Table 2–3 gives the heat dissipation in minimally as well as fully configured
GS80 systems.
Table 2–3 Heat Dissipation in GS80 Systems
System Configuration
GS80, one drawer
Minimal configuration:
Two power supplies, one CPU module, one memory
module, one system I/O module, minimally
configured PCI, one disk drive
GS80, two drawers
Minimal configuration:
Four power supplies, one CPU module, one memory
module, one system I/O module, minimally
configured PCI, one disk drive
GS80, one drawer
Full configuration:
Three power supplies, four CPU modules, four
memory modules, two system I/O modules, one PCI
box, one storage shelf with six disk drives
GS80, two drawers
Full configuration:
Six power supplies, eight CPU modules, eight
memory modules, four system I/O modules, one PCI
box, one storage shelf with six disk drives
See Table 2–9 for the power specifications of the I/O expander cabinet.
2-4 AlphaServer GS80/160/320 Site Preparation
Heat Dissipation
1,150 W/3,800 Btu/hr
1,900 W/6,400 Btu/hr
2,100 W/7,150 Btu/hr
3,450 W/11,650 Btu/hr
