver to unlock the CPU by giving the lock (Figure 10a) a turn to the left. 7. Lift the CPU (Figure 10c) off the computer (make sure the lock is fully turned to the left as the CPU will lift off with ease).

  • Page 38: Removing The Keyboard

    Disassembly Removing the Keyboard page 2 - 8 1. Turn off the computer, remove the battery ( 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you may need to use a small screwdriver to do this). 3.

  • Page 39: Removing The Keyboard Shielding Plate

    Disassembly Removing the Keyboard Shielding Plate page 2 - 8 page 2 - 18 1. Turn off the computer, remove the battery ( ) and keyboard ( 2. Remove screws (Figure 12a) from the keyboard shielding plate and lift the plate off the computer.

  • Page 40: Removing The Lcd And Top Case

    Disassembly Removing the LCD and Top Case page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...
  • Page 41 Disassembly & 5. Slide the LCD hinge covers (Figure 14a) out of the computer. 6. Remove screws & (Figure 14b) then carefully (pay careful attention to the antenna cables) lift the LCD assembly (Figure 14c) off the computer. & & 7.

  • Page 42: Removing The Touchpad And Click Board

    Disassembly Removing the TouchPad and Click Board page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 43: Removing The Switch Board

    Disassembly Removing the Switch Board page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 44: Removing The Modem

    Disassembly Removing the Modem page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 45: Removing The Speakers

    Disassembly Removing the Speakers page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 46: Removing The Mainboard

    Disassembly Removing the Mainboard page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 47: Removing The Fan Unit

    Disassembly Removing the Fan Unit page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 48: Removing The Floppy Disk Drive Assembly

    Disassembly Removing the Floppy Disk Drive Assembly page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 49: Removing The Pc Card Assembly

    Disassembly Removing the PC Card Assembly page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 50: Removing The Lcd Front Panel Module

    Disassembly Removing the LCD Front Panel Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 51: Removing The Inverter

    Disassembly Removing the Inverter page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 52: Removing The Pc Video Camera Module

    Disassembly Removing the PC Video Camera Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 53: Removing The Lcd Module

    Disassembly Removing the LCD Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...
  • Page 54 Disassembly 2 - 34 Removing the LCD Module...

  • Page 55: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the D400S/D410S series notebook’s construction into a series of illustrations. The compo- nent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 56: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table 1 - 1 Part List Illustration Part 400S 410S Location page A - 3 page A - 13 page A - 4 page A - 14 Bottom LCD 14”...

  • Page 57: Top (400S

    Part Lists Top (400S) Figure 1 Top (400S) Top (400S) A - 3...

  • Page 58: Bottom (400S

    Part Lists Bottom (400S) Figure 2 Bottom (400S) A - 4 Bottom (400S)

  • Page 59: Lcd 14" (400S

    Part Lists LCD 14" (400S) Figure 3 LCD 14" (400S) LCD 14" (400S) A - 5...

  • Page 60: Lcd 15" (400S

    Part Lists LCD 15" (400S) Figure 4 LCD 15" (400S) A - 6 LCD 15" (400S)

  • Page 61: Cd-Rom Drive (400S

    Part Lists CD-ROM Drive (400S) Figure 5 CD-ROM Drive (400S) CD-ROM Drive (400S) A - 7...

  • Page 62: Cd-Rw Drive (400S

    Part Lists CD-RW Drive (400S) Figure 6 CD-RW Drive (400S) A - 8 CD-RW Drive (400S)

  • Page 63: Combo Drive (400S

    Part Lists Combo Drive (400S) Figure 7 Combo Drive (400S) Combo Drive (400S) A - 9...

  • Page 64: Dvd-Rom Drive (400S

    Part Lists DVD-ROM Drive (400S) Figure 8 DVD-ROM Drive (400S) A - 10 DVD-ROM Drive (400S)

  • Page 65: Floppy Disk Drive (400S

    Part Lists Floppy Disk Drive (400S) Figure 9 Floppy Disk Drive (400S) Floppy Disk Drive (400S) A - 11...

  • Page 66: Hard Disk Drive (400S

    Part Lists Hard Disk Drive (400S) Figure 10 HDD Drive (400S) A - 12 Hard Disk Drive (400S)

  • Page 67: Top (410S

    Part Lists Top (410S) Figure 11 Top (410S) Top (410S) A - 13...

