  • Page 2 Preface Notebook Computer D470W/D480W Service Manual...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 4 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the D470W/ D480W series notebook PC.
  • Page 5 Preface IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, elec- tric shock and injury to persons, including the following: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 6 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 8 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode. • Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel.
  • Page 9 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 10: Table Of Contents

    External Locator - Right Side & Rear Views ........1-7 Sub-Woofer Speaker (D470W) ........... A-11 External Locator - Bottom View .............1-8 TV Tuner (D470W) ..............A-12 Mainboard Overview - Top (Key Parts) .........1-9 Floppy Disk Drive (D470W) ............A-13 Mainboard Overview - Bottom (Key Parts) ........1-10...
  • Page 11 Preface Hard Disk Drive (D470W) ............A-14 USB Port ..................B-19 Top (D480W) ................A-15 PCMCIA ENE1410 ..............B-20 Bottom (D480W) ................A-16 PCMCIA Power & Bluetooth Interface ........B-21 LCD 17" (D480W) ............... A-17 1394 PHY TSB41LV01 ..............B-22 CD-ROM Drive (D480W) ............A-18 LPC Super I/O ................B-23...

  • Page 12: Introduction

    1: Introduction Overview This manual covers the information you need to service or upgrade the D470W/D480W series notebook computer. In- formation about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.

  • Page 13: System Specifications

    Introduction System Specifications Processor BIOS • Intel Pentium 4 Processor - (478-pin) FC-PGA2 package • One 512KB Flash ROM • Phoenix BIOS µ 0.13) 0.13 Micron Process Technology, 512KB L2 Cache & 400MHz FSB - 2.0/ 2.2/ 2.4/ 2.5 /2.6 GHz LCD Options µ...

  • Page 14: Storage Devices

    Introduction Storage Devices Audio • 3.5" 3-mode Floppy Disk Drive • AC'97 2.1 compliant interface • 3D stereo enhanced sound system • Easy changeable 2.5" 9.5 mm (h) Hard Disk Drive • Compatible with Sound-Blaster PRO™ Supporting Master mode IDE •...

  • Page 15: Communication

    Introduction Communication Environmental Spec • Wireless Infrared transfer IrDA 1.1 compliant, 1cm - 1M • Temperature operating distance, 115.2K bps SIR/ 4Mbps FIR ° ° Operating: C ~ 35 C (w/o packing) • Built-in 10/100Mb Ethernet LAN ° ° Non-Operating: C ~ 60 C (packing) •...

  • Page 16: External Locator - Top View

    Introduction External Locator - Top View Figure 1 Top View 1. Optional PC Camera 2. LCD 3. Built-In Microphone 4. LED Power & Communication Indicators 5. LED Status Indicators 6. Hot-Key buttons 7. Close Cover/Lid Switch 8. Power Button 9. Keyboard 10.

  • Page 17: External Locator - Front & Left Side Views

    Introduction External Locator - Front & Left Side Views Figure 2 Front View 1. LCD Latches 2. Consumer Infrared Transceiver (functions with optional TV Tuner) 3. Mini IEEE 1394 Port 4. S/P DIF Out Port 5. Microphone-In Jack 6. Headphone-Out Jack 7.

  • Page 18: External Locator - Right Side & Rear Views

    Introduction External Locator - Right Side & Rear Views Figure 4 Right Side View 1. Security Lock Slot Figure 5 Rear View 9 10 1. Vent 2. DC-In Jack 3. 2 * USB 2.0/1.1 Ports 4. External Monitor (CRT) Port 5.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent/Fan Intake 2. Battery Cover 3. Hard Disk Cover 4. Bluetooth Module Cover 5. CPU & Memory Socket Cover 6. Optional Module Cover (Sub Woofer or TV Tuner or 6- in-1 Flash Card Reader) Note : The RAM and...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. PC Card Assembly 2. Northbridge - SiS M645DX 3. Southbridge - SiS 4. Flash BIOS ROM Mainboard Overview - Top (Key Parts) 1 - 9...

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU Socket (no CPU installed) 2. Memory Slots (no memory installed) 3. SiS 302LV TV- Out Controller 4. LAN Controller RTL8100BL 5. CardBus ENE CB1410 6. ALC202 - Audio Codec 7.

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. Modem Cable Connector (CN1) 2. LCD (and Inverter) Connector (JLCD1) 3. Video Camera Cable Connector (JCCD1) 4. Power Switch Board Cable Connector (JSW1) 5. TouchPad Cable Connector (JTP1) 6.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Wireless LAN Connector (JWL1) 2. DDR Fan Cable Connector (JFAN3) 3. CD-ROM Device Connector (JCDROM1) 4. Hard Disk Cable Connector (JHDD1) 5. Bluetooth Module Connector (JBT1) 6. CMOS Battery Cable Connector (JBAT1) 7.

