Clevo D400F Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for Clevo D400F

Summary of Contents for Clevo D400F

  • Page 3 Preface Notebook Computer D400F/D410F Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.

  • Page 5: About This Manual

    This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the D400F/ D410F series notebook PC.

  • Page 6: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS When using any electrical equipment, basic safety precautions should always be followed to reduce the risk of fire, elec- tric shock and injury to persons, including the following: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel.

  • Page 10: Related Documents

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Mainboard Overview - Top (Key Parts) ......... 1-9 Mainboard Overview - Bottom (Key Parts) ......... 1-10 Overview ..................1-1 Mainboard Overview - Top (Connectors) ........1-11 System Specifications ......... 1-2 Mainboard Overview - Bottom (Connectors) ....... 1-12 Processor Types ................1-2 Disassembly ..........2-1 Core Logic ..................1-2...
  • Page 12 Combo Drive (D400F) ..............A-9 HDD/Combo Connector ...............B-18 DVD-ROM Drive (D400F) ............A-10 USB Port ..................B-19 Floppy Disk Drive (D400F) ............A-11 PCMCIA ENE1410 ..............B-20 Hard Disk Drive (D400F) ............A-12 PCMCIA Power & MDC Interface ..........B-21 Top (D410F) ................. A-13 1394 PHY TSB41LV01 ..............B-22...
  • Page 13 Preface VGA DDR DRAM Termination ..........B-35 Mobility M10-P POW ..............B-36 VCORE ..................B-37 +1.2V, +1.5V ................B-38 +2.5V, +1.25V, +1.8V ..............B-39 +3V, +5V, +12V ................B-40 Charger ..................B-41 SW Board and HotKey ..............B-42 TouchPad and Switch Board ............B-43...
  • Page 14 Preface...

  • Page 15: Introduction

    1: Introduction Overview This manual covers the information you need to service or upgrade the D400F/D410F series notebook computer. Infor- mation about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.

  • Page 16: System Specifications

    Introduction System Specifications Feature Specification Processor Types Intel Pentium® 4 Processor (478-pin) FC-PGA2 Package µ 0.13) 0.13 Micron Process Technology, 512KB On-die L2 Cache & 800MHz Front Side Bus - 2.26 ~ 3.2 GHz Intel Pentium® 4 Processor (478-pin) FC-PGA2 Package µ...

  • Page 17: Pc Card

    Introduction Feature Specification PC Card One Type II PCMCIA 3.3V/5V socket supporting CardBus Keyboard “WinKey” keyboard Pointing Device Built-in TouchPad (scrolling key functionality integrated) Audio AC'97 2.2 compliant interface Built-in microphone 3D stereo enhanced sound system 2 Built-in speakers Sound-Blaster PRO™ Compatible S/PDIF Digital output (5.1 CH) Interface Two USB 2.0/1.1 ports...

  • Page 18: Design Differences

    Introduction Feature Specification Environmental Spec Temperature Relative Humidity ° ° Operating: C ~ 35 20% ~ 80% Non-Operating: -20°C ~ 60°C 10% ~ 90% Physical Dimensions 329 (w) x 275 (d) x 36.5 (h) mm Weight Around 2.8 kg (depend on optional modules included) without battery Optional DVD-ROM drive module Software DVD player...

  • Page 19: External Locator - Top View

    Introduction External Locator - Top View Figure 2 Top View 1. Optional Built-in PC Camera 2. LCD 3. Built-In Microphone 4. LED Power & Communication Indicators 5. LED Status Indicators 6. AP-Key buttons 7. Close Cover/Lid Switch 8. Power Button 9.

  • Page 20: External Locator - Front & Left Side Views

    Introduction External Locator - Front & Left Side Views Figure 3 Front View 1. LCD Latches 2. Mini IEEE 1394 Port 3. S/P DIF Out Port 4. Microphone Jack 5. Headphone Jack 6. Infrared Transceiver 7. Wireless Device ON/OFF Switch 8.

  • Page 21: External Locator - Right Side & Rear Views

    Introduction External Locator - Right Side & Rear Views Figure 5 Right Side View 1. Security Lock Slot Figure 6 Rear View 9 10 1. Vent 2. DC-In Jack 3. 2 * USB 2.0/1.1 Ports 4. External Monitor (CRT) Port 5.

  • Page 22: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 7 Bottom View 1. Vent/Fan Intake 2. Battery Cover 3. Hard Disk Cover 4. Bluetooth Module Cover 5. CPU, Heatsink, DDR, Wireless LAN Cover Note : The RAM and optional Wireless LAN module are lo- cated under the CPU Heatsink Cover.

  • Page 23: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 8 Mainboard Top Key Parts 1. PC Card Assembly 2. Northbridge - SiS 661FX 3. Southbridge - SiS 4. LAN RTL 8100C Mainboard Overview - Top (Key Parts) 1 - 9...

  • Page 24: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 9 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Memory Slots (no memory installed) 3. CardBus ENE 1410 4. ALC650 - Audio Codec 5. LPC - H8 6. LPC Super I/O NS PC87393 7.

