Table 2–9 gives the power specifications for the fully configured GS160/320 I/O
expander cabinet for different regions.
Table 2–9 Power Specifications of I/O Expander Cabinet
Specification
1
Voltage, Vrms
Frequency, Hz
Phase
Power plug, quantity
Maximum input
current
2
Total VA
Rating
Surge current
2
Total power
2
Heat output
Power cord length
Power cap (system)
Receptacle (site)
(industry equiv.)
1
The US/Canada model supports a nominal voltage of 115-127V. The Europe and
US/Canada/Japan models support a nominal voltage of 200-240V.
2
Based on fully configured expander cabinet that contains four PCI boxes and eight disk drives.
U.S./Canada
120
(GS80 system)
50–60
1-phase
2 circuits
2-wire+GND
L5-30P, 2
22A
2,600
30A
150A peak
2,550
8,700 Btu/hr
15 ft/4.5 m
2 DEC 12-11193-00
2 DEC 12-11194-00
2 NEMA L5-30R
U.S./Canada/Japan
200-240
(GS160/320 systems)
50–60
1-phase
2 circuits
2-wire+GND
L6-30P, 1
12A
2,600
30A
150A peak
2,550
8,700 Btu/hr
15 ft/4.5 m
2 DEC 12-16886-00
2 DEC 12-19658-01
2 NEMA L6-30R
System Specifications
Europe
220/240
(GS160/320 systems)
50–60
1-phase
2 circuits
2-wire+GND
IEC309 3P 32A, 1
11A
2,600
32A
170A peak
2,550
8,700 Btu/hr
15 ft/4.5 m
2 DEC 12-14379-07
2 Hubbell 332R6W
2 IEC 309 (32A)
2-11