  • Page 24: Disassembly

    2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the D470W/D480W series notebook’s parts and sub- systems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 25: Maintenance Tools

    Disassembly NOTE : All disassembly procedures assume that the system is turned OFF , and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 26: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 27: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Processor: 1. Remove the battery page 2 - 5 1.

  • Page 28: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. 2. Remove screws (Figure 1a) from the battery cover , and remove the cover. 3. Carefully (use a small screwdriver) disconnect the battery cable at point (Figure 4.

  • Page 29: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" IDE hard disk drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual ) when setting up a new hard disk.

  • Page 30: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting DDR 200/266 MHz. The main memory can be expanded up to 1024MB. The SO-DIMM modules supported are 128Mb, 256Mb, and 512Mb.
  • Page 31 Disassembly 5. Gently pull the two release latches ( & on the sides of the memory socket toward the sides of the computer. Figure 4 Removing/ Installing a RAM Module a. Pull release latches. b.Remove the module. 6. The module (Figure 4b) will pop-up, and you can remove it.

  • Page 32: Removing The Cd Device

    Disassembly Removing the CD Device The easy changeable CD device may be upgraded or changed. 1. Turn off the computer, remove the battery ( page 2 - 5 ) and turn it over. 2. Remove screws (Figure 5a) from the memory socket cover 3.
  • Page 33 Disassembly 4. Use a screwdriver to carefully push the CD device assembly out of the computer at point Figure 6 CD Device Removal Push the CD device out off the computer at point 5. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The screw holes should line up.

  • Page 34: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module page 2 - 5 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws (Figure 7a) from the Bluetooth module cover 3. Carefully lift up the Bluetooth module cover off the computer.

  • Page 35: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module page 2 - 5 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- nect it).

  • Page 36: Removing The Processor

    Disassembly Removing the Processor page 2 - 5 1. Turn off the computer, remove the battery ( ) and turn it over. 2. Remove screws from the memory socket cover 3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon- Figure 9 nect it).
  • Page 37 Disassembly 6. Remove screws (Figure 10a) and lift the CPU holder off the computer. 7. Unlock the processor by raising lever (Figure 10b). 8. Lift the CPU (Figure 10c) off the computer. Figure 10 Processor Removal (cont’d) a. Remove the screws and lift the CPU holder off the computer.

  • Page 38: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the D470W/D480W series notebook’s construction into a series of illustrations. The compo- nent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 39: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table 1 - 1 Part List Illustration Part D470W D480W Location page A - 3 page A - 15 page A - 4...

  • Page 40: Top (D470W

    Part Lists Top (D470W) Figure 1 Top (D470W) Top (D470W) A - 3...

  • Page 41: Bottom (D470W

    Part Lists Bottom (D470W) Figure 2 Bottom (D470W) A - 4 Bottom (D470W)

  • Page 42: Lcd 17" (D470W

    Part Lists LCD 17" (D470W) Figure 3 LCD 17" (D470W) LCD 17" (D470W) A - 5...

  • Page 43: Cd-Rom Drive (D470W

    Part Lists CD-ROM Drive (D470W) Figure 4 CD-ROM Drive (D470W) A - 6 CD-ROM Drive (D470W)

  • Page 44: Cd-Rw Drive (D470W

    Part Lists CD-RW Drive (D470W) Figure 5 CD-RW Drive (D470W) CD-RW Drive (D470W) A - 7...

  • Page 45: Dvd-Rom Drive (D470W

    Part Lists DVD-ROM Drive (D470W) Figure 6 DVD-ROM Drive (D470W) A - 8 DVD-ROM Drive (D470W)

  • Page 46: Combo Drive (D470W

    Part Lists Combo Drive (D470W) Figure 7 Combo Drive (D470W) Combo Drive (D470W) A - 9...

  • Page 47: Card Reader (D470W

    Part Lists Card Reader (D470W) Figure 8 Card Reader (D470W) A - 10 Card Reader (D470W)

  • Page 48: Sub-Woofer Speaker (D470W

    Part Lists Sub-Woofer Speaker (D470W) Figure 9 Sub-Woofer Speaker (D470W) Sub-Woofer Speaker (D470W) A - 11...

  • Page 49: Tv Tuner (D470W

    Part Lists TV Tuner (D470W) Figure 10 TV Tuner (D470W) A - 12 TV Tuner (D470W)

  • Page 50: Floppy Disk Drive (D470W

    Part Lists Floppy Disk Drive (D470W) Figure 11 Floppy Disk Drive (D470W) Floppy Disk Drive (D470W) A - 13...

