Network Status

This section displays information on the current wireless connection. This
window appears when you select Wireless in EWS. The option items may
differ due to the printer models.
• Link Status: indicates whether or not the WLAN interface is connected to
other wireless devices.
SSID
•
• Operation Mode
• Associated Frequency: indicates the associated frequency mode, for
example, 802.11b/g.
• BSSID: displays the associated BSSID, for example, 00:02:78:E3:43:89.
• Link Quality: represents quality of the wireless link between the print
server and an access point or other devices by percentage, for example,
Excellent, Very Good.
• Current Channel: represents the associated channel, for example, [10]
2457 MHz.

Network setup

These are the basic parameters required to make wireless connections found
on the Wireless menu of EWS. Click Submit after changing parameters.
• SSID: SSID (Service Set Identifier) is a name that identifies a wireless
network. Access points and wireless devices attempting to connect to a
specific wireless network must use the same SSID. The SSID is case-
sensitive.
• Operation Mode: Operation Mode refers to the type of wireless
connections. Choose one of the following options:
– Ad hoc: allows wireless devices to communicate directly with each
other in a peer-to-peer environment.
NOTE:
on your wireless network device.
– Infrastructure: allows wireless devices to communicate with each
other through an access point.
50
Appendix G. Wireless network environment
In Ad-Hoc mode, you may need to restart the print server depending
