Frymaster FOOTPRINT 8196345 Service & Parts Manual

Frymaster FOOTPRINT 8196345 Service & Parts Manual

Gas fryers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Frymaster, a member of the Commercial Food Equipment Service Association, recommends
using CFESA Certified Technicians.
24-Hour Service Hotline 1-800-551-8633
FEBRUARY 2009
*8196345*
www.frymaster.com
E-mail:
service@frymaster.com

Advertisement

Table of Contents
loading

Related Manuals for Frymaster FOOTPRINT 8196345

Summary of Contents for Frymaster FOOTPRINT 8196345

  • Page 1 Frymaster, a member of the Commercial Food Equipment Service Association, recommends using CFESA Certified Technicians. 24-Hour Service Hotline 1-800-551-8633 FEBRUARY 2009 *8196345* www.frymaster.com E-mail: service@frymaster.com...
  • Page 2 UNAUTHORIZED SERVICE CENTER. This appliance is intended for professional use only and is to be operated by qualified personnel only. A Frymaster DEAN Factory Authorized Service Center (FASC) or other qualified professional should perform installation, maintenance, and repairs. Installation, maintenance, or repairs by unqualified personnel may void the manufacturer’s warranty.
  • Page 3 If a flexible gas line is used, an additional restraining cable must be connected at all times when the fryer is in use. The front ledge of the fryer is not a step! Do not stand on the fryer. Serious injury can result from slips or contact with the hot oil.

  • Page 4: Table Of Contents

    Accessing Fryers for Servicing ... 1-4 Cleaning the Gas Valve Vent Tube ... 1-5 Checking the Burner Manifold Gas Pressure ... 1-5 Measuring Flame Current... 1-7 Replacing Fryer Components... 1-7 1.9.1 Replacing the Controller or the Controller Wiring Harness... 1-7 1.9.2 Replacing the Temperature Probe or High-Limit Thermostat ...
  • Page 5 PROTECTOR 1.15 Loading and Updating Software Procedures... 1-38 1.16 Principal Wiring Connections ... 1-39 1.17 Wiring Diagrams ... 1-40 1.17.1 Main Wiring ... 1-40 1.17.2 Transformer / Filter Boxes ... 1-41 1.17.2.1 FPGL230 and 430 Transformer/Filter Box (Domestic) ... 1-41 1.17.2.2 FPGL330 Transformer/Filter Box (Domestic)...
  • Page 6 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 7: Chapter 1: Service Procedures

    Simultaneously, the module causes the ignitor to spark for four seconds to light the burner. A flame sensor verifies the burner ® SERIES GAS FRYER Out to The ignition module...

  • Page 8: Interface Board

    All fryers in this series have an interface board located in the component box behind the control panel. The interface board provides a link between the computer and the fryer’s individual components without requiring excessive wiring, and allows the computer to execute commands from one central point.

  • Page 10: Thermostats

    ® Protector series gas fryers are also equipped with a high-limit thermostat. In the event that the fryer fails to properly control the oil temperature, the high-limit thermostat prevents the fryer from overheating to the flash point. The high-limit thermostat acts as a normally closed power switch that opens when exposed to temperatures above 425ºF to 450ºF (218ºC to 232ºC).

  • Page 11: Cleaning The Gas Valve Vent Tube

    4. On non-CE fryers only, place the gas valve in the ON position. 5. Place the fryer power switch in the ON position. When the burner has lit and burned steadily for at least one minute, compare the gas pressure reading to the pressure for the corresponding gas in the appropriate table on the following page.
  • Page 12 Non-CE Valve 7. Place the fryer power switch (and the gas valve in non-CE fryers) in the OFF position. Remove the fitting from the pressure tap hole and reinstall the pressure tap plug. CE Standard Burner Manifold Gas Pressures...

  • Page 13: Measuring Flame Current

    Connect the negative lead of the meter to the terminal from which the sensing wire was removed. 3. Place the fryer power switch in the ON position to light the burners. After the frypot temperature reaches 200°F (93°C), wait at least one minute before checking the reading. NOTE: The closer the unit is to normal operating temperature, the more accurate the reading will be.

  • Page 14: Replacing The Temperature Probe Or High-Limit Thermostat

    This will leave one set of wires, enclosed in spiral wrap, connected to the component box. 13. Remove the box and set it atop the fryer to expose the temperature probe and high-limit thermostat.

