Rear view

#
Item
6
USB 2.0 ports
7
LAN (RJ-45) port
8
DVI connector
9
HDMI connector
(optional)
10
Type B USB 3.0 port
11
Power jack
6
7
8
9
10
11
Description
Connect to USB devices.
Connects to a LAN.
Connects to a DVI display or projector.
Connects to an HDMI display or projector.
Connects your docking station to your computer.
Connects to the power adapter. The mini
docking station always needs external power to
operate, it is not USB-powered.
