Installing and Configuring the
Dell™ Internal Wireless Card
Model 5002
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2355dn Multifunction Mono Laser Printer and is the answer not in the manual?

Questions and answers

Related Manuals for Dell 2355dn Multifunction Mono Laser Printer

Summary of Contents for Dell 2355dn Multifunction Mono Laser Printer

  • Page 1 Installing and Configuring the Dell™ Internal Wireless Card Model 5002 w w w . d e l l . c o m | s u p p o r t . d e l l . c o m...
  • Page 2 Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

  • Page 3: Table Of Contents

    Installing the Dell Internal Wireless Adapter Hardware ... . . 5 Configuring the Dell Internal Wireless Adapter ....8 Appendix A.
  • Page 4 Appendix D. Additional functions ... . 34 Printer properties settings ........34 Firmware upgrade (HTTP) .
  • Page 5 Appendix H. Wireless Specifications ..55 Appendix I. Regulatory statement ... . . 56 FCC Compliance ..........56 EU Compliance .

  • Page 6: This Guide Can Be Used For Dell™ Laser Printers 5330Dn, 2335Dn, And 2355Dn

    Dell Internal Wireless Adapter Ethernet cable Installation Guide (This document) NOTE: In order to use the printer wirelessly you need to install and configure the Dell Internal Wireless Adapter. This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...

  • Page 7: Installing The Dell Internal Wireless Adapter Hardware

    For Dell Mono 5330dn only, Detach the dummy panel on the back of your printer using a firm object, such as a screwdriver. For Dell Mono Laser 5330dn This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 8 For Dell MFP Laser 2335dn and 2355dn Locate the card connector on the printer’s connector board. wireless network connector For Dell Mono Laser 5330dn For Dell MFP Laser 2335dn and 2355dn This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 9 In order to use the printer wirelessly you need to install and configure the See "Configuring the Dell Internal Dell Internal Wireless Adapter. Wireless Adapter" on page 8 for instructions. This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...

  • Page 10: Configuring The Dell Internal Wireless Adapter

    Method 3: Assigning the printer an IP address, using the IP address to • access the printer and using the printer's Embedded Web Server. page 15 for instructions. This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...

  • Page 11: Ethernet Cable

    Drivers on the computer Drivers on the computer Embedded Web Service web page Set all the wireless parameters Remove temporary cables Install Network Printer Drivers on the computer This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 12 This method supports two modes. Either; • Search List: Automatically displays a list of available networks and prompts for the security key (if applicable). This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 13 Configuration Page. For Dell 5330dn Mono Laser: Press Menu ( Press Scroll ( ) to highlight Reports and press Select ( ). This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 14 Press Menu ( Press Scroll ( ) to highlight Reports and press Select ( ). Press Scroll ( ) to highlight Network Settings and press Select ( ). This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 15 Wi-Fi Protected Setup™(WPS)-enabled access point (or wireless router). Press Setup Machine Setup from the home screen. Press the Next ( ) button. Press the up/down arrows to select Network Setup. This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 16 Drivers and Utilities or Software and Documentation Select Network Installation and follow the on-screen instructions. Grant Access to the Dell installation software if any firewall warnings appear. This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 17 Embedded Web Server. NOTE: The Dell Internal Wireless Adapter is shipped in Ad-Hoc mode by default. To configure the Dell Internal Wireless Adapter in Ad-Hoc mode, you must access the printer's Embedded Web Server using a direct connection to your computer. This is only recommended for advanced users.
  • Page 18 Press the Next ( ) button. Press the up/down arrows to select Reports. Press the up/down arrows to select Network Settings. The printer Configuration Page is printed. This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 19 Key. • Custom Mode: In this mode users can give their own SSID or edit SSID, choose the security manually and apply the settings. This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 20 Select ( ). On the Reports menu, scroll to Network Settings using Scroll ( ) and press Select ( ). The printer Configuration Page is printed. This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 21 Drivers and Utilities or Software and Documentation Select Network Installation and follow the on-screen instructions. Grant access to the Dell installation software if any firewall warnings appear. This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 22 192.0.0. 193 ) Copy the Subnet mask and Default gateway as seen on the Configuration Page. You should now be able to access the printer’s Embedded Web Server. This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...
  • Page 23 Dell Internal Wireless Adapter" on page 17 to complete configuring Dell Internal Wireless Adapter. NOTE: Remember to restore the proxy and IP settings on your computer once you have completed configuring the Dell Internal Wireless Adapter. This guide can be used for Dell™ laser printers 5330dn, 2335dn, and 2355dn...