  • Page 25: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 10 Mainboard Top Connectors 1. Modem Cable Connector (CN1) 2. LCD (and Inverter) Connector (LCD1) 3. Video Camera Cable Connector (JCCD1) 4. Power Switch Board Cable Connector (JSW1) 5. TouchPad Cable Connector (JTP1) 6.

  • Page 26: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 11 Mainboard Bottom Connectors 1. Wireless LAN Connector (JWL1) 2. DDR Fan Cable Connector (JFAN4) 3. CD-ROM Device Connector (JCDROM1) 4. Hard Disk Cable Connector (JHDD1) 5. Bluetooth Module Connector (JBT1) 6. CMOS Battery Cable Connector (JBAT1) 7.

  • Page 27: Disassembly

    2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the D400F/D410F series notebook’s parts and sub- systems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 28: Maintenance Tools

    Disassembly NOTE : All disassembly procedures assume that the system is turned OFF , and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 29: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 30: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Processor: 1. Remove the battery page 2 - 8 1.
  • Page 31 Disassembly To remove the TouchPad and Click Board: To remove the Modem: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.
  • Page 32 Disassembly To remove the Mainboard: To remove the Card Reader Assembly: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.
  • Page 33 Disassembly To remove the LCD Front Panel Module: To remove the PC Video Camera Module: 1. Remove the battery page 2 - 8 1. Remove the battery page 2 - 8 2. Remove the HDD page 2 - 9 2. Remove the HDD page 2 - 9 3.

  • Page 34: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. 2. Remove screws & (Figure 1a) from the battery cover , and remove the cover. 3. Carefully (use a small screwdriver) disconnect the battery cable at point (Figure 4.

  • Page 35: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual ) when setting up a new hard disk.

  • Page 36: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting DDR 333/400 MHz. The main memory can be expanded up to 1024MB. The SO-DIMM modules supported are 128Mb, Heat Sink Unit 256Mb, and 512Mb.
  • Page 37 Disassembly 5. Gently pull the two release latches ( & on the sides of the memory socket toward the sides of the computer. Figure 4 Removing/ Installing a RAM Module a. Pull release latches. b.Remove the module. 6. The module (Figure 4b) will pop-up, and you can remove it.

  • Page 38: Removing The Optical Device

    Disassembly Removing the Optical Device The easy changeable optical device may be upgraded or changed. 1. Turn off the computer, and remove the battery ( page 2 - 8 2. Remove screws (Figure 5a) from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- nect it).
  • Page 39 Disassembly 4. Use a screwdriver to carefully push the CD device assembly out of the computer at point Figure 6 CD Device Removal Push the CD device out off the computer at point 5. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The screw holes should line up.

  • Page 40: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module page 2 - 8 1. Turn off the computer, and remove the battery ( 2. Remove screws from the Bluetooth module cover 3. Carefully lift up the Bluetooth module cover off the computer. 4. Remove screws and carefully disconnect cables then remove the Bluetooth module Figure 7...

  • Page 41: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module page 2 - 8 1. Turn off the computer, and remove the battery ( 2. Remove screws from the memory socket cover Figure 8 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- Wireless LAN nect it).

  • Page 42: Removing The Processor

    Disassembly Removing the Processor page 2 - 8 1. Turn off the computer, and remove the battery ( 2. Remove screws from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- Figure 9 nect it).
  • Page 43 Disassembly & 6. Remove screws and lift the CPU holder off the computer. 7. Unlock the processor by raising lever 8. Lift the CPU off the computer. Figure 10 Processor Removal (cont’d) a. Remove the screws and lift the CPU holder off the computer.

  • Page 44: Removing The Keyboard

    Disassembly Removing the Keyboard page 2 - 8 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you may need to use a small screwdriver to do this).

  • Page 45: Removing The Keyboard Shielding Plate

    Disassembly Removing the Keyboard Shielding Plate page 2 - 8 page 2 - 18 1. Turn off the computer, remove the battery ( ) and keyboard ( 2. Remove screws from the keyboard shielding plate and lift the plate off the computer. Figure 12 Keyboard Shielding Plate Removal...

  • Page 46: Removing The Lcd And Top Case

    Disassembly Removing the LCD and Top Case page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...
  • Page 47 Disassembly 5. Slide the LCD hinge covers out of the computer. 6. Remove screws then carefully (pay careful attention to the antenna cables) lift the LCD assembly the computer. & & 7. Remove screws and disconnect cables , then lift the top case assembly off the computer.

  • Page 48: Removing The Touchpad And Click Board

    Disassembly Removing the TouchPad and Click Board page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 49: Removing The Led Board

    Disassembly Removing the LED Board page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 50: Removing The Modem

    Disassembly Removing the Modem page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 51: Removing The Speakers

    Disassembly Removing the Speakers page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 52: Removing The Mainboard

    Disassembly Removing the Mainboard page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 53: Removing The Fan Unit

    Disassembly Removing the Fan Unit page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 54: Removing The Card Reader Assembly

    Disassembly Removing the Card Reader Assembly page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 55: Removing The Pcmcia Assembly

    Disassembly Removing the PCMCIA Assembly page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 56: Removing The Lcd Front Panel Module

    Disassembly Removing the LCD Front Panel Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 57: Removing The Inverter

    Disassembly Removing the Inverter page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...

