INSTALLING THE PRINTER DRIVER SOFTWARE
Insert the installation CD-ROM into the CD-ROM drive.
5
Click the Start button and select Run. When the screen shown below appears, type
R:\SETUP (if the CD-ROM is designated as drive R) and click the OK button. Proceed
to step 7.
1
"Installation from CD-ROM" window will appear. Insert the installation CD-ROM into
6
the CD-ROM drive. Type R:\ (if the CD-ROM is designated as drive R) and click the
OK button. Proceed to step 7.
The installation program will start. To install the printer driver to the default folder,
7
click the Next button. To select a different folder, select Browse and type in the new
path and folder name. Click OK and say YES to create the folder, select the Next
button to continue.
On the display, you will see "printer port to be used". Normally, this is LPT1 and it is
8
selected automatically.
Ensure that Yes is checked to use the printer as the default printer.
Finally click the Next button.
A "Confirm installation" window will be displayed. To continue installation, click the
9
Yes button.
When the installation is complete, you will be asked whether or not to print a test
10
page. If you wish to do so, click the Yes button. At this time, ensure that paper is
loaded in the paper tray.
If the test print completes successfully, click the Finish button. "The installation of the
11
SHARP AL-1000 Series Software is complete." window will be displayed. Click the
OK button.
12
If you have any problem with the test print, see TROUBLESHOOTING on
page 23 and check the symptoms and solutions. Print the test page again after
removing the problem.
