Upgrading MBRIDGE FPGA on the management module

BigIron RX management modules contain an upgradable FPGA images called MBRIDGE and
SBRIDGE. The MBRIDGE and SBRIDGE image installed must be compatible with the software version
you are running on the BigIron RX.
The following table describes the MBRIDGE FPGA versions required for the 02.8.00a version.
Software Current MBRIDGE image
installed on
BigIron RX
02.4.00
02.4.00a
02.4.00b
02.4.00c
02.4.00d
02.4.00e
02.4.00f
02.4.00g
02.5.00 BigIron RX-16/8/4 (mbridge)
BigIron RX-32 (mbridge32)
02.5.00a through BigIron RX-16/8/4 (mbridge)
02.5.00f BigIron RX-32 (mbridge32)
02.6.00a through BigIron RX-16/8/4
02.6.00c BigIron RX-32 (mbridge32)
02.7.00 BigIron RX-16/8/4 (mbridge)
BigIron RX-32 (mbridge32)
02.7.01 BigIron RX-16/8/4 (mbridge)
BigIron RX-32 (mbridge32)
02.7.01a through BigIron RX-16/8/4 (mbridge)
02.7.01b BigIron RX-32 (mbridge32)
02.7.02 BigIron RX-16/8/4 (mbridge)
BigIron RX-32 (mbridge32)
02.7.02a through BigIron RX-16/8/4 (mbridge)
02.7.02h BigIron RX-32 (mbridge32)
02.7.03 through BigIron RX-16/8/4 (mbridge)
02.7.03a BigIron RX-32 (mbridge32)
02.8.00 through BigIron RX-16/8/4 (mbridge)
02.8.00a BigIron RX-32 (mbridge32)
Table 11: Switch Fabric module FPGA versions required per software version (BigIron RX-32)
Software image installed
on BigIron RX
02.5.00
02.5.00a through 02.5.00j
02.6.00
02.6.00a through 02.6.00e