  • Page 58: Removing The Pc Video Camera Module

    Disassembly Removing the PC Video Camera Module page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14...

  • Page 59: Removing The Lcd Panel

    Disassembly Removing the LCD Panel page 2 - 8 page 2 - 9 page 2 - 10 page 1. Turn off the computer, remove the battery ( ), hard disk ( ), RAM ( ), CD Device ( 2 - 12 ), Bluetooth module ( page 2 - 14 ), Wireless LAN module (...
  • Page 60 Disassembly 2 - 34...

  • Page 61: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the D400F/D410F series notebook’s construction into a series of illustrations. The compo- nent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 62: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table 1 - 1 Part List Illustration Part D400F D410F Location page A - 3 page A - 13 page A - 4...

  • Page 63: Top (D400F

    Part Lists Top (D400F) Figure 1 Top (D400F) Top (D400F) A - 3...

  • Page 64: Bottom (D400F

    Part Lists Bottom (D400F) 無鉛 Figure 2 Bottom (D400F) 無鉛 A - 4 Bottom (D400F)

  • Page 65: Lcd 14" (D400F

    Part Lists LCD 14" (D400F) Figure 3 LCD 14" (D400F) LCD 14" (D400F) A - 5...

  • Page 66: Lcd 15" (D400F

    Part Lists LCD 15" (D400F) Figure 4 LCD 15" (D400F) A - 6 LCD 15" (D400F)

  • Page 67: Cd-Rom Drive (D400F

    Part Lists CD-ROM Drive (D400F) Figure 5 CD-ROM Drive (D400F) CD-ROM Drive (D400F) A - 7...

  • Page 68: Cd-Rw Drive (D400F

    Part Lists CD-RW Drive (D400F) Figure 6 CD-RW Drive (D400F) A - 8 CD-RW Drive (D400F)

  • Page 69: Combo Drive (D400F

    Part Lists Combo Drive (D400F) Figure 7 Combo Drive (D400F) Combo Drive (D400F) A - 9...

  • Page 70: Dvd-Rom Drive (D400F

    Part Lists DVD-ROM Drive (D400F) Figure 8 DVD-ROM Drive (D400F) A - 10 DVD-ROM Drive (D400F)

  • Page 71: Floppy Disk Drive (D400F

    Part Lists Floppy Disk Drive (D400F) Figure 9 Floppy Disk Drive (D400F) Floppy Disk Drive (D400F) A - 11...

  • Page 72: Hard Disk Drive (D400F

    Part Lists Hard Disk Drive (D400F) Figure 10 HDD Drive (D400F) A - 12 Hard Disk Drive (D400F)

  • Page 73: Top (D410F

    Part Lists Top (D410F) Figure 11 Top (D410F) Top (D410F) A - 13...

  • Page 74: Bottom (D410F

    Part Lists Bottom (D410F) Figure 12 無鉛 Bottom (D410F) 無鉛 A - 14 Bottom (D410F)

  • Page 75: Lcd 14" (D410F

    Part Lists LCD 14" (D410F) Figure 13 LCD 14" (D410F) LCD 14" (D410F) A - 15...

  • Page 76: Lcd 15" (D410F

    Part Lists LCD 15" (D410F) Figure 14 LCD 15" (D410F) A - 16 LCD 15" (D410F)

  • Page 77: Cd-Rom Drive (D410F

    Part Lists CD-ROM Drive (D410F) Figure 15 CD-ROM Drive (D410F) CD-ROM Drive (D410F) A - 17...

  • Page 78: Cd-Rw Drive (D410F

    Part Lists CD-RW Drive (D410F) Figure 16 CD-RW Drive (D410F) A - 18 CD-RW Drive (D410F)

  • Page 79: Combo Drive (D410F

    Part Lists Combo Drive (D410F) Figure 17 Combo Drive (D410F) Combo Drive (D410F) A - 19...

  • Page 80: Dvd-Rom Drive (D410F

    Part Lists DVD-ROM Drive (D410F) Figure 18 DVD-ROM Drive (D410F) A - 20 DVD-ROM Drive (D410F)

  • Page 81: Floppy Disk Drive (D410F

    Part Lists Floppy Disk Drive (D410F) Figure 19 Floppy Disk Drive (D410F) Floppy Disk Drive (D410F) A - 21...

  • Page 82: Hard Disk Drive (D410F

    Part Lists Hard Disk Drive (D410F) Figure 20 HDD Drive (D410F) A - 22 Hard Disk Drive (D410F)

  • Page 83: Schematic Diagrams

    Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the D400F/D410F notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table 1 Diagram - Page Diagram - Page Diagram - Page Schematic System Block Diagram - Page B - 2...

