Installation instructions for stacked washers and dryers

Advertisement

Quick Links

Installation Instructions

for Stacked Washers and Dryers
Inside.....................................
Dimensions........................................................................
Before You Start................................................................
Installation.........................................................................
Installer Checklist ...........................................................
Date Purchased ________________
Model Number ________________
Serial Number _________________
Para bajar una copia de estas instrucciones en español, visite www.comlaundry.com.
Keep these instructions for future reference.
(If this machine changes ownership, this manual must accompany machine.)
2
4
5
Back Cover
www.comlaundry.com
Part No. 802715
December 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 802715 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alliance Laundry Systems 802715

  • Page 1: Installation Instructions

    Model Number ________________ Serial Number _________________ Para bajar una copia de estas instrucciones en español, visite www.comlaundry.com. Keep these instructions for future reference. (If this machine changes ownership, this manual must accompany machine.) Back Cover www.comlaundry.com Part No. 802715 December 2006...
  • Page 2 All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT WARNING...
  • Page 3 *13.1 in. (33.3 cm) 28 in. (71.1 cm) *With leveling legs turned into base. 3/8 in. NPT Gas Connection © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802715 15.4 in. (39.1 cm) 26.9 in. (68.3 cm) 2.0 in.
  • Page 4: Before You Start

    5/16 Inch Socket Wrench Duct Tape Teflon Tape (Gas Models) Figure 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Any disassembly requiring the use of tools must be performed by a suitably qualified service person.
  • Page 5: Step 1: Position Unit Near Installation Area

    The gas is flammable. Do not smoke or use an open flame during this time. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802715 Water Supply Water supply faucets must fit standard 3/4 inch (19.1 mm) female garden hose couplings.
  • Page 6: Connecting Hoses

    Plain Rubber Washer Hose Coupling Filter Screens Figure 2 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT IMPORTANT: Hoses and other natural rubber parts deteriorate after extended use. Hoses may develop cracks, blisters or material wear from the temperature and constant high pressure they are subject to.
  • Page 7: Step 3: Connect Drain Hose To Drain Receptacle

    (refer to Figure 4). Water Supply Faucets Risers (Air Cushions) Figure 4 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802715 Step 3: Connect Drain Hose to Drain Receptacle Remove the drain hose from its shipping position on the rear of the washer by unhooking the hose from the retainer clamp and by removing the shipping tape.
  • Page 8: Wall Installation

    Beaded Strap (tape if necessary) Fill Hoses Figure 6 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Laundry Tub Installation: For this type of installation, the drain hose MUST be secured to the stationary tub to prevent hose from dislodging during use.
  • Page 9: Step 4: (Gas Dryer Only) Connect Gas Supply Pipe

    For proper operation at altitudes above 3000 feet (915 m) the natural gas valve spud orifice size must be reduced to ensure complete combustion. Refer to Table 1. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802715 Natural Gas Altitude Adjustments Altitude...
  • Page 10: Step 5: (Electric Dryer Only) Connect Electrical Plug

    © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Grounding Information • This dryer must be connected to a grounded metal, permanent wiring system;...
  • Page 11: Connecting Power Cord With Three-Wire Plug

    30 Ampere Fuses or Circuit Breaker Neutral Wire 1. Disconnect power to dryer. 2. Remove access cover from rear of dryer. Figure 10 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802715 POWER SUPPLY INTERMEDIATE FUSE BOX (may...
  • Page 12: Connecting Power Cord With Four-Wire Plug

    8. Reinstall access cover and screw. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Connecting Power Cord with Four-Wire Plug NOTE: Four-wire cord is required for mobile homes or where codes do not permit grounding through neutral.
  • Page 13 4. Use a strain relief and insert end of power cord through power supply hole. Figure 16 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802715 5. Attach power cord ground (green) wire to rear bulkhead using ground screw removed in Step 3.
  • Page 14: Step 6: Connect Dryer Exhaust System

    • DO NOT use plastic or thin foil ducting. Rigid metal duct is recommended. Refer to Figure 18. Figure 18 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT • Locate dryer so exhaust duct is as short as possible.
  • Page 15: Exhaust Direction

    Maximum length of 4 in. (10.2 cm) diameter rigid metal duct. Maximum length of 4 in. (10.2 cm) diameter flexible metal duct. NOTE: Deduct 6 feet (1.8 m) for each additional elbow. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802715 Exhaust System For best drying results, recommended maximum length of exhaust system is shown in Table 3.
  • Page 16: Step 7: Position And Level The Unit

    Installing the unit on any type of carpeting, soft tile, a platform or other weakly supported structures is not recommended. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Dryer and Exhaust Duct Clearances Description Figure 19...
  • Page 17 Refer to Figure 21. Loosen the locknuts and adjust legs by screwing into or out of unit base. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802715 Wood Block SWD833N Make sure that the unit does not rock.
  • Page 18: Step 8: (Washer Only) Remove The Shock Sleeves And Shipping Brace

    Bolts and Lockwashers Figure 22 Reinstall front access panel. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT IMPORTANT: DO NOT tip washer more than 6 inches (152.4 mm) in any direction after shipping brace has removed. Shock absorbers may separate and damage to unit may result.
  • Page 19: Electric Dryer

    • Do not operate both a washer and gas dryer on the same circuit. Use separetely fused 15 amp circuits. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802715 The dryer is designed to be operated on a separate...
  • Page 20 Neutral Neutral Side Round Grounding Prong Figure 26 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Washer Washer requires 120 Volt, 60 Hertz electrical supply and comes equipped with a 3-prong grounding plug. Refer to serial plate for specific electrical requirements.
  • Page 21: Step 12: Check Heat Source

    Do not modify the plug provided with the washer – if it will not fit the outlet, have a proper outlet installed by a qualified electrician. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 802715 NOTE: Have a qualified electrician check the polarity of the wall receptacle.
  • Page 22 4. Reinstall the lower front panel. Air Shutter Lockscrew Appliance Main Gas Valve © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT WARNING For personal safety, lower front panel must be in place during normal operation.
  • Page 24: Installer Checklist

    (Refer to the manual for more detailed information) • Position Unit Near Installation Area. CHECK • Connect Fill Hoses. Filter Screen CHECK • Connect Drain Hose to Drain Receptacle. CHECK Gas Only • Connect Gas Supply Pipe. • Check for Gas Leaks. CHECK Electric Only •...