  • Page 68: Bottom (410S

    Part Lists Bottom (410S) Figure 12 Bottom (410S) A - 14 Bottom (410S)

  • Page 69: Lcd 14" (410S

    Part Lists LCD 14" (410S) Figure 13 LCD 14" (410S) LCD 14" (410S) A - 15...

  • Page 70: Lcd 15" (410S

    Part Lists LCD 15" (410S) Figure 14 LCD 15" (410S) A - 16 LCD 15" (410S)

  • Page 71: Cd-Rom Drive (410S

    Part Lists CD-ROM Drive (410S) Figure 15 CD-ROM Drive (410S) CD-ROM Drive (410S) A - 17...

  • Page 72: Cd-Rw Drive (410S

    Part Lists CD-RW Drive (410S) Figure 16 CD-RW Drive (410S) A - 18 CD-RW Drive (410S)

  • Page 73: Combo Drive (410S

    Part Lists Combo Drive (410S) Figure 17 Combo Drive (410S) Combo Drive (410S) A - 19...

  • Page 74: Dvd-Rom Drive (410S

    Part Lists DVD-ROM Drive (410S) Figure 18 DVD-ROM Drive (410S) A - 20 DVD-ROM Drive (410S)

  • Page 75: Floppy Disk Drive (410S

    Part Lists Floppy Disk Drive (410S) Figure 19 Floppy Disk Drive (410S) Floppy Disk Drive (410S) A - 21...

  • Page 76: Hard Disk Drive (410S

    Part Lists Hard Disk Drive (410S) Figure 20 HDD Drive (410S) A - 22 Hard Disk Drive (410S)
  • Page 77 Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the D400S/D410S notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table 1 Diagram - Page Diagram - Page Schematic System Block Diagram - Page B - 2...

  • Page 78: Schematic Diagrams

    Schematic Diagrams System Block Diagram D400 System Block Diagram NORTHWOOD CLOCK GENERATOR SOCKET - 478 TV-OUT Host Bus GTL+ & AGTL SiS 302LV VB-LINK DDR INTERFACE Sheet 1 of 35 PANEL SiS M650 System Block 702 mBGA Diagram CRT PORT Ultra 66/100/133 HDD/CD-ROM CON M I II/F...
  • Page 79 Schematic Diagrams Socket 478 1 of 2 HD#[0..63] HD#[0..63] [5] VCC_CORE JCPU1A HD#0 HA#[3..31] HA#[3..31] HD#1 HD#2 HD#3 HA#31 HD#4 HA#30 HD#5 HA#29 HD#6 HA#28 L<0.1inch HD#7 HA#27 R535 HA#31 HD#8 HA#26 1K(R) HD#9 HA#25 HD#10 HA#24 Q29(R) HD#11 HA#23 2N7002 HD#12 HA#22...

  • Page 80: Socket 478 & Itp 2

    Schematic Diagrams Socket 478 & ITP 2 of 2 VCC_CORE 49.9_1% CPUGTLVREFA R275 CPUGTLVREFB 49.9_1% C316 C313 C330 R276 C346 C349 C112 220P 220P 100_1% 220P 220P 100_1% CPU SIGNAL TERMINALION VCC_CORE VCC_CORE CLOSE TO CPU JCPU1B FERR# R274 4.7uH_SMD_30% 62_1% IERR AE23...

  • Page 81: Clock Generator

    Schematic Diagrams Clock Generator Damping Resistors Main Clock Generator Place near to the +3VS By-Pass Capacitors Clock Outputs Place near to the Clock CLOCK GEN (650) FCM2012V121 Outputs CLK_VCC3 VDDREF CPU-1 49.9_1% RP44 HCLK-CPU HCLK-CPU VDDZ CPUCLK0 HCLK-CPU [3] C401 CPU-2 49.9_1% C102...

  • Page 82: M650 (Host/Agp) 1

    Schematic Diagrams M650 (Host/AGP) 1 of 4 AHSYNC VAHSYNC [10] BHSYNC VADE VBHSYNC [10] VADE [10] AVSYNC VAVSYNC [10] BVSYNC VBDE VBVSYNC [10] VBDE [10] R264 HNCOMP BCLK VBCLK [10] Rds-on(n) = 10 ohm 20_1% HNCVERF = 1/3 VCCP R263 HPCOMP 10PF(R) NEAR SISM650...