  • Page 51: Hard Disk Drive (D470W

    Part Lists Hard Disk Drive (D470W) Figure 12 HDD Drive (D470W) A - 14 Hard Disk Drive (D470W)

  • Page 52: Top (D480W

    Part Lists Top (D480W) Figure 13 Top (D480W) Top (D480W) A - 15...

  • Page 53: Bottom (D480W

    Part Lists Bottom (D480W) Figure 14 Bottom (D480W) A - 16 Bottom (D480W)

  • Page 54: Lcd 17" (D480W

    Part Lists LCD 17" (D480W) Figure 15 LCD 17" (D480W) LCD 17" (D480W) A - 17...

  • Page 55: Cd-Rom Drive (D480W

    Part Lists CD-ROM Drive (D480W) Figure 16 CD-ROM Drive (D480W) A - 18 CD-ROM Drive (D480W)

  • Page 56: Cd-Rw Drive (D480W

    Part Lists CD-RW Drive (D480W) Figure 17 CD-RW Drive (D480W) CD-RW Drive (D480W) A - 19...

  • Page 57: Dvd-Rom Drive (D480W

    Part Lists DVD-ROM Drive (D480W) Figure 18 DVD-ROM Drive (D40W) A - 20 DVD-ROM Drive (D480W)

  • Page 58: Combo Drive (D480W

    Part Lists Combo Drive (D480W) Figure 19 Combo Drive (D480W) Combo Drive (D480W) A - 21...

  • Page 59: Card Reader (D480W

    Part Lists Card Reader (D480W) Figure 20 Card Reader (D480W) A - 22 Card Reader (D480W)

  • Page 60: Sub-Woofer Speaker (D480W

    Part Lists Sub-Woofer Speaker (D480W) Figure 21 Sub-Woofer Speaker (D480W) Sub-Woofer Speaker (D480W) A - 23...

  • Page 61: Tv Tuner (D480W

    Part Lists TV Tuner (D480W) Figure 22 TV Tuner (D480W) A - 24 TV Tuner (D480W)

  • Page 62: Floppy Disk Drive (D480W

    Part Lists Floppy Disk Drive (D480W) Figure 23 Floppy Disk Drive (D480W) Floppy Disk Drive (D480W) A - 25...

  • Page 63: Hard Disk Drive (D480W

    Part Lists Hard Disk Drive (D480W) Figure 24 HDD Drive (D480W) A - 26 Hard Disk Drive (D480W)

  • Page 64: Schematic Diagrams

    Schematic Diagrams Appendix B:Schematic Diagrams This appendix has circuit diagrams of the D470W/D480W notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table 1 Diagram - Page Diagram - Page Diagram - Page Schematic System Block Diagram - Page B - 2...

  • Page 65: System Block Diagram

    Schematic Diagrams System Block Diagram TV-OUT NORTHWOOD CLOCK ATI M9 GENERATOR SOCKET - 478 PANEL 2/16/32 2/16/32 DDRAM DDRAM Host Bus GTL+ & AGTL DDR INTERFACE TV-OUT SiS 302LV SiS M650 VB-LINK 702 mBGA Sheet 1 of 41 PANEL CRT PORT System Block Diagram Ultra 66/100/133...
  • Page 66 Schematic Diagrams Socket 478 1 of 2 HD#[0..63] HD#[0..63] 5 VCC_CORE JCPU1A HA#[3..31] HD#0 HA#[3..31] HD#1 HD#2 HD#3 HA#31 HD#4 HA#30 HD#5 HA#29 HD#6 HA#28 HD#7 HA#27 HD#8 HA#26 HD#9 HA#25 HD#10 HA#24 HD#11 HA#23 HD#12 HA#22 HD#13 HA#21 HD#14 HA#20 HD#15 HA#19...

  • Page 67: Socket 478 & Itp 2

    Schematic Diagrams Socket 478 & ITP 2 of 2 VCC_CORE CPUGTLVREFA R275 49.9_1% CPUGTLVREFB 49.9_1% C316 C313 C330 R276 C346 C349 C112 220P 220P 100_1% 220P 220P 100_1% CPU SIGNAL TERMINALION VCC_CORE VCC_CORE CLOSE TO CPU JCPU1B FERR# R274 4.7uH_SMD_30% 62_1% IERR AE23...

