Patch Types 1, 4 and 6 can be used by the host for post-scan image control for the i800/i1800 (with image
addressing) Series Scanners (they are not used for image addressing).
The Toggle Patch may be used to switch back and forth from bi-tonal and color/grayscale scanning for the
i280, 3590C, i600, i800 and i1800 (without image addressing) Series Scanners. This provides Color on the
Fly during capture, with no need for post-scan processing by the host application.
NOTE: The patch codes illustrated below are not to spec. Use the patch sheets included in this packet for
specifications.
Patch Codes
Patch 1
Patch 4/Toggle Patch
Patch 6
Patch code specifications
Patch 1
Patch 4/Toggle Patch
Patch 6
Zone Millimetres
Inches
Low High Low
Range
Range Range
A 0.19 0.21 4.83
B 0.27 0.29 6.86
C 0.47 0.49 11.94 12.45
D 0.55 0.57 13.97 14.48
E 0.63 0.65 16.00 16.51
F 0.71 0.73 18.03 18.54
G 0.79 0.81 20.07 20.57
Zone Inches Millimetres
Low
Low High
Range Range Range
A 0.07 0.09 1.78
B 0.15 0.17 3.81
C 0.35 0.37 8.89
D 0.43 0.45 10.92
E 0.63 0.65 16.00
F 0.71 0.73 18.03
G 0.79 0.81 20.07
Zone Inches Millimetres
Low
Low High
Range Range Range
A 0.07 0.09 1.78
B 0.15 0.17 3.81
C 0.23 0.25 5.84
D 0.31 0.33 7.87
E 0.51 0.53 12.95
F 0.59 0.61 14.99
G 0.79 0.81 20.07
High
Range
5.33
7.37
High
Range
2.29
4.32
9.40
11.43
16.51
18.54
20.57
High
Range
2.29
4.32
6.35
8.38
13.46
15.49
20.57