  • Page 83: M650 (Memory For Ddr) 2

    Schematic Diagrams M650 (Memory for DDR) 2 of 4 /RMD[0..63] /RMD[0..63] [7,8] /RDQM[0..7] /RDQM[0..7] [7,8] /RDQS[0..7] /RDQS[0..7] [7,8] /RMA[0..14] /RMA[0..14] [7,8] /RCS#[0..5] /RCS#[0..5] [7,8] CKE[0..5] CKE[0..5] [7] Rs place close to DIMM1 BGA1B +2.5V /RMD4 RP46 AJ23 /RMD5 AG22 DQM0 /RDQM0 AH21 /RMD6...

  • Page 84: M650 (& Crt Out) 3

    Schematic Diagrams M650 (& CRT Out) 3 of 4 BGA1C SIS M650 NOTE: This page is for universal PCB design( suitable for both 645 or 650) ZCLK0 ZCLK0 ZCLK REFCLK0 NB Hardware Trap Table VOSCI REFCLK0 [4] ZUREQ [13] ZUREQ ZUREQ ZDREQ embedded pull-low...

  • Page 85: M650 (Power) 4

    Schematic Diagrams M650 (Power) 4 of 4 +3VS +3VS +1.8VS +3VS C360 +1.8V 10UF/10V 0.1UF C412 C410 C374 BGA1D 10U(0805) 10UF/10V 0.1UF C427 C423 C381 +1.8V AUX1.8 AUX3.3 0.1UF C426 C395 C367 0.1UF 0.1UF 0.1UF +1.8VS C382 C681 0.1UF +3VS +1.8VS C363 0.1UF...

  • Page 86: Ddr Memory Dimm

    Schematic Diagrams DDR Memory DIMM +2.5V /RMA0 /RMD0 /RMA0 +2.5V /RMA1 /RMD1 /RMA1 /RMA2 /RMD2 /RMA2 RP20 /RMA3 /RMD3 /RMA3 CKE4 /RMA4 /RMD4 /RMA4 CKE2 /RMA5 /RMD5 /RMA5 CKE3 /RMA6 /RMD6 /RMA6 CKE5 /RMA7 /RMD7 /RMA7 /RMA8 /RMD8 /RMA8 8P4R-470 /RMA9 /RMD9 /RMA9...

  • Page 87: Ddr Sstl-2 Termination

    Schematic Diagrams DDR SSTL-2 Termination SSTL-2 Termination Resistors MD/DQM(/DQS) SSTL-2 MA/Control SSTL-2 SSTL-2 OD 2.5V /RMD[0..63] /RMD[0..63][6,7] /RDQM[0..7] /RDQM[0..7][6,7] +1.25VS +1.25VS /RDQS[0..7] /RDQS[0..7][6,7] /RMA[0..14] /RMA[0..14] [6,7] /RCS#[0..5] /RCS#[0..5] [6,7] /RMD0 /RMA2 /RMA0 /RMD1 /RDQS0 /RMA12 /RSRAS# /RMD2 [6,7] /RSRAS# RP63 8P4R-33 RP34 8P4R-33...

  • Page 88: Lvds Interface (Sis302Lv

    Schematic Diagrams LVDS Interface (SiS302LV) C248 33PF(R) +3VS COMPOSITE R211 0(R) Z1301 LVDD1 FCM1608K121 R212 FCM1608K-121T07 JTV1 10UF/10V 0.1UF 0.1UF LGND 2.7UH DA204U(R) DA204U(R) R213 C250 33PF(R) R202 C261 C249 C262 C251 330PF 330PF +3VS 330PF 330PF LVDD2 SVIDEO CON PIN(GND1,GND2)=GND FCM1608K121 +3VS...

  • Page 89: Panel Con & Led Indicator

    Schematic Diagrams Panel Con & LED Indicator +3VS LCDVCC LCDVCC LCDVCC 4800 FCM2012V-121 FCM2012V-121 C322 C284 JLCD1 +3VS C337 C338 0.1UF 0.1UF R278 TXOUT-LN0 TXOUT-UN0 4.7U(0805) 0.1UF C285 C286 TXOUT-LP0 TXOUT-UP0 R301 0.1UF 4.7U(0805) TXOUT-LN1 TXOUT-UN1 Z245 TXOUT-LP1 TXOUT-UP1 TXOUT-LN2 TXOUT-UN2 TXOUT-LP2 TXOUT-UP2...

