Active Management uptime is 2 minutes 2 seconds
==========================================================================
SL 1: RX-BI-24C 24-port 1 GbE Copper Module (Serial #: SA51050944, Part #: 31521-
001D)
Boot
: Version 2.7.3T155 Copyright (c) 1996-2010 Brocade Communications
Systems, Inc.
Compiled on Apr 20 2011 at 15:09:22 labeled as rlb02800
(307473 bytes) from boot flash
Monitor: Version 2.8.0T155 Copyright (c) 1996-2010 Brocade Communications Systems,
Inc.
Compiled on Apr 20 2011 at 01:07:02 labeled as rlb02800b
(307473 bytes) from code flash
IronWare: Version 2.8.0T157 Copyright (c) 1996-2010 Brocade Communications Systems,
Inc.
Compiled on Apr 20 2011 at 01:16:26 labeled as rlp02800
(2340308 bytes) from Primary
FAP 1 version: 2
FAP 2 version: 2
FAP 3 version: 0
FAP 4 version: 0
660 MHz Power PC processor 440GP (version 8020/0020) 330 MHz bus
512 KB Boot Flash (AM29LV040B), 16 MB Code Flash (MT28F640J3)
512 MB DRAM, 8 KB SRAM, 0 Bytes BRAM
LP Slot 1 uptime is 59 seconds
..All show version done
The fields are described in the Code Flash and Boot Flash Information, which appears above.
Different image information
The following sections describe the various software images for the management module and interface
module.
Management Modules
The following table describes the various software images for the management module.
Field
Boot Image
IronWare Software Release 02.8.00a for Brocade BigIron RX Series Swtches
Release Notes v 1.0
Table 4: Software image files for management modules
Description
Indicates the boot image running in the management module. The output
displays the following information about the image:
•
Version – "2.2.1Txxy" indicates the image version number. The
"Txxy" is used by Brocade for record keeping. The "xx" indicates the
hardware type, while the "y" indicates the image type.
•
Size – The size, in bytes, of the image.
•
Compilation date and time – The date and time that Brocade compiled
the image.
Page 15 of 40
