Rear view

#
Item
2
USB 2.0 ports
3
LAN (RJ-45) port
4
DVI connector
5
Type B USB 2.0 port
6
Power jack
Description
Connect to USB devices.
Connects to a LAN.
Connects to a DVI display or projector.
Connects your docking station to your computer.
Connects to the power adapter. The mini
docking station always needs external power to
operate, it is not USB-powered.
2
3
4
5
6
4