  • Page 90: Pci/Ide/Hyperzip) 1 Of 4

    Schematic Diagrams 962 (PCI/IDE/HyperZip) 1 of 4 AD[0..31] IDESAA[0..2] [19,20,25] AD[0..31] IDESAA[0..2] [14] IDECS#A[0..1] IDECS#A[0..1] [14] IDESAB[0..2] IDESAB[0..2] [14] +1.8VS IDECS#B[0..1] IDECS#B[0..1] [14] R118 BGA2A C151 C150 +3VS 0.01UF 0.1UF IDEAVDD REQ4# PREQ#4 IDEAVSS REQ3# RP32 PREQ#3 REQ2# ICHRDYA [25] REQ2# ICHRDYA [14] PREQ#2...

  • Page 91: Misc Signals) 2 Of 4

    Schematic Diagrams 962 (Misc Signals) 2 of 4 BGA2B Programable on-die pull-high strength for CPU_S: ( Infinite, 150, 110, 56 Ohm) R102 4.7K NEED NOT to place OSC25MHI INIT# close to 96X +3VS INIT# INIT# OSC25MHO A20M# A20M# A20M# RN11 SMI# SMI# SMI#...

  • Page 92: Usb I

    Schematic Diagrams 962 (USB I/F) 3 of 4 BGA2C 1394_MA2/EESK UCLK48M UCLK48M[4] EESK(GPI21) USBCLK48M 1394_MA1/EEDI EEDI(GPI22) 1394_MA0/EEDO UV3- -DATA3 EEDO(GPI23) -DATA3 [17] 1394_EECS UV0+ UV0+ [17] EECS(GPI24) UV0+ UV0- UV3+ +DATA3 UV0- UV0- [17] +DATA3 [17] UV1+ UV1+ [17] UV1+ UV1- UV1- [17] UV1-...

  • Page 93: Power & Rtc) 4 Of

    Schematic Diagrams 962 (Power & RTC) 4 of 4 +1.8VS +1.8V +3VS C512 C511 C351 C406 C526 C489 C490 C505 C508 C469 C147 C482 C476 C501 C477 C127 0.1UF 0.1UF 10UF/10V 10UF/10V 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V BGA2D +1.8VS VDDZ...

  • Page 94: Hdd/Combo Connector

    Schematic Diagrams HDD/Combo Connector RP41 IDEDB7 /2IDB7 [13] IDEDB7 IDEDB6 /2IDB6 /2IDB8 IDEDB8 [13] IDEDB6 IDEDB8[13] IDEDB5 /2IDB5 /2IDB11 IDEDB11 [13] IDEDB5 IDEDB11[13] +3VS IDEDB4 /2IDB4 /2IDB9 IDEDB9 [13] IDEDB4 IDEDB9[13] JCDROM1 /2IDB10 IDEDB10 IDEDB10[13] R277 4.7K MICHRDYB 8P4R-10 CD-L CD-R [26] CD-L...

  • Page 95: Usb Port

    Schematic Diagrams USB Port 560K 470K OC0# OC0# USBVCC0 FCM2012V121 C309 C308 1.1A F1AJ3 0.1UF 10UF/10V L101 JCCD1 0.1UF -DATA3 -DATA3 FCM1608K121 L102 +DATA3 UV0- -DATA0 +DATA3 UV0- FCM1608K121 UV0+ +DATA0 CCD CON UV0+ NEAR CCD CON. C101 C100 R204 R217 C264 C259...

  • Page 96: Pcmcia Ti1410

    Schematic Diagrams PCMCIA TI1410 B_VCC C627 C619 C608 C602 C601 C644 C617 C632 C595 C646 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V 10UF/10V C618 C645 0.1UF 0.1UF JPCM1 B_VCC VPPD0 B_CD0 [20] VPPD0 VPPD1 B_CD1 [20] VPPD1 VCCD0# B_CD2 [20] VCCD0#...

  • Page 97: Pcmcia Power

    Schematic Diagrams PCMCIA Power +5VS C563 0.1UF JMDC1 +12V +3VS MONO_OUT AUDIO_PD PHONE PHONE [26] MONO_PHONE R431 AUXR B_VCC BVCC AUXL C588 10K(R) BVCC CDGND C590 C591 R423 BVCC CD_R 0.1UF CD_L 0.1UF 4.7U(0805) 8.2K(R) P_DN VDD3 3.3V AC_SYNC AC_SYNC [15,26] 3.3V SYNC AC_SDOUT...

