- Page 1 Frontload Washers Metered Commercial FLW1526C Para bajar una copia de estas instrucciones en español, visite www.comlaundry.com. Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 802734R6 www.comlaundry.com September 2012...
- Page 3 These factors MUST BE supplied by the person(s) installing, maintaining, or operating the washer. Always contact the distributor, service agent, or the manufacturer about any problems or conditions you do not understand. 802734 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
-
Page 4: Table Of Contents
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... - Page 5 Vacations and Extended Non-Use ........... 30 Reinstallation of Shipping Materials ..........31 Cleaning Foreign Object Trap ............31 Troubleshooting .................. 32 Contact Information................34 Installer Checklist..............Back Cover © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734...
-
Page 6: Safety Information
6. To reduce the risk of an electric shock or fire, DO NOT use an extension cord or an adapter to connect the washer to the electrical power source. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... - Page 7 Always contact your dealer, distributor, service agent or the manufacturer about any problems or conditions you do not understand. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734...
-
Page 8: Installation
(10.41cm) (10.67cm) 1.5 in. 26.875 in. (68.3 cm) (3.8 cm) MODELS WITH GRAVITY DRAIN FLW2202N 1.5 in. (3.81 cm) Inside Diameter 1.86 in. (4.72 cm) Outside Diameter © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 9: Before You Start
NOTE: Some moisture in the wash drum is normal. Water is used during testing at the manufacturer. D074I Wrench Screwdriver Pliers Socket Wrench Level Figure 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 10: Installing The Washer
Tighten the locknuts securely against the washer base using the 7/8 in. wrench. If the locknuts are not H135I tight, washer will move out of position during Figure 2 operation. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 11: Step 3: Connect Fill Hoses
NOTE: When installing in newly constructed or flame during this time. renovated building, it is very important to flush the W029 lines since build-up may have occurred during construction. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 12: Connecting Hoses
All hoses should be checked on a monthly basis for any visible signs of deterioration. Any hose showing the signs of deterioration listed above should be replaced immediately. All hoses should be replaced every five years. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 13: Step 4: (Non-Gravity Drain Models Only) Connect Drain Hose To Drain Receptacle
1-3/8 inch (3.5 cm) outside diameter drain hose. W005I W005I Risers (Air Cushions) Water Supply Faucets Figure 6 FLW1978N Shipping Tape Figure 7 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 14: Step 5: (Gravity Drain Models Only) Connect Drain Outlet To Drain System
1.8 m (6 ft.) 23.9 (6.31) 2.1 m (7 ft.) 18.5 (4.89) FLW1980N 2.4 m (8 ft.) 10.6 (2.79) FLW1980N Drain Trough Drain Outlet Hose Figure 9 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 15: Step 6: Remove The Shock Sleeves And Shipping Brace
For leveling purposes, the washer may be tilted a maximum of 6 inches (152.4 mm) in any direction. FLW2271N FLW2271N Figure 12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 16: Step 7: Wipe Out Inside Of Wash Drum
• DO NOT use an extension cord. • DO NOT use an adapter. • DO NOT operate other appliances on the same circuit. Use separately fused 15 Amp circuits. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 17: Step 9: Check Installation
NOTE: Have a qualified electrician check the polarity of the wall receptacle. If a voltage reading is measured other than that in Figure 16, the qualified electrician should correct the problem. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 18: Vending
6. Install extension spring in bracket hole and hole in upper arm of lever. Refer to Figure 18. 7. Bend loops closed after installation. 8. Check to make sure the lever swings freely. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 19: Slide Extension Assembly - Models Starting Serial No. 1211
NOTE: If more switch down-force is required, install lever with arm that has two stars facing down to provide additional switch travel. TLW2090N TLW2090N Lever Off Switch Figure 20 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... - Page 20 "A" facing up and toward extension bracket and lever assembly. Refer to Figure 23. Extension Bracket and Coin Slide Bracket - Lever Assembly Letter "A" TLW2157N Figure 25 TLW2155N Figure 23 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734...
-
Page 21: Models Prepped For Card Reader
4. Check to make sure coin slide is operating properly by inserting coins and starting a cycle. The IN USE light will turn on, or flash if it is already on, to indicate proper operation. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 22: Operation
When washing bulky items such as blankets and comforters, use the DELICATE cycle. The cycle includes agitation and final spin speeds that maintain the load’s balance and minimize wear to the articles. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 23: Step 3: Add Laundry Supplies
IN USE light comes on (indicating start of cycle), FLW2129N press the PUSH-TO-START button. FLW2129N Detergent Bleach Fabric Softener Figure 29 W297I W297I Service Door Figure 32 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 24: Indicator Lights
W092 End of cycle (door will remain locked for about 1 minute) The washer will stop (pause) shortly before the first spin and final spin. Table 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 25: Operation Instructions For Mdc Washers
When washing bulky items such as blankets and comforters, use the DELICATES COLD cycle. The cycle includes agitation and final spin speeds that maintain the load’s balance and minimize wear to the articles. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 26: Step 3: Add Laundry Supplies
Figure 36 FLW2130N Detergent Bleach Fabric Softener Figure 35 CAUTION Dispenser drawer requires a special tool for removal. Contact a service person if removal is necessary. W236 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 27: Step 5: Insert Coin(S) Or Card
Insert coin(s) in coin slot. Check pricing as seen on WASHER. digital display. FLW1923N W387I FLW1923N Figure 37 Figure 39 To Insert Card Insert card into opening. DRY1927N Figure 38 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 28: Indicator Lights
START stopped. START flashes one second on and one second off when W092 the full vend price has been satisfied. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 29: Operation Instructions For Netmaster Washers
Contact a service person if removal is necessary. Step 2: Close Loading Door W236 Close loading door tightly. The washer will not operate with the loading door open. FLW2132N Figure 41 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 30: Step 4: Set Fabric Selector
Push touchpad for HOT, WARM or COLD. Light indicates selection. NOTE: Always follow manufacturer’s care labels. PERM NORMAL DELICATES PRESS START WARM COLD M343I Figure 46 H206I H206I Figure 44 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 31: Step 7: Start Washer
SPIN is lit for all spin cycles. DOOR LOCKED DOOR LOCKED is lit whenever the door is locked. The door cannot be opened when this light is on. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 32: Maintenance
Usually a mild soap solution will work. If there is an extreme build-up of minerals from a hard water supply, the surfaces may need to be cleaned with a lime removal chemical. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 33: Reinstallation Of Shipping Materials
Shock Sleeves Motor Mount Hooked End of Shipping Brace Bolts and Lockwashers Figure 48 Refer to Installation section, step 6 for proper procedures whenever the washer is moved. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 34: Troubleshooting
Laundry load may be oversudsing or overloaded. Make sure you are using low-sudsing, high efficiency (HE) detergent and proper load sizes. Make sure outside perimeter of the door glass where seal contacts glass is clean. • © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... - Page 35 “H” on the valve bracket) and cold faucet is connected to cold mixing valve (indicated with “C” on the valve bracket). • Make sure laundry room water heater is adjusted properly. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734...
-
Page 36: Contact Information
If replacement parts are required, contact the source from where you purchased your washer or call (920) 748-3950 for the name and address of the nearest authorized parts distributor. FLW2123N FLW2123N Nameplate Figure 49 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802734... -
Page 40: Installer Checklist
FLW2126N CHECK CHECK (Gravity Drain Models Only) • Connect Drain • Plug In the Outlet to Drain Washer System. D254IE0A D254IE0A FLW1980N CHECK CHECK FLW1980N CHECK D254IE0A © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