  • Page 68: Clock Generator

    Schematic Diagrams Clock Generator Main Clock Generator Damping Resistors Place near to the +3VS Clock Outputs By-Pass Capacitors Place near to the Clock CLOCK GEN (650) FCM2012V121 Outputs CLK_VCC3 VDDREF CPU-1 49.9_1% RP44 HCLK-CPU HCLK-CPU VDDZ CPUCLK0 HCLK-CPU 3 C401 CPU-2 49.9_1% C102...

  • Page 69: M650 (Host/Agp) 1

    Schematic Diagrams M650 (Host/AGP) 1 of 4 AAD18/AHSYNC 22(R) AAD30/BHSYNC 22(R) VAHSYNC 10 VBHSYNC 10 AAD18/AHSYNC AAD30/BHSYNC AAD17/AVSYNC 22(R) AAD31/BVSYNC AAD16/VADE 22(R) AAD17/AVSYNC VAVSYNC 10 AAD31/BVSYNC VBVSYNC 10 AAD16 10,30 AAD27/VBDE AAD27 10,30 R264 HNCOMP 22(R) AAD28/VBCTL0 VBCLK AAD28 10,30 AAD29/VBCTL1 20_1% Rds-on(n) = 10 ohm...
  • Page 70 Schematic Diagrams M650 (Memory for DDR) 2 of 4 /RMD[0..63] /RMD[0..63] 7,8 /RDQM[0..7] /RDQM[0..7] 7,8 /RDQS[0..7] /RDQS[0..7] 7,8 /RMA[0..14] /RMA[0..14] 7,8 /RCS#[0..5] /RCS#[0..5] 7,8 CKE[0..5] CKE[0..5] 7 Rs place close to DIMM1 BGA1B +2.5V /RMD4 RP46 AJ23 /RMD5 AG22 DQM0 /RDQM0 AH21 /RMD6...

  • Page 71: M650 (& Crt Out) 3

    Schematic Diagrams M650 (& CRT Out) 3 of 4 BGA1C NOTE: This page is for universal PCB design( suitable for both 645 or 650) SIS M650 ZCLK0 ZCLK0 ZCLK REFCLK0 NB Hardware Trap Table VOSCI REFCLK0 4 ZUREQ ZUREQ ZDREQ ZUREQ embedded pull-low ZDREQ...

  • Page 72: M650 (Power) 4

    Schematic Diagrams M650 (Power) 4 of 4 +3VS +3VS +1.8VS +3VS C360 +1.8V 10UF/10V 0.1UF C412 C410 C374 BGA1D 10U(0805) 0.1UF 10UF/10V C427 C423 C381 AUX1.8 +1.8V AUX3.3 0.1UF C426 C395 C367 0.1UF 0.1UF 0.1UF +1.8VS C382 C681 0.1UF +3VS +1.8VS C363 0.1UF...

  • Page 73: Ddr Memory Dimm

    Schematic Diagrams DDR Memory DIMM +2.5V /RMA0 /RMD0 /RMA0 +2.5V /RMA1 /RMD1 /RMA1 /RMA2 /RMD2 /RMA2 RP20 /RMA3 /RMD3 /RMA3 CKE4 /RMA4 /RMD4 /RMA4 CKE2 /RMA5 /RMD5 /RMA5 CKE3 /RMA6 /RMD6 /RMA6 CKE5 /RMA7 /RMD7 /RMA7 /RMA8 /RMD8 /RMA8 8P4R-470 /RMA9 /RMD9 /RMA9...

  • Page 74: Ddr Sstl-2 Termination

    Schematic Diagrams DDR SSTL-2 Termination SSTL-2 Termination Resistors MD/DQM(/DQS) SSTL-2 MA/Control SSTL-2 SSTL-2 OD 2.5V /RMD[0..63] /RMD[0..63]6,7 /RDQM[0..7] /RDQM[0..7]6,7 +1.25VS +1.25VS /RDQS[0..7] /RDQS[0..7]6,7 /RMA[0..14] /RMA[0..14] 6,7 /RCS#[0..5] /RCS#[0..5] 6,7 /RMD0 /RMA2 /RMD1 /RMA0 /RDQS0 /RMA12 /RMD2 /RSRAS# /RSRAS# RP63 8P4R-33 RP34 8P4R-33 /RMD3...

  • Page 75: Lvds Interface (Sis302Lv

    Schematic Diagrams LVDS Interface (SiS302LV) C248 33PF(R) +3VS COMPOSITE Z1301 R211 0(R) COMPOSITE LVDD1 FCM1608K121(R) R212 FCM1608K-121T07 JTV1 10U/10V(R) 0.1UF 0.1UF LGND 2.7UH DA204U(R) DA204U(R) R213 C250 33PF(R) R202 C261 C249 C262 C251 330PF 330PF +3VS 330PF 330PF LVDD2 SVIDEO CON PIN(GND1,GND2)=GND FCM1608K121(R) +3VS...