  • Page 15: Replacing An Ignition Module

    1.9.4 Replacing an Ignition Module 1. Disconnect the fryer from the electrical supply. 2. Lift up on the bezel to disengage the tabs on its lower edge from the control panel frame. 3. Remove the top two screws in the upper corners of the computer.

  • Page 16: Replacing Or Cleaning A Combustion Air Blower

    1. Disconnect the blower wiring harness, remove the blower assembly mounting nuts, and remove the blower assembly from the fryer. If cleaning the motor, continue with Step 2; otherwise, install the replacement blower, reconnect the wiring harness, and then go to Step 6.

  • Page 17: Adjusting The Air/Gas Mixture

    Reinstall the blower shield. 5. Reinstall the blower assembly in the fryer and reconnect the wiring disconnected in Step 1. 6. Light the fryer in accordance with the procedure described in Chapter 3, Section 3.2.2 of the ®...

  • Page 18: Replacing A Gas Valve

    Reconnect the high-limit thermostat wires and drain safety wires to the valve. E. Reconnect the fryer to the gas supply and open the cut off valve. Apply a solution of soapy water around each connection to check for gas leaks. Eliminate any that are found.

  • Page 19: Replacing A Burner Assembly

    13. Reverse steps 1 through 9 to reassemble the components. 14. Fill the frypot with oil. Turn the fryer on, turn off or bypass the melt cycle, and operate the unit for at least 10 minutes. 15. Visually examine the burner flame. The color and intensity on both sides should be the same.

  • Page 20: Replacing The Filter Motor, Filter Pump, Or Filter Pump Solenoid Valve

    3. Position a container beneath the oil return fitting at the front of the cabinet. Disconnect the flexible oil line from the fitting, allowing any residual oil to drain into the container. 4. At the rear of the fryer, unplug the left connector (as viewed from the rear of the fryer) from the transformer box.
  • Page 21 Cut any ties that prevent the box from being pulled out of the control panel frame. 10. Carefully pull the box clear of the frame and rest it on top of the fryer. 11. Using a pin pusher, remove the temperature probe, high-limit thermostat wires and RTD probe wires from the plugs or terminals, marking each wire to facilitate re-assembly.

  • Page 22: Replacing Frypot Insulation And/Or Upper Burner Rails

    1.9.12 Replacing Frypot Insulation and/or Upper Burner Rails NOTE: Replacing the burner rails requires completely tearing down the frypot and installing new frypot insulation. Refer to the frypot exploded view below for component identification. 1. Remove the frypot per Section 1.9.11. 2.
  • Page 23 11. Remove the upper burner rails (11). NOTE: For the following steps, refer to the frypot exploded view on page 1-16 for component identification. 12. Remove any residual insulation, sealant, and/or oil from the exterior of the frypot. 13. Place the “L” shaped pieces of the combustion chamber insulation (1) in the front and rear corners of both upper rail-retaining slots.
  • Page 24 together with two ¼” self-tapping screws. NOTE: Full-vat units have a two-piece insulation retainer and two pieces of insulation. Dual-vat units have one-piece components. 30. Return to the rear of the frypot and fully tighten all washer-nuts. 31. Remove and replace the plenum gaskets (18). 32.

  • Page 25: Troubleshooting And Problem Isolation

    PROBLEMS RELATED TO THE ELECTRONIC CIRCUITS If gas and electrical power are being supplied to the fryer, the next most likely cause of ignition failure is a problem in the 24 VAC circuit.
  • Page 26 If the fryer’s gas and air supplies are correct, the problem is most likely with one of the electrical components. Examine the ignition module and computer for signs of melting, distortion, and/or discoloration due to excessive heat build-up in the fryer (this condition usually indicates improper flue performance).
  • Page 27 Verify that the ignition wire is tightly connected at both ends and free of obvious signs of damage. Again, if damage is due to excessive heat in the fryer, that problem must also be corrected. Check for proper operation by disconnecting the wire from the ignitor (spark plug), inserting the tip of a screw driver into the terminal.

  • Page 28: Computer Malfunctions

    The CM7 computer performs the recovery test each time the fryer warms up. An operator can view the results of the test any time the fryer is above the 325ºF (163ºC) point by pressing the INFO button once when the fryer is on. The test results will be displayed in the computer’s LED panel in minutes and seconds.
  • Page 29 • The operator attempted to filter oil that was not heated. Cold oil is thicker and causes the pump motor to work harder and overheat. If the motor hums but the pump does not rotate, there is a blockage in the pump. Incorrectly sized or installed paper will allow food particles and sediment to pass through the filter pan and into the pump.