  • Page 24: Appendix A. Setip Address Utility

    MAC address. Refer to a user’s guide of your printer/MFP to print the network configuration page. From the Start menu, select Programs Dell Dell Printers your printer driver name Set IP Address Utility. From the Start menu, select Programs...

  • Page 25: Appendix B. Management Protocols

    Appendix B. Management protocols Before using your network printer/MFP , you may need to check or configure some parameters using management protocols. DHCP/BOOTP Dynamic Host Configuration Protocol (DHCP) is a communication protocol enabling network administrators to centrally manage and to automate the assignment of IP addresses in a network.

  • Page 26: Snmp

    SNMP Simple Network Management Protocol (SNMP), which is part of the TCP/IP protocol suite, is an application layer protocol that facilitates the exchange of management information between network devices. It enables network administrators to remotely monitor and configure network devices, find and solve network problems, and plan for network growth.

  • Page 27: Slp

    Service Location Protocol (SLP) is an Internet standard network protocol that provides a framework to allow networking applications to discover the existence, location, and configuration of networked services in enterprise networks, such as printers, Web servers, fax machines, video cameras, file systems, backup devices (tape drives), databases, directories, mail servers, and calendars.

  • Page 28: Dynamic Dns (Ddns)

    Using SLP Once SLP is enabled, the network print server works as a Service Agent and the User Agent, for example, EWS, searches for the network print server by SLP Protocol. Dynamic DNS (DDNS) DNS (Domain Name System) is used for registration of domain names and provides Host names to an IP address resolution service.

  • Page 29: Wins

    WINS Before Dynamic DNS was defined, DNS could only be updated manually when DHCP servers automatically provided (or removed) IP addresses. As a result, DNS servers often contained obsolete listings. In response, Microsoft developed Windows Internet Name Service (WINS) to solve this problem for NetBIOS names.

  • Page 30: Bonjour

    The WINS server will update the printer's NetBIOS name in its database. Users can use the printer name instead of its IP address. Bonjour Bonjour allows for a network system to be easily discovered and its capabilities to be revealed by any Bonjour-compliant client software, such as Print Center Utility built in to Mac OS X.
  • Page 31 • Embedded Web Service (EWS): Select Printer Server Settings Print Server Settings UPnP(SSDP). – Auto IP Enabled: You can enable or disable Auto IP. When this option is selected, the network print server cannot find the control point and receive an IP address from the control point. The network print server will create an IP address of “169.254.XXX.XXX.”...

  • Page 32: Appendix C. Printing Protocols

    Appendix C. Printing protocols Before setting the network printing ports, you must install the printer driver with the local port (LPT) on the system. Refer to your printer/MFP user’s guide. Standard TCP/IP port You can print your documents to your network printer by creating a Standard TCP/IP port.

  • Page 33: Lpr Port

    Enter the IP address or DNS name of your network printer and click Next. For the port name, a default name will be entered by Windows. You can change it to a more user-friendly name. Follow the instructions on the screen to complete installation. Now, you can select your printer from the Print Setup dialogue box.

  • Page 34: Ipp Port

    Make sure that the appropriate Standard TCP/IP port is selected and click Configure Port. Select LPR from the Protocol section. Enter the print queue name and click OK. Click OK to close the properties window. In Unix Depending on your particular Unix system, LPD configuration may vary. See your system documentation for the correct syntax for the system.
  • Page 35 nonce value, the HTTP method, and the requested URI. In this way, the password is never sent in the clear to avoid the most serious flaws of Basic authentication. • User Name, Password: The user name and password can include A to Z, a to z, 0 to 9, and other symbols !#$%&()+-./{}~_@.

  • Page 36: Appendix D. Additional Functions

    Firmware upgrade (HTTP) You can upgrade your printer’s firmware using the HTTP protocol. First, you need to download firmware from the Dell website (http://suport.dell.com.) NOTE: Before upgrading the firmware, make sure that TCP/IP parameters are entered in the print server.

  • Page 37: Restart

    Network Menu. • Speed: Automatic, 10 Mbps(Half Duplex), 10 Mbps(Full Duplex), 100 Mbps(Half Duplex),100 Mbps(Full Duplex). select a Ethernet speed from the drop-down list. • 1000 Mbps(Full Duplex) for Dell 5330dn Mono Laser Printer only. Click Submit. Appendix D. Additional functions...