  • Page 84: System Block Diagram

    Schematic Diagrams System Block Diagram TV-OUT NORTHWOOD CLOCK ATI M10P & GENERATOR PRESCOTT SOCKET - 478 PANEL 2/16/32 2/16/32 Host Bus DDRAM DDRAM DDR INTERFACE SiS 648FX TV-OUT ( SiS 302LV ) PAGE 10 VB-LINK 839 mBGA Sheet 1 of 42 PANEL CRT PORT System Block...
  • Page 85 Schematic Diagrams Socket 478 1 of 2 HD#[0..63] HD#[0..63] 5 VCC_CORE VIDPWRGD VIDPWRGD38 JCPU1A HA#[3..31] HD#0 HA#[3..31] HD#1 HD#2 HD#3 HA#31 HD#4 HA#30 HD#5 HA#29 HD#6 HA#28 HD#7 HA#27 HD#8 HA#26 HD#9 HA#25 HD#10 HA#24 HD#11 HA#23 HD#12 HA#22 HD#13 HA#21 HD#14 HA#20...
  • Page 86 Schematic Diagrams Socket 478 & ITP 2 of 2 VCC_CORE CPUGTLVREFA 49.9_1% R324 CPUGTLVREFB R400 49.9_1% C338 C336 C415 R323 C399 C405 C492 R401 220P 220P 100_1% 220P 220P 100_1% CPU SIGNAL TERMINALION VCC_CORE VCC_CORE CLOSE TO CPU JCPU1B FERR# R368 4.7uH_SMD_30% 62_1%...
  • Page 87 Schematic Diagrams Clock Generator Main Clock Generator Damping Resistors Place near to the +3VS Clock Outputs By-Pass Capacitors Place near to the Clock FCM2012V121 CLOCK GEN (660) Outputs CLK_VCC3 VDDREF CPU-1 RP37 HCLK-CPU HCLK-CPU R395 49.9_1% VDDZ CPUCLK0 HCLK-CPU 3 CPU-2 C504 C505...

  • Page 88: M648Fx-1 (Host/Agp) 1 Of 4

    Schematic Diagrams M648FX-1 (Host/AGP) 1 of 4 AAD18/AHSYNC 22(R) AAD30/BHSYNC 22(R) AAD18/AHSYNC VAHSYNC 10 AAD30/BHSYNC VBHSYNC 10 22(R) AAD17/AVSYNC AAD31/BVSYNC 22(R) AAD17/AVSYNC VAVSYNC 10 AAD31/BVSYNC VBVSYNC 10 AAD16/VADE AAD16/VADE 10,30 AAD27/VBDE AAD27/VBDE 10,30 HNCOMP R313 20_1% 22(R) VBCLK AAD28/VBCTL0 AAD28/VBCTL0 10,30 Rds-on(n) = 10 ohm AAD29/VBCTL1...

  • Page 89: M648Fx-2 (Memory For Ddr) 2 Of 4

    Schematic Diagrams M648FX-2 (Memory for DDR) 2 of 4 /RMD[0..63] /RMD[0..63] 7,8 /RDQM[0..7] /RDQM[0..7] 7,8 /RDQS[0..7] /RDQS[0..7] 7,8 /RMA[0..14] /RMA[0..14] 7,8 /RCS#[0..5] /RCS#[0..5] 7,8 CKE[0..5] CKE[0..5] 7 Rs place close to DIMM1 0402 Package BGA1B +2.5V /RMD4 RP38 AN35 /RMD5 8P4R-10 AP36 DQM0...

  • Page 90: M648Fx-3 & Crt Out 3 Of

    Schematic Diagrams M648FX-3 & CRT Out 3 of 4 BGA1C NOTE: This page is for universal PCB design( suitable for both 645 or 650) ZCLK0 ZCLK0 ZCLK REFCLK0 REFCLK0 4 ZUREQ VOSCI NB Hardware Trap Table ZUREQ ZUREQ ZDREQ ZDREQ ZDREQ embedded pull-low ROUT...

  • Page 91: M648Fx-4 (Power) 4

    Schematic Diagrams M648FX-4 (Power) 4 of 4 IVDD L124 FH50ACB321611T(R) C479 0.1UF +1.5VS +3VS +1.8VS 80 mil +1.8VS L123 FH50ACB321611T +1.8VS C529 0.1UF AUX_IVDD +1.8VS +1.8VS SUPPORT M660 BGA1D L126 0(R) +1.5V AB12 L127 10U(0805) 0.1UF AUX_IVDD +1.8V +1.8VS AC12 C456 AUX3.3 IVDD...

  • Page 92: Ddr Memory Dimm

    Schematic Diagrams DDR Memory DIMM +2.5V /RMA0 /RMD0 /RMA0 +2.5V /RMA1 /RMD1 /RMA1 /RMA2 /RMD2 /RMA2 RP18 /RMA3 /RMD3 /RMA3 CKE4 /RMA4 /RMD4 /RMA4 CKE2 /RMA5 /RMD5 /RMA5 CKE3 /RMA6 /RMD6 /RMA6 CKE5 /RMA7 /RMD7 /RMA7 /RMA8 /RMD8 /RMA8 8P4R-470(0402) /RMA9 /RMD9 /RMA9...