  • Page 30: Leakage

    1.10.6 Leakage Leakage of the frypot will usually be due to improperly sealed high-limit thermostats, RTD’s, temperature probes, and drain fittings. When installed or replaced, each of these components must ® be sealed with Loctite PST56765 sealant or equivalent to prevent leakage. In very rare cases, a leak may develop along one of the welded edges of the frypot.
  • Page 31 208-250V C onfiguration 100-120V C onfiguration BINDS AND JAMS Noisy, jerky or erratic movement of the lifts is usually due to lack of lubrication of the rods and ® bushings. Apply a light coat of Lubriplate or similar lightweight white grease to the rod and bushings to correct the problem.

  • Page 32: Troubleshooting Guides

    The wiring diagram on the Pages 1-45 and 46 identifies the components and wiring connection points. 1.11 Troubleshooting Guides The troubleshooting guides on the following pages are intended to assist service technicians in quickly isolating the probable causes of equipment malfunctions by following a logical, systematic process.
  • Page 33 1-27...

  • Page 34: Troubleshooting The Gas Valve

    1.11.4 Replacing the Transformer or Filter Relay Disconnect the fryer from the electrical power supply. Remove the cover from the transformer box in the rear of the fryer to expose the interior of the transformer box. Replace the transformer or filter CAUTION...

  • Page 35: Probe Resistance Chart

    relay marking the wires to ease reassembly. Once replaced, reconnect the power. When replacing a filter relay in the transformer, ensure the 24VAC relay (8070012) is used. 1.12 Probe Resistance Chart Probe Resistance Chart ® For use with Protector Series fryers manufactured with Minco Thermistor probes only. OHMS OHMS 1059...

  • Page 36: Ato

    Ensure the yellow LED is securely attached to plug J6 on the ATO board. Check to see that fryer is heating. Check probe resistance. If probe is bad, replace the probe. Ensure that the oil in the JIB is above 70°F (21°C).
  • Page 37 1.13.2 ATO (Automatic Top-Off) Board Pin Positions and Harnesses Connector From/To Solenoids Top Off Pump JIB Reset Switch Solenoids Top Off Pump & JIB Reset Switch J4 (Rear) / Transformer J5 (Front) J1 - Vat #1 J2 - Vat #2 ATO RTD J3 - Vat #3 Orange LED...

  • Page 38: Replacing The Ato Board Or Transformer

    1.13.3 Replacing the ATO Board or Transformer Disconnect the fryer from the electrical power supply. Locate the ATO box (see Figure 1 on page 1-29), behind the JIB (Jug In Box). Remove the cover to expose the transformer and ATO board (see Figure 2). Mark and unplug any wires or harnesses.
  • Page 39 This display is normal when the fryer is first turned on while in the melt cycle mode. To bypass the melt cycle press and hold a #2 product button under the LCD display until a chirp is heard.
  • Page 40 Check resistance of probe, if faulty replace probe. Swap the computer wiring harness with one known to be good. If problem is corrected replace the harness. Is displayed if the fryer loses its ability to heat oil. displayed when temperature (232°C) thermostat has opened, halting the heating of the oil.
  • Page 41 Problem Probable Causes CM7 display shows Loose or damaged harness software for only CM7. 1.14.2 CM7 Useful Codes To enter any of the following codes: Press the UNLOCK ▼ button three times. TECH is button. CODE is displayed. Enter a code listed below for the appropriate displayed.

  • Page 42: Cm7 Menu Summary Tree

    1.14.3 CM7 Menu Summary Tree Reflected below are the major programming sections in the CM7 and the order in which submenu headings will be found under the sections in the Installation and Operation Manual. Adding New Menu Items Storing Menu Items in Product Buttons Temperature Conversion from F°...

  • Page 43: Cm7 Board Pin Positions And Harnesses

    1.14.4 CM7 Board Pin Positions and Harnesses Connector From/To Interface SMT Computer to Board to Computer Previous CM7 J7 or Network Resistor 807-4552 ATO J1 or Next CM7 J6 Interface Board Ground Computer Locator to Computer SD Card Harness PN Function 12VAC In Ground...

  • Page 44: Loading And Updating Software Procedures

    9. Repeat steps 1-8 for all computers. 10. Remove ALL power from the fryer on the rear of the unit. 11. Restore power to the fryer. There is short delay prior to the computer powering up and displaying OFF. 12. With the computer displaying OFF, verify software update by pressing the TEMP button to check updated CM7/ATO version.

