Table 2–7 Power Specifications of a GS320 with Three System Boxes
Specification
1
Voltage, Vrms
Frequency, Hz
Phases
Power plug, quantity
Maximum input
current/phase
Rating
Surge current
2
Total VA
2
Total power
2
Heat output
Power cord length
Power cap (system)
Receptacle (site)
(industry equiv.)
1
The US/Canada/Japan model supports a three-phase star connected source with nominal voltage of
115-127V/200-220V or a three-phase delta connected source with a nominal voltage of 200-240V.
The Europe model supports a three-phase star connected source with a nominal voltage of 200-
240V/346-415V.
2
Based on fully loaded system with two PCI boxes and one storage shelf in the power cabinet.
U.S./Canada/Japan
120/208 or 202
50–60
2 circuits
3-phase star or
3-wire+N+GND
L21-30P, 2
21A
30A
170A peak
9,600
9,500 watts
32,500 Btu/hr
15 ft/4.5 m
2 DEC 12-12314-00
2 DEC 12-12315-01
2 NEMA L21-30R
2 circuits
3-phase delta
3-wire junct. GND
or 4-wire-mid-GND
System Specifications
Europe
380–415
50–60
3-phase star
2 circuits
3-wire+N+GND
IEC309 5P 32A, 2
13A
32A
170A peak
9,600
9,500 watts
32,500 Btu/hr
15 ft/4.5 m
2 DEC 12-14379-06
2 Hubbell 532R6W
2 IEC 309 (32A)
2-9