  • Page 93: Ddr Sstl-2 Termination

    Schematic Diagrams DDR SSTL-2 Termination SSTL-2 Termination Resistors MD/DQM(/DQS) SSTL-2 MA/Control SSTL-2 SSTL-2 OD 2.5V /RMD[0..63] /RMD[0..63]6,7 /RDQM[0..7] /RDQM[0..7]6,7 +1.25VS +1.25VS /RDQS[0..7] /RDQS[0..7]6,7 0402 Package /RMA[0..14] 0402 Package /RMA[0..14] 6,7 /RCS#[0..5] /RCS#[0..5] 6,7 /RMA2 /RMD0 /RMD1 /RMA0 /RMA12 /RDQS0 /RMD2 /RSRAS# /RSRAS# RP52...

  • Page 94: Lvds Interface (Sis302Lv

    Schematic Diagrams LVDS Interface (SiS302LV) C272 33PF(R) +3VS LVDD1 FCM1608K121(R) R259 C386 C385 FCM1608K-121T07 JTV2 10U/10V(R) 0.1UF 0.1UF LGND 2.7UH DA204U(R) DA204U(R) R260 C275 33PF(R) R252 C297 C273 C300 C276 330PF 330PF +3VS 330PF 330PF L100 SVIDEO CON LVDD2 PIN(GND1,GND2)=GND FCM1608K121(R) +3VS C348...

  • Page 95: Panel Con & Led Indicator

    Schematic Diagrams Panel Con & LED Indicator LCDVCC LCDVCC FCM2012V-121 FCM2012V-121 +3VS C350 C311 60 mil LCDVCC 4800 JLCD1 0.1UF 0.1UF +3VS TXOUT-LN0 TXOUT-UN0 C352 C351 TXOUT-LP0 TXOUT-UP0 R288 4.7U(0805) 0.1UF TXOUT-LN1 TXOUT-UN1 C330 C331 TXOUT-LP1 TXOUT-UP1 R287 0.1UF 4.7U(0805) Z245 TXOUT-LN2 TXOUT-UN2...

  • Page 96: Pci/Ide/Hyperzip) 1

    Schematic Diagrams 963-1 (PCI/IDE/HyperZip) 1 of 4 AD[0..31] IDESAA[0..2] 19,20,25 AD[0..31] IDESAA[0..2] IDECS#A[0..1] IDECS#A[0..1] IDESAB[0..2] IDESAB[0..2] +1.8VS IDECS#B[0..1] IDECS#B[0..1] R519 BGA5A C191 C699 +3VS 0.01UF 0.1UF IDEAVDD REQ4# PREQ4# IDEAVSS REQ3# PREQ3# RP32 REQ2# ICHRDYA REQ2# ICHRDYA 14 FRAME# REQ1# PREQ2# ICHRDYA IDEREQA...

  • Page 97: Misc Signals) 2

    Schematic Diagrams 963-2 (Misc Signals) 2 of 4 Programable on-die pull-high strength for CPU_S: BGA5B ( Infinite, 150, 110, 56 Ohm) R166 4.7K OSC25MHI NEED NOT to place INIT# close to 96X +3VS INIT# INIT# OSC25MHO A20M# A20M# A20M# RN97 SMI# SMI# SMI#...
  • Page 98 Schematic Diagrams 963-3 (USB I/F) 3 of 4 BGA5C 1394_EECS GPIO24/EECS 1394_MA0/EEDO UCLK48M UCLK48M4 GPIO23/EEDO USBCLK48M 1394_MA1/EEDI GPIO22/EEDI 1394_MA2/EESK +DATA0 +DATA0 GPIO21/EESK UV0+ -DATA0 UV0- -DATA0 +DATA1 +DATA1 UV1+ -DATA1 -DATA1 UV1- +DATA2 PHY_LPS PHY_LPS +DATA2 PHY_REQ UV2+ -DATA2 PHY_REQ -DATA2 LREQ UV2-...

  • Page 99: Power & Rtc) 4

    Schematic Diagrams 963-4 (Power & RTC) 4 of 4 +1.8VS +1.8V +3VS C686 C687 C417 C499 C710 C650 C663 C678 C682 C711 C645 C653 C651 C679 C652 C661 0.1UF 0.1UF 10UF/10V 10UF/10V 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V +1.8VS BGA5D VDDZ...

  • Page 100: Hdd/Combo Connector

    Schematic Diagrams HDD/Combo Connector JCDROM1 CD-L CD-R CD-L CD-R 26 CDGND CDGND IDERST# IDEDB8 IDEDB813 IDEDB7 IDEDB9 IDEDB7 IDEDB913 IDEDB6 IDEDB10 IDEDB6 IDEDB1013 +3VS IDEDB5 IDEDB11 IDEDB5 IDEDB1113 IDEDB4 IDEDB12 R506 IDEDB4 IDEDB1213 4.7K IDEDB3 IDEDB13 CBLIDB13 IDEDB3 IDEDB1313 IDEDB2 IDEDB14 IDEDB2 IDEDB1413...