  • Page 45: Principal Wiring Connections

    1.16 Principal Wiring Connections 1-39...

  • Page 46: Wiring Diagrams

    1.17 Wiring Diagrams 1.17.1 Main Refer to "PRINCIPAL WIRING CONNECTIONS" on Page 1-39 for detail of connection points J1, J2, J3. 1-40 The Heat Strip is not present here on 330’s.

  • Page 47: Transformer / Filter Boxes

    1.17.2 Transformer / Filter Boxes 1.17.2.1 FPGL230 and 430 Transformer / Filter Box (Domestic) 1-41...

  • Page 48: Fpgl330 Transformer/Filter Box (Domestic)

    1.17.2.2 FPGL330 Transformer / Filter Box (Domestic) 1-42...

  • Page 49: Modular Basket Lift (100/120V)

    1.17.3 Modular Basket Lift (100/120V) 1-43...

  • Page 50: Modular Basket Lift (208/250V)

    1.17.4 Modular Basket Lift (208/250V) 1-44...

  • Page 51: Simplified Wiring Diagrams

    1.18 Simplified Wiring Diagrams 1.18.1 FPGL30 Series Full Vat 1-45...
  • Page 52 1.18.2 FPGL30 Series Full Vat (Australia and Pacific Rim) 1-46...

  • Page 53: Fpgl30 Series Simplified Wiring

    1.18.3 FPGL30 Series Simplified Wiring 1-47...

  • Page 54: Fpgl30 Series Data Network Flowchart

    1.18.4 FPGL30 Series Data Network Flowchart 1-48...

  • Page 55: Chapter 2: Parts List

    PROTECTOR CHAPTER 2: PARTS LIST Accessories ITEM PART # 803-0209 Brush, Frypot 803-0197 Cleanout Rod, 27-inch 810-2793 Hanger, Basket 809-0171 Thumbscrew, ¼-20 X 1⅜-inch Universal Hood (use 809-0921 for Spacer) 106-8930 Cover, Frypot, Full Vat 826-0993SP Handle Kit, Frypot Cover (includes handle and screws) 803-0375 Basket Support Rack, Full Vat 803-0136...

  • Page 56: Basket Lift Assemblies And Associated Parts

    2.2 Basket Lift Assembly and Associated Parts...
  • Page 57 2.2 Basket Lift Assembly and Associated Parts cont. ITEM PART # 200-2942 Mount, Modular Basket Lift 806-5964SP Motor Assembly, Modular Basket Lift 807-2133 Capacitor, 12.5 μFarad, 250VAC Motor Run 807-2572 Microswitch Resistor Assembly 806-8530SP 100-120V Modular Basket Lift (see Note 2 in illustration) 106-2771 208-250V Modular Basket Lift 809-0082...

  • Page 58: Doors, Sides, Flue Caps, Top Caps And Casters

    809-0970 Retaining Ring 230-4685 Hinge, Door Lower 810-1494 Caster without Brake 810-2970 Caster with Brake Flue Cap-Stainless Steel 823-6325 Two Station Fryer 106-7977 Three Station Fryer 106-8955 Four Station Fryer Top Cap 824-1846 Two Station Fryer 823-6289 Three Station Fryer...

  • Page 59: Drain System Components

    Drain System Components 2.4.1 Drain Valves and Associated Parts ITEM PART # 809-0540 Nut, ½-13 2-Way Hex Lock 900-2936 Retainer, Nut Drain Valve 810-3350 Handle, Drain Valve FV 810-0677 Grip, Drain Handle 901-2348 Cover, Safety Switch 807-2103 Switch, Micro 816-0220 Insulation, RF Switch 806-8137 Bracket, Switch Drain Assy...

  • Page 60: Drain Tube Sections And Associated Parts

    2.4.2 Drain Tube Sections and Associated Parts ITEM PART # 823-6610 4625 Drain Tube, Full-Vat Left Closed/Right End Open 823-6467 Drain Tube, Dump GL30 823-6615 Drain Tube, Dump GL230 823-6611 Drain Tube, Full-Vat Right, Left, Open/Right End Open 823-6612 Drain Tube, Full-Vat Center, Left Open/Right End Open 823-6614 Drain Tube, Full-Vat GL230 Right, Left Open/Right Closed Short 823-6613...