  • Page 76: Panel Con & Led Indicator

    Schematic Diagrams Panel Con & LED Indicator LCDVCC LCDVCC FCM2012V-121 FCM2012V-121 +3VS C322 C284 LCDVCC 4800 JLCD1 0.1UF 0.1UF +3VS TXOUT-LN0 TXOUT-UN0 C337 C338 TXOUT-LP0 TXOUT-UP0 R278 4.7U(0805) 0.1UF TXOUT-LN1 TXOUT-UN1 C285 C286 TXOUT-LP1 TXOUT-UP1 R301 0.1UF 4.7U(0805) Z245 TXOUT-LN2 TXOUT-UN2 VDD5 TXOUT-LP2...

  • Page 77: Pci/Ide/Hyperzip) 1

    Schematic Diagrams 962 (PCI/IDE/HyperZip) 1 of 4 AD[0..31] IDESAA[0..2] 19,20,25 AD[0..31] IDESAA[0..2] IDECS#A[0..1] IDECS#A[0..1] IDESAB[0..2] IDESAB[0..2] +1.8VS IDECS#B[0..1] IDECS#B[0..1] R118 BGA2A C150 C151 +3VS 0.01UF 0.1UF IDEAVDD REQ4# PREQ#4 IDEAVSS REQ3# PREQ#3 RP32 REQ2# ICHRDYA REQ2# ICHRDYA 14 PREQ#2 ICHRDYA FRAME# REQ1# IDEREQA...
  • Page 78 Schematic Diagrams 962 (Misc Signals) 2 of 4 BGA2B Programable on-die pull-high strength for CPU_S: ( Infinite, 150, 110, 56 Ohm) R102 4.7K NEED NOT to place OSC25MHI +3VS INIT# close to 96X INIT# INIT# OSC25MHO A20M# A20M# A20M# RN11 SMI# SMI# SMI#...
  • Page 79 Schematic Diagrams 962 (USB I/F) 3 of 4 BGA2C 1394_MA2/EESK UCLK48M UCLK48M4 EESK(GPI21) USBCLK48M 1394_MA1/EEDI EEDI(GPI22) 1394_MA0/EEDO UV3- -DATA3 -DATA3 EEDO(GPI23) 1394_EECS UV0+ UV0+ EECS(GPI24) UV0+ UV0- UV3+ +DATA3 UV0- +DATA3 UV0- UV1+ UV1+ UV1+ UV1- UV1- UV1- PHY_LPS UV2+ C465 C466 R239...
  • Page 80 Schematic Diagrams 962 (Power & RTC) 4 of 4 +1.8VS +1.8V +3VS C512 C511 C351 C406 C526 C489 C490 C505 C508 C469 C147 C482 C476 C501 C477 C127 0.1UF 0.1UF 10UF/10V 10UF/10V 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V BGA2D +1.8VS VDDZ...
  • Page 81 Schematic Diagrams HDD/Combo Connector RP41 IDEDB7 /2IDB7 IDEDB7 IDEDB6 /2IDB6 /2IDB8 IDEDB8 IDEDB6 IDEDB8 13 IDEDB5 /2IDB5 /2IDB9 IDEDB9 IDEDB5 IDEDB9 13 +3VS IDEDB4 /2IDB4 /2IDB10 IDEDB10 IDEDB4 IDEDB1013 /2IDB11 IDEDB11 JCDROM1 IDEDB1113 R277 4.7K MICHRDYB CD-L CD-R 8P4R-10 CD-L CD-R 5.6K MIDEREQB...
  • Page 82 Schematic Diagrams USB Port 560K OC0# 470K OC0# USBVCC0 +5VS C309 C308 FCM2012V121 1.1A F1AJ3 0.1UF L101 10UF/10V JCCD1 -DATA3 0.1UF -DATA3 FCM1608K121 L102 +DATA3 +DATA3 UV0- -DATA0 FCM1608K121 UV0- CCD CON UV0+ +DATA0 NEAR CCD CON. C848 UV0+ C847 47P(R) 47P(R) C101...
  • Page 83 Schematic Diagrams PCMCIA ENE1410 B_VCC C627 C619 C608 C602 C601 C644 C617 C632 C595 C646 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V 10UF/10V C618 C645 0.1UF 0.1UF JPCM1 B_VCC VPPD0 B_CD0 VPPD0 VPPD1 B_CD1 VPPD1 VCCD0# B_CD2 VCCD0# VCCD1# B_CD3 C625...
  • Page 84 Schematic Diagrams PCMCIA Power & Bluetooth Interface +5VS C563 0.1UF JMDC1 +12V +3VS MONO_OUT AUDIO_PD PHONE PHONE MONO_PHONE R431 AUXR B_VCC BVCC AUXL C588 10K(R) BVCC CDGND C590 C591 R423 BVCC CD_R 0.1UF CD_L 0.1UF 4.7U(0805) 8.2K(R) P_DN VDD3 3.3V AC_SYNC 3.3V SYNC...