  • Page 101: Usb Port

    Schematic Diagrams USB Port 560K OC0# OC0# USBVCC0 USBVCC0 FCM2012V121 10UF/10V 0.1UF C345 C317 0.1UF -DATA0 JCCD1 -DATA0 -DATA3 -DATA3 +DATA0 FCM1608K121 +DATA0 +DATA3 +DATA3 FCM1608K121 CCD CON NEAR CCD CON. C347 C346 47P(R) JUSB2 47P(R) USB-PLUG V+_OUT1 DATA_L1 DATA_H1 R255 560K PLW3216S161SQ2...

  • Page 102: Pcmcia Ene1410

    Schematic Diagrams PCMCIA ENE1410 B_VCC C811 C810 C789 C781 C780 C837 C802 C822 C779 C853 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V 10UF/10V C809 C852 0.1UF 0.1UF JPCM1 B_VCC VPPD0 B_CD0 VPPD0 VPPD1 B_CD1 VPPD1 VCCD0# B_CD2 VCCD0# VCCD1# B_CD3 C235...

  • Page 103: Pcmcia Power & Mdc Interface

    Schematic Diagrams PCMCIA Power & MDC Interface C756 0.1UF JMDC1 +12V +3VS MONO_OUT AUDIO_PD PHONE MONO_PHONE PHONE AUXR B_VCC BVCC AUXL C765 BVCC CDGND C767 C768 R568 BVCC CD_R 0.1UF CD_L 0.1UF 4.7U(0805) 8.2K(R) P_DN VDD3 3.3V AC_SYNC AC_SYNC 15,26 3.3V SYNC AC_SDOUT...

  • Page 104: 1394 Phy Tsb41Lv01

    Schematic Diagrams 1394 PHY TSB41LV01 L145 BLM21P221SGPTM00-03 PHY3V L146 BLM21P221SGPTM00-03(R) +3VS C864 C872 C880 C889 C877 C878 C869 C873 0.01UF 0.01UF 0.01UF 0.1UF 0.1UF 0.1UF 0.1UF 4.7U(0805) R709 6.34K_1% Sheet 21 of 42 R708 1394 PHY PHY3V Z216 Z240 TSB41LV01 R696 1K(R) VDD5...

  • Page 105: Lpc Super I/O

    Schematic Diagrams LPC Super I/O +3VS C760 C754 C752 0.1UF 0.1UF 0.1UF +3VS SA10 SA11 SA12 PD[0..7] PD[0..7] 23 +5VS SA13 +5VS LPC_AD[0..3] R585 15,24 LPC_AD[0..3] SA14 SA15 LPC_AD0 LAD0 PD0/INDEX# SA16 LPC_AD1 LAD1 PD1/TRK0# FLASH# R591 LPC_AD2 LAD2 PD2/WP# BIOSCS# SA17 LPC_AD3...

  • Page 106: Lpt/Com Port

    Schematic Diagrams LPT/COM Port R724 0(R) VDD5 VDD3 C285 R725 0.1UF R285 100K PME# C270 PME# 19,22,24,25 0.1UF(K%) C307 C269 COM1RI 2N7002 C306 0.1UF(K%) 0.1UF(K%) JCOM1 1SS355 0.1UF(K%) R286 RN49 100K SOUTA SOUTA RTSA# T1IN T1OUT RTSA# T2IN T2OUT DTRA DTRA T3IN T3OUT...
  • Page 107 Schematic Diagrams LPC H8 VDD5 R651 0(0805)(R) 3VH8 3VH8 R650 0(0805) VDD3 C813 3VH8 4.7U(0805) C281 0.1UF +5VS C814 3VH8 1.1A F1AJ3 FH50ACB321611T C812 C804 C303 0.1UF 0.1UF RP70 0.1UF 0.1UF C838 C783 C782 C773 JPS1 KB-SI3 0.1UF 0.1UF 0.1UF 10UF/10V KB-SI2 KB-SI4...

  • Page 108: Lan Rtl8110S(B)-32/Rtl8100C

    Schematic Diagrams LAN RTL8110S(B)-32/RTL8100C LANVDD3 L120 LAN_DVDD BK2125HS121 C394 C395 BK2125HS121(R) 0.1U +2.5V BK2125HS121 10U/10V(0805) LANVCC1.8 JLAN1 C353 C274 C302 C299 C312 C271 RING 10U(0805) 0.1U FCM1608K121 RING 10U(0805) 0.1U 0.1U 0.1U 0.1U FCM1608K121 MDC 2P PLW3216S161SQ2 LAN_AVDDL MDI0+ MDI0- TD4- MX4- V_DAC...