  • Page 61: Electronics And Electrical Components

    Electronics and Electrical Components 2.5.1 Component Boxes...
  • Page 62 2.5.1 Component Boxes cont. ITEM PART # 810-1164 Block, One-Piece Screwless Terminal 816-0217 Insulation, Terminal Block Paper 807-3843 Fuse 3A 250V Domestic 807-3293 Fuse 5A 125V International Only 807-3483 Cable, 21-inch Ignition – For 807-3366/3365 Modules 826-2024 Cable, Ignition - 1 wire / 1 Rajah 826-1721 Cable, Ignition - 2 wire / 2 Rajah 807-1878...

  • Page 63: Transformer Boxes

    2.5.2 Transformer Boxes...
  • Page 64 2.5.2 Transformer Boxes cont. ITEM PART # Box Assembly, Transformer 106-9021SP FPGL230 106-9022 FPGL330 106-9734 GL230 CE Export 106-9710 GL330 CE Export 106-5801 GL430/252 106-8133 Cable Assembly, Transformer Box Line GL230,330, 330 CE Export 106-8168 Cable Assembly, Transformer Box Line GL230 CE Export 106-8170 Cable Assembly, Transformer Box Filter Pump GL230 and 330 106-9742...

  • Page 65: Computers And Associated Components

    2.5.3 Computers and Associated Components NOTE: See Page 2-7 for Interface Board to Computer Wiring Harness. ITEM PART # Replacement CM7 Computer 108-0231 Non-CE CM7 (For use in US, Canada, Mexico and all other non-CE coun- tries) 810-3141 Sound Device, Universal SMT * Not illustrated.

  • Page 66: Wiring

    Wiring 2.6.1 Main Wiring Harnesses 2-PIN FEMALE CONNECTOR 12-PIN MALE CONNECTOR 12-PIN MALE CONNECTOR 2-PIN FEMALE CONNECTOR 12-PIN MALE CONNECTOR 12-PIN MALE CONNECTOR ITEM PART # 807-1978 U.S. and Non-CE Export Main Wiring Harness 50/52 807-4014 U.S. and Non-CE Export Main Wiring Harness 350/52 807-2168 CE Main Wiring Harness (not shown) 807-1978...

  • Page 67: Cm7 And Ato Wiring Harnesses

    2.6.2 CM7 and ATO Wiring Harnesses ITEM PART # 807-4546 Computer Communication (used from Computer to Computer) 807-4655 FV Harness RTD Medium (used from RTD to ATO Board) 807-4654 FV ATO/RTD Probe 807-4553 ATO Power (used from Transformer to ATO Board) ATO Pump and JIB (used from ATO Board to Top-off Pump and JIB Reset 807-4719 Switch)

  • Page 68: Frypots And Associated Components

    Frypots and Associated Components 2.7.1 Full-Vat Frypot Components 2-14...
  • Page 69 2.7.1 Full-Vat Frypot Components cont. ITEM PART # 106-8978SP Frypot Assembly Full-Vat Protector 106-8979 Frypot Assembly Full-Vat Protector 826-2595 Insulation Kit, Complete Full-Vat 826-2592 Insulation Kit, Burner Full-Vat 106-7524 Flue Assembly, Full-Vat 220-2222 Back, Lower Full-Vat Combustion Chamber 220-2226 Retainer, Full-Vat Upper Insulation 220-2231 Retainer, Outer Frypot 222-2694...

  • Page 70: Frypot Assemblies And Associated Parts

    2.7.2 Frypot Assemblies and Associated Parts ITEM PART # 106-8978SP Frypot Assembly, Full-Vat Protector Natural 106-8979SP Frypot Assembly, Full-Vat Protector LP 106-9025SP Valve, Drain Assy. FV 826-2569 Probe, RTD and Fitting Kit 807-0678 Temperature Probe 210-0681 Probe Guard 826-1177 Thermostat, High-Limit 425°F/218°C * Not illustrated.

  • Page 71: Gas Supply And Combustion System Components

    1-inch NPT black iron pipe nipples, elbows, tees, plugs, and unions, which acquired. (Typical) ® Series Fryer See page 2-19 and 20 for details of gas valves and related components. locally 2-17 See pages 2-14 through 2-15 for burners and burner insulation...
  • Page 72 Gas Supply and Combustion System Components cont. ITEM PART # Ignitor (includes gasket 816-0059, which may be ordered separately) 826-0981 Natural Gas (G20, G25) 826-0982 Propane (G30, G31) 826-1002 Manufactured Gas Blower Assembly, Combustion Air (includes harness and Items 4, and 5) 106-2996SP 100V 50/60 Hz (Left) 106-2999SP...

