- Page 1 ODK480 USB-C 15-IN-1 4K Triple Display Docking Station Customer Services: (978)230-8895(US) Mon-Fri: 9am-6pm(EST) User Manual...
- Page 2 Thank you for choosing acer! Please read this user manual carefully when using this product. Preface Thank you for purchasing acer products. For optimum operation, please read this manual carefully before using. Model ODK480 Item Name USB-C 15-IN-1 4K Triple Display Docking Station...
- Page 3 Serial number Name Function description Power LED Power LED indicates device 4-Pole Earphone Jack supports audio playback 4-Pole Earphone Jack and microphone input with a single connector USB-A Port Data transfer only, speed up to 10Gbps (10Gbps) USB-C Port Data transfer only, speed up to 10Gbps (10Gbps) ON/OFF button to turn the docking station Power Switch...
- Page 4 Cable Holder Connection The cable holder is designed to secure the USB-C cable tightly. If you are concerned that the USB-C cable may become loose, please follow the steps below to install the cable holder onto the dock. 1. Insert the cable into the cable holder according to the arrow direction. 2.
- Page 5 Monitor Connection Before use, please note the docking station has 3 video stream groups, they are "ALT MODE", "Display 1" or "Display 2". And the ports of the same video stream group cannot be used simultaneously. ALT MODE Display 1 Display 2 Video Port HDMI...
- Page 6 Monitor 1 Host Monitor 2 2.3 Triple Display 1. Connect this docking station to the power supply adapter. 2. Connect your host laptop to USB-C host port of the docking station. 3. Connect your monitors to the docking station and make sure that 3 monitors are in 3 different video stream groups.
- Page 7 Driver Installation Before using this docking station, please enter the https://www.synaptics.com/products/displaylink-graphics/downloads to find and download the corresponding driver for this docking station and install it as the following steps: For Windows 1. Locate the downloaded folder and double-click the driver file you just downloaded. 2.
- Page 8 For Mac 1. Double-click the driver file you just downloaded, navigate to the Install DisplayLink Manager window, click Continue. 2. Click Continue to the next window, then click Agree. 3. Click Install and choose Use Password..., then entter the screen password and click Install Software.
- Page 9 4. Please wait patiently for the installation to complete, thenclick Close. 5. If you have enabled notifications from DisplayLink Manager,it will remind you to allow screen recording when it detects that this permission is missing. 6. If you didn't get the notification from DisplayLink Manager, please click Go in the function bar at the top left of screen, then select Applications and click DisplayLink Manager.
- Page 10 7. Click the DisplayLink Graphics icon in the function bar at the top right of the screen, and the notification will also appear in the DisplayLink Manager window.A warning is found here, you should allow the screen recording permission for DisplayLink Manager.
- Page 11 10. When the small window pops up, choose a password or use your fingerprint to unlock. 10.1 If you use password to unlock, and click Use Password, then enter your password and choose Unlock. 10.2 If you use fingerprint to unlock, it will jump directly to the next step. 11.
- Page 12 II RealTek Network Driver Installation For Windows 1. Locate the downloaded folder and unzip the file to the desktop, please select Yes if your computer asks your permission, then double-click the Driver icon on the desktop. 2. Click Next to continue the installation process. 3.
- Page 13 4. After the Driver is successfully installed, select Finish to exit the wizard. For macOS 1. Locate the downloaded folder and 3. Navigate to the wizard window, double click the icon on the desktop. and click Continue to the next step. 2.
- Page 14 7. Select Install Software after 6. Select Use Password or use Touch ID entering the screen password. to allow thhe software installation. 8. Please wait patiently for the installation 9. Please restart your Mac. to complete, then click Restart. Display Settings Before configuring the settings, please make sure this docking station has been connected to your laptop and monitors correctly.
- Page 15 For macOS X12 or Below 1.Click Apple icon->About This Mac 2.Click Displays->Displays Preferences 3. Select "Display" from the list, then you can enjoy different operations of mirroring, expanding and rotating on your monitors. 4. Or click "Gather Windows " to gather all connected displays and make separate settings.
- Page 16 For macOS X13 1.Click Apple icon->About This Mac 2. Click "More Info..." 3. Select "Displays" from the list, then you can enjoy different operations of mirroring, expanding and rotating on your monitors.
- Page 17 After-Sale Services If you are not sure how to get your acer product working properly, please contact our friendly support team in your free time for a quick solution. Customer Services: (978) 230-8895(US)
- Page 18 Product Pictures...
- Page 19 CAN ICES(B)/NMB(B) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