  • Page 109: Audio Codec Alc650

    Schematic Diagrams Audio Codec ALC650 L143 FCM1608K-121 VDDA +3VS For some crystal, the bias resistor is needed R642 C906 C907 C798 C801 C831 C836 1M(R) 0.1UF 0.1UF R630 10UF/10V 10UF/10V 10UF/10V 10UF/10V L148 FCM2012V121(R) 0(R) AGND LOUT-L C833 60 mil 60 mil LOUT-R 24.576MHz...

  • Page 110: Audio Out & Off Board Connectors

    Schematic Diagrams Audio Out & Off Board Connectors VDDA JAUDIO3 R237 INTMIC AUDIO_JACK INTMIC 2.2K(R) C250 SPDIF/LINE-R FCM1608K-121 SPDIF OUT SPDIF/LINE-R SPDIF/LINE-L 0.1UF FCM1608K-121 SPDIF/LINE-L C243 C248 C249 10UF/10V(R) R236 2.2K(R) 680P 680P JAUDIO2 BK1608HS330 AUDIO_JACK AGND Vrefout R235 2.2K R238 FCM1608K-121 MIC IN...

  • Page 111: System Power Control

    Schematic Diagrams System Power Control +2.5V +2.5VS 4800 U10B R589 U11B +12V U10C S3AUXSW# SUSB# 74LVC14 C758 SUSB# 13,24 PSON# R204 R203 15,29 PSON# U10D 10UF/10V 100K 74(A)HC08 330K C222 SLP S3 74LVC14 0.1UF PSON PSON# 74LVC14 PSON 29,40 2N7002 U10E U11C U10F...

  • Page 112: Fan Control And Speedstep

    Schematic Diagrams Fan Control and SpeedStep L135 FAN_VCC FCM2012V121 MAIN FAN C698 100U/16V DIP R546 JFAN2 24.9K H_DPSLP# H_DPSLP# 2,36 R545 F01J2E 4.7K FAN_SEN FAN_SEN R516 FI-S03P-HF 3904 CPUSTP# C706 CPUSTP# 4,15 FAN1-ON R509 1SS355 FAN1-ON 0.1UF 2SD1834 C660 0.1UF(R) R209 4.7K FAN_VCC_3...

  • Page 113: Mobility M10-P

    Schematic Diagrams Mobility M10-P AAD[0..15] +3VS 5,10 AAD[0..15] BGA2A AAD0 R113 AAD1 GPIO0 Part 1 of 6 R116 AAD2 GPIO1 AAD16/VADE AAD3 GPIO2 5,10 AAD16/VADE AAD17/AVSYNC AAD4 GPIO3 R114 R333 8.2K(R) R354 8.2K(R) AAD17/AVSYNC GPIO4 AAD18/AHSYNC AAD5 +3VS R474 AAD18/AHSYNC GPIO5 AAD27/VBDE AAD6...

  • Page 114: Mobility M10-P Mem A/B

    Schematic Diagrams Mobility M10-P MEM A/B DMAB[0..13] DMAB[0..13] DMAA[0..13] DMAA[0..13] OPTIONAL SERIES OPTIONAL SERIES TERMINATION TERMINATION FOR MEMORY FOR MEMORY ADDR & CNTRL ADDR & CNTRL INSTALL INSTALL RESISTORS RESISTORS MEMORY CHANNEL A CLOSER TO MEMORY CHANNEL B CLOSER TO DQMA#[7..0] DQMB#[7..0] DQMA#[7..0]...

  • Page 115: Vga Ddr Dram Channel A

    Schematic Diagrams VGA DDR DRAM Channel A +2.5V_MEM +1.25VS +2.5V_MEM MDA0 RN56 C465 0.1U MDA1 MDA2 MDA3 8P4R_56(0402) BGA6 BGA7 MDA5 RN57 0.1U 470P MDA4 56(0402) 56(0402) QSA0 DQMA#0 8P4R_56(0402) MEM_MAA0 MEM_CLKA0 MDA12 MEM_MAA1 MEM_CLKA0# MDA11 MEM_MAA2 MEM_CLKA1 DQMA#1 MEM_MAA3 MEM_CLKA1# QSA1 8P4R_56(0402)

  • Page 116: Vga Ddr Dram Channel B

    Schematic Diagrams VGA DDR DRAM Channel B +2.5V_MEM +1.25VS +2.5V_MEM C150 MDB6 RN87 C623 0.1U 470P MDB2 R128 56(0402) R127 56(0402) MDB7 MDB0 8P4R_56(0402) C131 BGA3 BGA4 MEM_CLKB0 DQMB#0 RN86 0.1U MDB5 MEM_CLKB0# MEM_CLKB1 MDB1 MEM_CLKB1# QSB0 8P4R_56(0402) MEM_MAB0 MDB8 C638 0.1U MEM_MAB1 R507...

