- Page 1 Frontload Washers Para bajar una copia de estas instrucciones FLW1522C en español, visite www.comlaundry.com. FLW1522C Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 801455R2 www.comlaundry.com April 2012...
-
Page 3: Table Of Contents
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 4: Replacement Parts
Shepard Street P.O. Box 990 Ripon, WI 54971-0990 U.S.A. Phone: (920) 748-3950 for the name and address of the nearest authorized parts distributor. 801455 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 5: Installation
18.7 in. (47.5 cm) 14.3 in. (36.3 cm) 28 in. 26.9 in. (71.1 cm) (68.3 cm) 2 in. (5.1 cm) FLW2044N MODELS WITH NEW STYLE DOOR FLW2044N © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 6: Before You Start
• Bag for storing shipping materials. Figure 1 Electrical Refer to serial plate for specific electrical requirements. For more detailed information refer to section on Electrical Requirements. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 7: Installing The Washer
Continue tightening and rechecking until no leaks are found. W520I W520I Filter Screen (Screen must be facing outward) FLW702N Fill Hose FLW702N Rubber Washer (Plain) Figure 2 Figure 3 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 8: Step 3: Connect Drain Hose To Drain Receptacle
This will prevent the drain hose from dislodging from drain receptacle during use. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 9: Sink Installation
Figure 7). This will prevent the drain hose from dislodging during use. Figure 8 FLW1960N FLW1960N Drain Hose Tie-Down Strap (Wire tie or tape if necessary) Figure 7 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 10: Step 4: Position And Level The Washer
NOTE: Use of the dispenser drawer or washer door as a handle in the transportation of the washer may cause damage to the dispenser or door. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 11: Step 5: Remove The Shock Sleeves And Shipping Brace
6 inches (152.4 mm) in any direction. H336I H336I Shock Sleeves Motor Mount Bolts and Lockwashers Hooked End of Shipping Brace Figure 11 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 12: Step 6: Wipe Out Inside Of Washer Drum
Supply Dispenser Pump Outlet provided specifically for that purpose by the factory. Figure 13 5. Refer to supply injection system instructions for details on operation. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 13: Control Function Test
2. Open manual shut-off valves to the washer. 3. Apply power to the washer. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 14: Electrical Requirements
110/120 Volts AC (alternating current) 15 Amps. Refer to Figure 18 to determine correct polarity of the wall receptacle. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 15: Grounding Instructions
W031 plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug. W213 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 16: Water Supply Requirements
Order hoses as follows: W005I W005I No. 20617 Fill Hose (8 ft.) (2.44 m) Water Supply Faucets No. 20618 Fill Hose (10 ft.) (3.05 m) Risers (Air Cushions) Figure 20 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 17: Information For Handy Reference
Phone Number Service Agency Service Agency Address Phone Number NOTE: Record the above information and keep your sales slip. Model and serial numbers are located on the nameplate. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 801455... -
Page 20: Installer Checklist
Supplies to to Drain Receptacle. Washer. FLW1959N FLW1959N CHECK CHECK FLW2027N FLW2027N • Position and • Plug In the Washer. Level the Washer. FLW2047N FLW2047N CHECK CHECK D254I D254I © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT...