  • Page 98: Phy Tsb41Lv01

    Schematic Diagrams 1394 PHY TSB41LV01 +3VS PHY3V BLM21P221SGPTM00-03 C573 C582 C583 C581 C586 C580 C585 C572 0.01UF 0.01UF 0.01UF 0.1UF 0.1UF 0.1UF 0.1UF 4.7U(0805) R170 6.34K_1% R176 PHY3V Z216 Z240 Sheet 21 of 35 R422 1K(R) VDD5 PHYISO# R439 4.7K PHY3V 1394 PHY ISO#...

  • Page 99: Lpc Si/O

    Schematic Diagrams LPC SI/O +3VS C530 C539 C529 0.1UF 0.1UF 0.1UF +3VS SA10 SA11 SA12 PD[0..7] PD[0..7] [23] +5VS SA13 +5VS LPC_AD[0..3] R228 [15,24] LPC_AD[0..3] SA14 SA15 LPC_AD0 LAD0 PD0/INDEX# SA16 LPC_AD1 LAD1 PD1/TRK0# FLASH# R227 LPC_AD2 LAD2 PD2/WP# BIOSCS# SA17 LPC_AD3 LAD3...

  • Page 100: Lpt/Com Port

    Schematic Diagrams LPT/COM Port VDD5 VDD3 C260 0.1UF R223 100K C247 PME# PME# [19,22,24,25] 0.1UF(K%) C246 C268 COM1RI 2N7002 C267 0.1UF(K%) 0.1UF(K%) JCOM1 1SS355 0.1UF(K%) R224 RN10 100K SOUTA [22] SOUTA T1IN T1OUT RTSA# [22] RTSA# T2IN T2OUT DTRA [22] DTRA T3IN T3OUT...
  • Page 101 Schematic Diagrams LPC H8 VDD5 R508 0(0805)(R) 3VH8 3VH8 R509 0(0805) VDD3 C212 4.7U(0805) 3VH8 1.1A 3VH8 C575 C255 0.1UF +5VS C570 HF50ACB321611T C571 0.1UF 0.1UF 0.1UF C569 C562 C561 C202 RP39 C9 0.1UF KB-SI3 0.1UF 0.1UF 0.1UF 10UF/10V JPS1 KB-SI2 KB-SI4 PS2_CLK2...

  • Page 102: Lan Rtl8100Bl

    Schematic Diagrams LAN RTL8100BL VCTRL LANVDD3 LANVCC25 LANVDD3 2SB1198K C431 C432 C404 C384 C403 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V 0.1UF 10UF/10V DE-COUPLE CAPS PLEASE CLOSE CHIP POWER PIN *For RTL8100C application, all bead must be rated 300mA/100ohm@100Mhz The maximum voltage drop when on should be less than 0.3V LANVDD3 C362 FCM2012V121...

  • Page 103: Audio Codec Alc201A

    Schematic Diagrams Audio Codec ALC201A For some crystal, FCM1608K-121 VDDA +3VS U18 78L05(SO8)(R) the bias resistor is needed VDDA R486 C613 C616 C637 C638 1M(R) C672 0.1UF R482 10UF/10V 0.1UF 10UF/10V 0(R) C665 C664 0.1UF(R) 0.1UF 4.7U(0805) AGND C642 LOUT-L LOUT-R 24.576MHz C615...

  • Page 104: Audio Out & Off Board Connectors

    Schematic Diagrams Audio Out & Off Board Connectors VDDA INTMIC R192 INTMIC 2.2K C225 JAUDIO3 0.1UF SPDIF OUT SPDIF C226 FCM1608K-121 SPDIF R191 C234 10UF/10V 2.2K BK1608HS330 JAUDIO2 AGND MIC IN Vrefout R190 2.2K(R) Vrefout MIC1 R196 FCM1608K-121 MIC1 C231 C232 C233 JAUDIO1...

  • Page 105: System Power Control

    Schematic Diagrams System Power Control U14B R462 U15B +12VS +12V U14C S3AUXSW# SUSB# 74LVC14 SUSB# [13,24] PSON# [15,29] PSON# U14D 74(A)HC08 R197 100K SI2301 74LVC14 SLP S3 C235 R523 4.7UF/25V PSON 74LVC14 PSON [33] 100K U14E PSON 2N7002 U15C U14F 74LVC14 S3AUXSW# SUSC# [24]...