  • Page 38: Appendix E. Netware Environment

    NetWare client that is attached to the network. This section describes how to continue printing with your network printer card in a NetWare environment. NOTE: This section is applicable for Dell 5330dn Mono Laser Printer. NetWare printing The NetWare architecture for printing is comprised of the following: Printers...

  • Page 39: Configuring Netware

    workstation for printing. Configuration for NetWare printing involves creation of printers, print queues, and print servers, and the associations between them on the NetWare file server. The file server configuration for printers, print queues, and print servers may be achieved using NetWare supplied utilities, such as PCONSOLE and NWADMIN.
  • Page 40 • IPX/SPX mode configuration: Configure IPX/SPX mode for your NetWare system. – Bindery configuration: You can set up the bindery server. • Bindery Setup: Use this option if you have already configured one or more bindery servers (file servers running NetWare 3.x, or 4.x, 5.x, or 6.x in bindery emulation) with a print server and a print queue for network printing.

  • Page 41: Printing In Netware

    Printing in NetWare To print to your network printer on a NetWare workstation, you need to add a print queue. NOTE: To use bindery emulation, you must log on to a Bindery server as an administrator. In the NDS mode, log on to target text of the NDS tree where you have administrator privileges.

  • Page 42: Appendix F. Ethertalk Environment

    EtherTalk Protocol: allows you to enable or disable the EtherTalk protocol. • EatherTalk Printer Name: allows you to set the printer name for EtherTalk protocol. The default name is DELL+MAC address. This name is automatically displayed on Chooser. Appendix F. EtherTalk environment...

  • Page 43: Configuring The Printer

    List. Select the printer in the Printer List. For MAC OS 10.3, if Auto Select does not work properly, select Dell in Printer Model and your printer name in Model Name. For MAC OS 10.4, if Auto Select does not work properly, select Dell in Print Using and your printer name in Model.

  • Page 44: Tcp/Ip Printing

    For MAC OS 10.6, if Auto Select does not work properly, select Select Printer Software... and your printer name in Print Using. Click Add. The printer appears in the Printer List as the default printer (in boldface). It also appears in the Printer pop-up menu when you print a document. TCP/IP printing Apple added TCP/IP printing to all versions including and after OS 10.3.

  • Page 45: Bonjour Printer

    For MAC OS 10.5~10.6, enter the queue name in the Queue field. For MAC OS 10.3, if Auto Select does not work properly, select Dell in Printer Model and your printer name in Model Name. For MAC OS 10.4, if Auto Select does not work properly, select Dell in Print Using and your printer name in Model.
  • Page 46 Printer List. Select your printer from the Printer List. For MAC OS 10.3, if Auto Select does not work properly, select Dell in Printer Model and your printer name in Model Name. For MAC OS 10.4, if Auto Select does not work properly, select Dell in Print Using and your printer name in Model.

  • Page 47: Appendix G. Wireless Network Environment

    Appendix G. Wireless network environment Overview The Wireless Network Printer Card supports the IEEE 802.11b/g standard for wireless LAN (WLAN) communications. Properly configuring your network's wireless settings on the print server will allow you to send print jobs to the print server over the WLAN.

  • Page 48: Access Point

    On Apple networks, Infrastructure mode is called Airport Network mode. In this mode, the dell print server receives print jobs from wireless and wired network computers through an access point.
  • Page 49 Channels There are several channels specified in the 802.11b/g standard for wireless communications. The number of available channels authorized for use may be restricted based on your location (generally regulatory domain). See Appendix for available channels at your location. When shipped from the factory, the Wireless Network Printer Card is configured for Ad-hoc mode using the automatic channel selection.
  • Page 50 each key value is 10 hexadecimal digits (0-9 and A-F) or 5 alphanumeric characters. In 128-bit mode, each key value is 26 hexadecimal digits or 13 alphanumeric characters. Contact your network administrator for this configuration. IEEE 802.1x (WPA-Enterprise Model Only) IEEE 802.1x uses EAP (Extensible Authentication Protocol) and an authentication server, such as RADIUS (Remote Authentication Dial In User Server, RFC2138) for client and network server authentication.
  • Page 51 Certificates may be issued and signed by a trusted third party, called Certificate Authority (CA). In EAP/802.1x authentications, such as EAP-TLS, EAPTTLS, and PEAP, the dell network print server may require one or both of the following certificates: Root Certificate: A certificate from a trusted Certificate Authority (CA) is •...

