Different image information

Management Modules

This field
Boot Image
Monitor Image
IronWare Image
IronWare Software Release 02.7.03a for Brocade BigIron RX Series Swtches
Release Notes v 1.0
Displays
Indicates the boot image running in the management module. The output
displays the following information about the image:
•
Version – "2.2.1Txxy" indicates the image version number. The "Txxy" is
used by Brocade for record keeping. The "xx" indicates the hardware type,
while the "y" indicates the image type.
•
Size – The size, in bytes, of the image.
•
Compilation date and time – The date and time that Brocade compiled the
image.
Indicates the Monitor image running in the management module. The output
displays the following information about the image:
•
Version – "2.2.1Txxy" indicates the image version number. The "Txxy" is
used by Brocade for record keeping. The "xx" indicates the hardware type,
while the "y" indicates the image type.
•
Size – The size, in bytes, of the image.
•
Compilation date and time – The date and time that Brocade compiled the
image.
Indicates the IronWare image running in the management module. The output
displays the following information about the image:
•
Version – "2.2.1Txxy" indicates the image version number. The "Txxy" is
used by Brocade for record keeping. The "xx" indicates the hardware type,
while the "y" indicates the image type.
•
Size – The size, in bytes, of the image, of the image change, and the check
sum changes.
•
Compilation date and time – The date and time that Brocade compiled the
image.