  • Page 106: Fan Control And Speedstep

    Schematic Diagrams Fan Control and SpeedStep FAN_VCC +5VS FCM2012V121 MAIN FAN JFAN1 R409 R410 H_DPSLP# H_DPSLP# F01J2E 24.9K(R) FAN_SEN 4.7K(R) FAN_SEN R517 FI-S03P-HF +3VS 3904(R) FAN1-ON R367 1SS355 CPUSTP# FAN1-ON CPUSTP# 4,15 2SC4672 C522 2ND FAN 0.1UF JFAN2 C515 0.1UF(R) FAN2_SEN FAN2_SEN R524...

  • Page 107: Vcore

    Schematic Diagrams VCORE PR131 PR63 FCM1608K121 INTVCC SYS5V PC84 PC76 PC82 PC78 PC77 PR20 PR21 VR_PWRGD PC80 PC79 PC81 PC141 PC142 PC143 PC144 10U/25V 10U/25V 10U/25V 0.1U 0.1U 0.1U 10U/25V 0.1U 0.1U 0.1U 0.1U VID0 2,15 VID1 SENSE1- SENSE1+ PC18 1000PF RB751V RB751V...

  • Page 108: Ddr Power

    Schematic Diagrams DDR Power VDDP SYS5V PR96 PR95 PC113 1U PC52 1U PD16 RB751V PD17 PC106 RB751V PC34 0.1uF/25V 10U_1210 PC132 1000P PGOOD1 PGOOD2 PC133 1000P VCCA1 PQ21A FDS6982 VDDP1 VCCA2 2.5V PC49 PC107 PR93 PC33 ILIM1 TON1 0.1uF/25V PR103 20K 1% 10U_1210 PR105...

  • Page 109: System

    Schematic Diagrams System PR108 VIN1 PC57 PC56 0.1A 12VR 0.1U 10U/25V PC62 PC58 PC123 PC55 0.1U 10U/25V 0.1U PD18 PC54 PC119 10U/16V PD22 PC63 RB751V 0.1U 1U/50V_0805 11FS2 10U_1210 PD19 PC53 PQ43A 0.1U RB751V PC122 AO4900 BST3 0.1U VDD3 SYS3V PR86 PR109 PQ44A...

  • Page 110: Charger

    Schematic Diagrams Charger F1J3FTP PQ40 Si4435 2.5A 2.5A PC25 PC89 PC24 PR72 PD30 0.1U 10U_1210 0.1U PQ15 Si4435 PQ18 CDRH-1205-470 100m(2512) 03A04 DTA114EUA PC94 PC96 PR24 PD28 PC99 PC95 PC32 PC97 1N4148 10U/25V_DIP F1J3FTP 0.1U(0805) 0.1U(1206) 100K 10U/25V_DIP 10U/25V_DIP 0.1U(1206) PR75 PR73 PQ17...

  • Page 111: Sw Board And Hotkey

    Schematic Diagrams SW Board and HotKey VSW2 LID_SW#_10 VCN1 VIN_10 VIN_10 MPU-101-81 PWRS_10 PWRS_10 LID_SW#_10 LID_SW#_10 WEB0#_10 WEB0#_10 0.1U WEB1#_10 WEB1#_10 WEB2#_10 WEB2#_10 GND_L GND_L CON8 GND_L Hot keys,Power switch,key,Lid Sheet 34 of 35 SW Board and HotKey VIN_10 VSW1 PWRS_10 HCH STS-05-A 0.1U...

  • Page 112: Touchpad And Switch Board

    Schematic Diagrams TouchPad and Switch Board VCC5_T 10MIL VCC5_T VCN3 10MIL VCN2 TPADDATA TPADCLK TPADDATA TPADCLK 10MIL SW_UP TP_FFC4-R SW_DOWN SW_L 0.1U SW_R 120P 120P 120P 0(R) Sheet 35 of 35 plan GND_A GND_A TouchPad and Switch Board C178D83N C178D83N GND_A GND_A GND_A...

  • Page 113: Updating The Flash Rom Bios

    1. Using your web browser go to www.clevo.com.tw 2. Choose Download from the menu bar at the top of the page. 3. In the Driver section select the model of your computer (D400S/D410S Series) and the driver type (BIOS). 4. Select GO.

This manual is also suitable for:

D410s

Table of Contents