  • Page 85: 1394 Phy Tsb41Lv01

    Schematic Diagrams 1394 PHY TSB41LV01 +3VS L147 BLM21P221SGPTM00-03 PHY3V BLM21P221SGPTM00-03(R) C573 C582 C583 C581 C586 C580 C585 C572 0.01UF 0.01UF 0.01UF 0.1UF 0.1UF 0.1UF 0.1UF 4.7U(0805) Sheet 21 of 41 R170 6.34K_1% R176 1394 PHY PHY3V Z216 Z240 TSB41LV01 R422 1K(R) VDD5 PHYISO#...

  • Page 86: Lpc Super I/O

    Schematic Diagrams LPC Super I/O +3VS C530 C539 C529 0.1UF 0.1UF 0.1UF +3VS SA10 SA11 SA12 PD[0..7] PD[0..7] 23 +5VS SA13 +5VS LPC_AD[0..3] R228 15,24 LPC_AD[0..3] SA14 SA15 LPC_AD0 LAD0 PD0/INDEX# SA16 LPC_AD1 LAD1 PD1/TRK0# FLASH# LPC_AD2 R227 LAD2 PD2/WP# BIOSCS# SA17 LPC_AD3...

  • Page 87: Lpt/Com Port

    Schematic Diagrams LPT/COM Port VDD5 VDD3 C260 0.1UF R223 100K PME# C247 PME# 19,22,24,25 0.1UF(K%) C246 C268 COM1RI 2N7002 0.1UF(K%) C267 0.1UF(K%) JCOM1 1SS355 0.1UF(K%) R224 RN10 100K SOUTA SOUTA T1IN T1OUT RTSA# RTSA# T2IN T2OUT DTRA DTRA T3IN T3OUT COM1RI DSRA# R2OUTB...

  • Page 88: Lpc H8

    Schematic Diagrams LPC H8 R508 0(0805)(R) VDD5 3VH8 3VH8 L135 R509 0(0805) VDD3 C212 4.7U(0805) 3VH8 C255 0.1UF +5VS C575 3VH8 1.1A F1AJ3 FH50ACB321611T C570 C571 0.1UF 0.1UF RP39 0.1UF 0.1UF C569 C562 C561 C202 JPS1 KB-SI3 0.1UF 0.1UF 0.1UF 10UF/10V KB-SI2 KB-SI4...

  • Page 89: Lan Rtl8100Bl

    Schematic Diagrams LAN RTL8100BL VCTRL LANVDD3 LANVCC25 LANVDD3 2SB1198K C431 C432 C404 C384 C403 0.1UF 0.1UF 0.1UF 0.1UF 0.1UF 10UF/10V 0.1UF 10UF/10V DE-COUPLE CAPS PLEASE CLOSE CHIP POWER PIN *For RTL8100C application, all bead must be rated 300mA/100ohm@100Mhz The maximum voltage drop when on should be less than 0.3V LANVDD3 C362 FCM2012V121...

  • Page 90: Audio Codec Alc201A

    Schematic Diagrams Audio Codec ALC201A For some crystal, FCM1608K-121 VDDA +3VS U18 78L05(SO8)(R) the bias resistor is needed VDDA R486 C613 C616 C637 C638 1M(R) C672 0.1UF 0.1UF R482 10UF/10V 10UF/10V 0(R) C665 C664 0.1UF(R) AGND 0.1UF 4.7U(0805) C642 0 LOUT-L LOUT-R 24.576MHz...

  • Page 91: Audio Out & Off Board Connectors

    Schematic Diagrams Audio Out & Off Board Connectors VDDA JAUDIO1 SPDIF OUT INTMIC R192 AUDIO_JACK INTMIC 2.2K C225 SPDIF FCM1608K-121 SPDIF 0.1UF C234 C226 680P R191 10UF/10V 2.2K JAUDIO2 BK1608HS330 AUDIO_JACK AGND Vrefout R190 2.2K(R) MIC IN Vrefout MIC1 R196 FCM1608K-121 MIC1 C231...