  • Page 117: Vga Ddr Dram Termination

    Schematic Diagrams VGA DDR DRAM Termination MDB[63..0] 31,33 MDB[63..0] MEM_MDB[63..0] Close to memory device MEM_MDB[63..0] MDA[63..0] Close to memory device 31,32 MDA[63..0] MDB0 RN36 8P4R-10(0402) MEM_MDB0 MEM_MDA[63..0] MDB2 MEM_MDB2 MDA0 RN55 8P4R-10(0402) MEM_MDA0 MDB1 MEM_MDB1 MDA2 MEM_MDA2 MDB3 MEM_MDB3 MDA1 MEM_MDA1 MDB4 RN37...

  • Page 118: Mobility M10-P Pow

    Schematic Diagrams Mobility M10-P POW BGA2F VDDC Part 6 of 6 VDDC 655mA BGA2D +3VS DIODE SUPPLIES POWER VDDC +2.5V_MEM VDDR1 TO VDDC RAIL VDDC Part 4 of 6 VDDR1(CLKBFB) WHEN VDDC IS OFF AND +3.3V IS ON VDDC VDDR1 VDDC C655 C583...

  • Page 119: Vcore

    Schematic Diagrams VCORE VCC5_DRV VCC5_DRV PD22 FS1J3 TEST_C H_DPSLP# VCC_CORE PC108 PD23 0.47U/25V(0805) PR13 PR14 PR15 AUX3 AUX1 AUX2 40.2K 1% 40.2K 1% 40.2K 1% RB751V PR69 PC21 PC25 10U/25V PC97 CPU_PSC_HI PR11 15nF 301 1% PC107 PR66 PC22 PC20 10U/25V PC117 PC116...

  • Page 120: V, +1.5V

    Schematic Diagrams +1.2V, +1.5V SYS5V PR41 PR42 PC154 PC50 RB751V PD15 RB751V PC56 PC55 0.1uF/25V 10U_1210 PC158 1000P PGOOD1 PGOOD2 PC142 1000P VDDP1 VCCA1 PC156 PC53 VDDP2 VCCA2 PC49 PC54 0.1uF/25V PQ26 PR35 10U_1210 Sheet 37 of 42 TON1 1.5V IRF7811AV PR135 ILIM1...

  • Page 121: V, +1.25V, +1.8V

    Schematic Diagrams +2.5V, +1.25V, +1.8V VDDP SYS5V PR129 PR130 PC57 PC67 PD36 RB751V PD37 RB751V PC41 PC45 PC40 0.1uF/25V 10U_1210 10U_1210 PC165 1000P PGOOD1 PGOOD2 PC58 1000P VCCA1 PQ17 IRF7811AV VDDP1 VCCA2 2.5V PC64 PC145 PR133 PC44 ILIM1 TON1 0.1uF/25V 2.0UH PR139 20K 1%...

  • Page 122: 5V, +12V

    Schematic Diagrams +3V, +5V, +12V PR160 VIN1 PC78 PC76 0.1A 12VR 0.1U 10U/25V PC83 PC82 PC175 PC74 0.1U 10U/25V 0.1U PD16 PC73 PC168 10U/16V PD21 PC84 RB751V 0.1U 1U/50V_0805 11FS2 10U_1210 PC72 PD17 PQ59A 0.1U RB751V PC174 AO4900 BST3 0.1U VDD3 SYS3V PR116...

  • Page 123: Charger

    Schematic Diagrams Charger F1J3FTP PQ54 2.5A 2.5A Si4435 PC32 PC125 PC31 PR100 PD30 0.1U 10U_1210 0.1U PQ13 Si4435 PQ19 CDRH-1205-470 100m(2512) 03A04 DTA114EUA PC129 PC137 PC136 PR27 PD28 PC138 PC134 PC42 1N4148 10U/25V_DIP F1J3FTP 0.1U(0805) 0.1U(1206) 100K 100U/25V_DIP 100U/25V_DIP 0.1U(1206) PR105 PR101 PQ18...

  • Page 124: Sw Board And Hotkey

    Schematic Diagrams SW Board and HotKey VSW2 LID_SW#_10 VCN1 VIN_10 VIN_10 MPU-101-81 PWRS_10 PWRS_10 LID_SW#_10 LID_SW#_10 WEB0#_10 WEB0#_10 0.1U WEB1#_10 WEB1#_10 WEB2#_10 WEB2#_10 Sheet 41 of 42 GND_L GND_L CON8 SW Board and HotKey GND_L Hot keys,Power switch,key,Lid VIN_10 VSW1 PWRS_10 HCH STS-05-A 0.1U...

  • Page 125: Touchpad And Switch Board

    Schematic Diagrams TouchPad and Switch Board VCC5_T 10MIL VCC5_T VCN3 10MIL VCN2 TPADDATA TPADCLK TPADDATA TPADCLK 10MIL SW_UP TP_FFC4-R SW_DOWN SW_L 0.1U SW_R 120P Sheet 42 of 42 120P 120P 0(R) plan TouchPad and GND_A GND_A Switch Board C178D83N C178D83N GND_A GND_A GND_A...
  • Page 126 Schematic Diagrams B - 44...

This manual is also suitable for:

D410f

Table of Contents
