Removing the cabinet cover and board cover

Ensure that the power switch on the copier is in the off position. Remove the power
1
cord from the power cord socket at the rear of the copier.
Remove the screw from the cabinet cover at the rear side of the machine using the
2
supplied screwdriver.
Slide the cabinet cover in the direction indicated by the arrow and pull the cover while
3
raising it a little to remove it.
Remove the three screws from the board cover.
4
INSTALLING THE OPTIONAL PRINTER UPGRADE KIT
1
5