  • Page 92: System Power Control

    Schematic Diagrams System Power Control U14B R462 U15B +12VS U14C S3AUXSW# SUSB# 74LVC14 SUSB# 13,24 PSON# 15,29 PSON# U14D R197 74(A)HC08 100K SI2301 SLP S3 74LVC14 C235 R758 4.7UF/25V PSON 74LVC14 R654 100K PSON 100K U14E PSON U15C 2N7002 U14F 74LVC14 6,13 S3AUXSW#...

  • Page 93: Fan Control And Speedstep

    Schematic Diagrams Fan Control and SpeedStep FAN_VCC FCM2012V121 MAIN FAN C833 100U/16V DIP R410 H_DPSLP# JFAN1 24.9K H_DPSLP# 2,36 R409 F01J2E 4.7K FAN_SEN FAN_SEN R517 100K FI-S03P-HF 3904 CPUSTP# CPUSTP# 4,15 FAN1-ON C522 R367 1SS355 FAN1-ON 0.1UF 2SD1834 C515 0.1UF(R) R182 L125 4.7K...

  • Page 94: Mobility M9-P

    Schematic Diagrams Mobility M9-P 5,10 AAD[0..15] BGA3A AAD0 GPIO0 GPIO0 AAD28/VBCTL0 AAD1 Part 1 of 5 GPIO1 5,10 AAD28 GPIO1 AAD2 GPIO2 GPIO2 AAD29/VBCTL1 AAD3 GPIO3 +3VS 5,10 AAD29 AAD4 GPIO3 GPIO4 T377 AAD5 GPIO4 GPIO5 T378 AAD[0..15] AAD6 GPIO5 GPIO6 5,10 AAD[0..15]...

  • Page 95: Mobility M9-P Mem A/B

    Schematic Diagrams Mobility M9-P MEM A/B OPTIONAL SERIES OPTIONAL SERIES TERMINATION MEMORY CHANNEL A MEMORY CHANNEL B TERMINATION FOR MEMORY FOR MEMORY ADDR & CNTRL ADDR & CNTRL INSTALL INSTALL RESISTORS RESISTORS CLOSER TO CLOSER TO DQMB#[7..0] DQMB#[0..7] DQMA#[7..0] DQMA#[0..7] MEM_MAB[13..0] MEM_MAB[0..13] MEM_MAA[13..0]...

  • Page 96: Vga Dram 1

    Schematic Diagrams VGA DRAM 1 of 2 CHANNEL +2.5V_MEM +2.5V_MEM MEM_MAA[0..13]31 MEM_MDA[0..63] MEM_MDA[0..63] 3 3 MEM_MDA0 MEM_MDA32 MEM_MDA1 MEM_MAA0 MEM_MAA0 MEM_MDA33 MEM_MDA2 MEM_MAA1 MEM_MAA1 MEM_MDA34 MEM_MDA3 MEM_MAA2 MEM_MAA2 MEM_MDA35 MEM_MDA4 MEM_MAA3 MEM_MAA3 MEM_MDA36 MEM_MDA5 MEM_MAA4 MEM_MAA4 MEM_MDA37 MEM_MDA6 MEM_MAA5 MEM_MAA5 MEM_MDA38 Sheet 32 of 41 MEM_MDA7...

  • Page 97: Vga Dram 1 Of 2 - Termination

    Schematic Diagrams VGA DRAM 1 of 2 - Termination Close to memory device MDB[0..63] MDA[0..63] Close to memory device MEM_MDB[0..63] 3 4 MEM_MDA[0..63] 3 2 MDB0 MEM_MDB0 MDA0 MEM_MDA0 MDB1 RN24 8P4R-22 MEM_MDB1 MDA1 RN25 8P4R-22 MEM_MDA1 MDB2 MEM_MDB2 MDA2 MEM_MDA2 MDB3 MEM_MDB3...
  • Page 98 Schematic Diagrams VGA DRAM 2 of 2 CHANNL B MEM_MDB[0..63] 3 3 MEM_MDB[0..63] 3 3 +2.5V_MEM +2.5V_MEM MEM_CSB0# MEM_RASB# MEM_MAB[0..13]31 MEM_CASB# MEM_MDB0 MEM_MDB32 MEM_MDB1 MEM_MAB0 MEM_MAB0 MEM_MDB33 MEM_MDB2 MEM_MAB1 MEM_MAB1 MEM_MDB34 MEM_MDB3 MEM_MAB2 MEM_MAB2 MEM_MDB35 MEM_WEB# MEM_MDB4 MEM_MAB3 MEM_MAB3 MEM_MDB36 MEM_MDB5 MEM_MAB4 MEM_MAB4...