  • Page 52: Network Status

    Network Status This section displays information on the current wireless connection. This window appears when you select Wireless in EWS. The option items may differ due to the printer models. • Link Status: indicates whether or not the WLAN interface is connected to other wireless devices.

  • Page 53: Security Setup

    • Frequency Mode: Choose a frequency mode. The dell print server supports 802.11b and 802.11g frequency modes. – 802.11b/g (2.4GHz) mode: Data is sent using IEEE802.11g standard communications in the 2.4 GHz band. This mode is compatible with IEEE802.11b standard.

  • Page 54: Network Key Setup

    higher priority on a RADIUS server. Available authentications are NONE, EAP-MD5, EAP MSCHAPv2 in 802.1x Authentication on Static WEB security. • Encryption: This option will be changed due to the option you have selected in the Authentication field. Network Key Setup Enter the network key due to the Encryption option you have selected.
  • Page 55 • User Password: 802.1x EAP authentication methods, such as EAP-MD5, EAP-MSCAHPv2, EAP-TTLS, and PEAP, require an EAP user password as an account password. A user password is necessary, if 802.1x authentication is enabled. This is not saved as the default value. •...
  • Page 56 In the Certificate Snap-in dialogue box, select Computer Account and click Next Finish Close Select the certificate you want to change to a file. When making a root certificate, select one of the certificates in the trusted root certificate authority folder. When making a client certificate, select one of the certificates in the personal folder.

  • Page 57: Appendix H. Wireless Specifications

    Appendix H. Wireless Specifications Items Specifications Supported networks • Windows 2000, XP 64 bit (Home & Pro), XP 32 bit (Home & Pro), Server 2003 & 2008, Vista 32bit / 64bit (Starter, Home Basic, Home Premium, Ultimate, Enterprise & Business), Windows 7, Server 2008 R2 •...

  • Page 58: Appendix I. Regulatory Statement

    Appendix I. Regulatory statement FCC Compliance FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 59 IMPORTANT NOTE: In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization.

  • Page 60: Eu Compliance

    The user’s manual for end users must include the following information in a prominent location "IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter."...
  • Page 61 A minimum separation distance of 20 cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements of the Council recommendation 1999/519/EC of 12 July 1999. As long as the 2 conditions above are met, no further evaluation under Article 3.2 of the R&TTE Directive and do not require further involvement of an R&TTE Directive Notified Body for the final product.
  • Page 62 Conformity Assessment of the Products integrating the DELL5002 The following is a supplementary explanation of conformity assessments for final products integrating the radio modules such as the DELL5002, that have passed conformity assessments in accordance with the R&TTE Directive. The procedures for conformity assessment in accordance with the R&TTE Directive are the responsibility of the manufacturer of the final product.
  • Page 63 Conformity assessment procedures for final products exempted from R&TTE Directive Article 3.2 In every case, the manufacturer of a final product must follow the procedures for conformity assessment of the final product with the requirements of R&TTE Directive Article 3.1(a) and (b), for safety and EMC. The conformity assessment for Article 3.2 is carried out in accordance with the following: 1) Attach the EN 300 328 test report of the assessed radio module and the EC Declaration of Conformity to the conformity assessment of the final product...

  • Page 64: Appendix J. Openssl License

    Appendix J. OpenSSL License Copyright (c) 1998-2001 The OpenSSL Project. All rights reserved. Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.

  • Page 65: Original Ssleay License

    This product includes cryptographic software written by Eric Young (eay@cryptsoft.com). This product includes software written by Tim Hudson (tjh@cryptsoft.com). Original SSLeay License Copyright (C) 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved. This package is an SSL implementation written by Eric Young (eay@cryptsoft.com).
  • Page 66 THIS SOFTWARE IS PROVIDED BY ERIC YOUNG ``AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE AUTHOR OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;...
  • Page 67 Index Bonjour 43 Firmware upgrade 34 BOOTP 23 HTTP 23 Certificates client certificate 53 making files 53 root certificate 53 IP filtering 34 Channels 51 IPP port 32 Client certificate installing 53 LPR port 31 DDNS 26 DHCP 23 NetWare adding a printer 39 adding a queue 39 Bindery configuration 38...
  • Page 68 Resetting 11, 50, 51 WINS 27 Root certificate Wireless network installing 53 channels 51 frequency 51 operation mode 50 security settings 51 SSID 50 SLP 25 SNMP 24 Standard TCP/IP port 30 TCP/IP in Macintosh 42 management protocol BOOTP 23 DDNS 26 DHCP 23 HTTP 23...