  • Page 73: Gas Valves And Associated Components

    Gas Valves and Associated Components 2-19...
  • Page 74 826-1121 Kit, Propane Gas w/ flexlines and hardware 810-1715 Valve, CE Gas (G20, G25, G30, G31) 810-1041 Accessory Kit (contains parts to adapt Item 2 to specific fryer configuration) 806-9678SP Plug Assembly, CE Gas Valve 810-0494 Ferrule (Nut), Orifice 810-1355 Gas Line, ⅜-inch OD X 15-inch SS Flexible...

  • Page 75: Filtration System Components

    2.10 Filtration System Components 2-21...
  • Page 76 Crumb Tray, Two-Vat Fryer, Half Size Filter Pan 810-2091 Hold-Down Ring 13.65 x 21.41, Standard Size Pan 3, 4, and 5 Vat 810-3289 Hold-Down Ring 11.20 x 19.10, Two-Vat Fryer, Half Size Filter Pan 812-2024 SanaGrid Filter Screen, Standard Size Filter Pan 812-2041...

  • Page 77: Return Valve Assembly And Associated Parts

    Rod, Handle Right RF 816-0643 Grip, Oil Return Valve Handle 809-0601 Clip, Clevis 810-1668 Adaptor, Male ⅝” OD x ½” 810-1067 Flexline, ⅝” OD x 8.50” Long Manifold, Rear Oil Return 810-3275 Two-Station Fryer 810-3245 Three-Station Fryer 810-3368 Four-Station Fryer COMPONENT 2-23...

  • Page 78: Ato (Auto Top-Off) Components

    2.12 ATO (Auto Top-Off) Components 2.12.1 JIB (Jug In Box) Low Indicator Light Assembly ITEM PART # 106-8105SP Light, Yellow 24VDC LED Flush 230-4142 Bracket, Protector Light 2.12.2 ATO (Automatic Top-Off) Board ITEM PART # 106-9258 Box, Assembly Auto Top Off 2 Board RTD 816-0771 Seal, Top Off Board 106-9611...

  • Page 79: Ato (Automatic Top-Off) Solenoid And Pump Assemblies

    2.12.3 ATO (Automatic Top-Off) Solenoid and Pump Assemblies ITEM PART # 106-9680SP Pump, ¼ FNPT 12VDC, 19PSI 15.1GPH 106-8477 Solenoid Manifold Assembly GL30-3 (includes three solenoid assemblies) 106-8014 Solenoid Manifold Assembly GL30-6 (includes six solenoid assemblies) 807-4590 Solenoid 813-0940 Elbow, ¼ NPT x ⅜ Flare 816-0708 Fitting, ¼...

  • Page 80: Wiring Connectors, Pin Terminals And Tools

    2.13 Wiring Connectors, Pin Terminals and Tools ITEM PART # 807-1068 2-Pin Female 807-0158 6-Pin Female 807-0156 9-Pin Female 807-0159 12-Pin Female 807-0875 15-Pin Female 807-1067 2-Pin Male 807-0157 6-Pin Male 807-0155 9-Pin Male 807-0160 12-Pin Male 807-0804 15-Pin Male 826-1341 Terminal, Female Split Pin (Pkg of 25) 826-1342...

  • Page 81: Fasteners

    2.14 Fasteners ITEM PART # 809-0429 Bolt, ¼-inch – 20 x 2.00-inch Hex Head ZP Tap 809-0131 Bolt, ¼-inch -20 x ¾-inch Hex 809-0953 Bolt, ¼-20 x ¾-inch Hex Head 807-1926 Bushing, .875-inch Split 809-0514 Capscrew, 5/16-inch-18 NC Hex 809-0448 Clip, Tinnerman 826-1351 Nut Retainer, ¼-20 (Pkg.
  • Page 82 2.14 Fasteners cont. ITEM PART # 809-0500 Screw, 10 x ½-inch Hex Washer Head 410 SS 809-0434 Screw, 10 x ⅜-inch Hex Washer Head NP 809-0123 Screw, 10 x ¾-inch Slot Head 826-1389 Screw, ¼-20 x ¾-inch Hex Head ZP (Pkg. of 10) (809-0131) 826-1346 Spacer, Ignition Module (Pkg.
  • Page 83 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 84 Frymaster, L.L.C., 8700 Line Avenue, Shreveport, Louisiana 71106 TEL 1-318-865-1711 FAX (Parts) 1-318-219-7140 FAX (Tech Support) 1-318-219-7135 SERVICE HOTLINE 819-6345 PRINTED IN THE UNITED STATES 1-800-551-8633 FEBRUARY 2009...