  • Page 99: Mobility M9-P Pow

    Schematic Diagrams Mobility M9-P POW BGA3D BGA3E VDDC VDDC Part 4 of 5 VDDC VDDC Part 5 of 5 VDDC VDDC VDDC VDDC +1.5VS VDDC VDDC VDDC 4.0A 200mil VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC C758 C759 C760 C761 C762 C763...

  • Page 100: Vcore

    Schematic Diagrams VCORE PD44 PR131 PR63 FCM1608K121 INTVCC FS1J3 PC84 SYS5V PR151 PR152 PR20 PR21 PC76 PC82 PC78 PC77 PC80 PC79 PC81 10U/25V 10U/25V 10U/25V 0.1U 10U/25V 0.1U 0.1U 100K 100K VR_PWRGD VID0 2,15 VID1 PD45 SENSE1- SYS5V+ FS1J3 SENSE1+ PC18 1000PF RB751V...

  • Page 101: Ddr Power

    Schematic Diagrams DDR Power VDDP SYS5V PR96 PR95 PC113 PC52 PD16 RB751V PD17 PC106 RB751V PC34 0.1uF/25V 10U_1210 PC132 1000P PGOOD1 PGOOD2 PC133 1000P VCCA1 PQ70 VDDP1 VCCA2 2.5V Si4800 PC49 PC107 PR93 PC33 ILIM1 TON1 0.1uF/25V PR103 20K 1% 10U_1210 PR105 750K...

  • Page 102: System Power

    Schematic Diagrams System Power PR108 VIN1 PC57 PC56 0.1A 12VR 0.1U 10U/25V PC62 PC58 PC123 PC55 0.1U 10U/25V 0.1U PD18 PC54 PC119 10U/16V PD22 PC63 RB751V 0.1U 1U/50V_0805 11FS2 10U_1210 PC53 PD19 PQ43A 0.1U RB751V AO4900 PC122 BST3 0.1U VDD3 SYS3V PR86 PR109...

  • Page 103: Charger

    Schematic Diagrams Charger F1J3FTP PQ40 2.5A Si4435 2.5A PC25 PC89 PC24 PR72 PD30 0.1U 10U_1210 0.1U PQ15 Si4435 PQ18 CDRH-1205-470 100m(2512) 03A04 DTA114EUA PC94 PC96 PR24 PD28 PC99 PC95 PC32 PC97 1N4148 10U/25V_DIP F1J3FTP 0.1U(0805) 0.1U(1206) 100K 100U/25V_DIP 0.1U(1206) 100U/25V_DIP PR75 PR73 PQ17...

  • Page 104: Sw Board And Hotkey

    Schematic Diagrams SW Board and HotKey VSW2 LID_SW#_10 VCN1 VIN_10 VIN_10 MPU-101-81 PWRS_10 PWRS_10 LID_SW#_10 LID_SW#_10 WEB0#_10 WEB0#_10 0.1U WEB1#_10 WEB1#_10 WEB2#_10 WEB2#_10 Sheet 40 of 41 GND_L GND_L CON8 SW Board and HotKey GND_L Hot keys,Power switch,key,Lid VIN_10 VSW1 PWRS_10 HCH STS-05-A 0.1U...

  • Page 105: Touchpad And Switch Board

    Schematic Diagrams TouchPad and Switch Board VCC5_T 10MIL VCN3 VCC5_T 10MIL VCN2 TPADDATA TPADCLK TPADDATA TPADCLK 10MIL SW_UP TP_FFC4-R SW_DOWN SW_L 0.1U SW_R Sheet 41 of 41 120P 120P 120P 0(R) TouchPad and plan GND_A GND_A Switch Board C178D83N C178D83N GND_A GND_A GND_A...

  • Page 106: Switches And Jumpers

    BIOS Update Appendix C:Switches and Jumpers This appendix is about the system’s switch and jumper settings. The following figure shows the location of the DIP Switch and Jumper the system uses. You can access them after you remove the Back Cover. Be sure to turn OFF the system before you perform any part removal procedure. Figure C - 1 Mainboard Switch and Jumper...
  • Page 107 BIOS Update Settings CPU Type/Voltage Jumper Settings (SWEB8) SWEB8-1 SWEB8-2 SWEB8-3 SWEB8-4 SWEB8-5 SWEB8-6 CPU Type Voltage VID4 VID3 VID2 VID1 VID0 P4-Mobile 1.30V P4-2.0~2.8G (DT) 1.50V P4-Celeron (DT) 1.525V P4-3.06G (DT) 1.55V P4-Portability 2.4~2.8G 1.525V Function Jumper Settings (SW1) Function Settings SW1-1 SW1-2...

This manual is also suitable for:
