Frymaster FMPH155 Specifications

Frymaster FMPH155 Specifications

Footprint pro filtration system for he gas fryers

Advertisement

Quick Links

Frymaster
FootPrint PRO® Filtration
System for HE Gas Fryers
Models
F M P H 1 5 5 *
F P P H 2 5 5
FPPH255

Specifications

Frymaster's renowned, patented built-in
FootPrint PRO Filtration System puts
filtration where it's most convenient to
use -- right within the fryer battery --
eliminating the need for additional floor
and storage space.
The filtering process is fast and easy,
encouraging frequent filtering -- a critical
part of maximizing oil life, especially with
trans-fat free oils. It is also sequential, so
one fryer may be filtered while the others
are still in use. It is engineered with
features that allow added convenience,
easier serviceability and allows for using
three different filter mediums with one
pan.
8700 Line Avenue 71106
P. O. Box 51000 71135-1000
Shreveport, LA
USA
®
F P P H 3 5 5
F P P H 4 5 5

Standard Features

Filter pan design easy-to-clean --
saves time
Large capacity filter pan is
lightweight for easy removal
Filter pan designed on rails to clear
floormats
Ample under-fryer cleaning space
when filter pan is removed
Sloped drain pan leaves minimal
shortening residue behind after
filtering
Increased diameter on oil pick-up
tube prevents clogging
Sleek, rounded styling enhances
aesthetics and allows easier
cleaning
Large 3-inch round drain line
creates 13% more capacity for oil
to drain freely
This system is enhanced with a gravity
draining system that allows residual oil to
drain into the filter pan so that drain lines
are always open. The filter, housed
beneath two FootPrint-ready gas fryers or
one fryer and a spreader, is capable of
filtering up to six fryers, individually,
without having to be moved from fryer to
fryer, saving valuable labor. One fifty-
pound fryer can be filtered in about four
minutes, while other fryers in the battery
keep on cooking.
FOOTPRINT PRO FILTRATION COMBINATIONS
FPPH255
FPPH555
Tel: 318-865-1711
Tel: 1-800-221-4583
Fax: 318-868-5987
E-mail: info@frymaster.com
F P P H 5 5 5
F P P H 6 5 5
Stainless steel alloy construction
extends long frypot life even
longer
1/3 H.P. motor
Stainless steel crumb catcher
1 box of 25 prepackaged
applications of Filter Magic®
powder
1 box of 25 sheets of Filter Magic
paper
Filtration Options &
Accessories
External oil discharge -- MUST be
ordered when equipment order
is placed. Specify rear or front
disposal
See individual fryer specification
sheets for fryer options
FPPH355
FPPH455
FPPH655
www.frymaster.com
Bulletin No. 818-0436 10/07
Project
Item
Quantity
CSI Section 11400
Approval
Date
* I n c l u d e s
s p r e a d e r c a b i n e t
H55 fryers are ENERGY
STAR® compliant.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FMPH155 and is the answer not in the manual?

Questions and answers

Summary of Contents for Frymaster FMPH155

  • Page 1: Standard Features

    F M P H 1 5 5 * F P P H 2 5 5 FPPH255 Specifications Frymaster’s renowned, patented built-in FootPrint PRO Filtration System puts filtration where it’s most convenient to use -- right within the fryer battery -- eliminating the need for additional floor and storage space.
  • Page 2 AMPERAGE FOR FILTER ONLY -- Filter Motor -- Domestic: 120V 60 Hz (7.5 AMP) Export: 220V-240V 50/60 Hz (4.5 AMP) -- Contact factory for other voltages FOR FRYER SPECIFICATIONS, FEATURES, AND OPTIONS, SEE INDIVIDUAL SPEC SHEETS. 8700 Line Avenue 71106 Tel: 318-865-1711 P.

This manual is also suitable for:

Fpph255Fpph355Fpph455Fpph555Fpph655
