NEC Storage Manager User Manual page 125

5. The dialog for renaming a logical disk appears.
(1) The logical disk name must be unique in the system. (Do not assign the same name twice or more.)
(2) The initial value of the logical disk name field consists of 20 characters; 16 characters specific to the disk array
and 4 characters of the logical disk number.
(3) Any logical disk name that does not conform to the following rules is invalid:
Number of available characters:
Available characters:
* All the characters must be 1-byte characters.
6. When the logical disk is successfully renamed, the following message is displayed.
Figure 7-53 Message for Successful Completion of Renaming the Logical Disk
Figure 7-52 Dialog for Renaming a Logical Disk
1 to 24 characters
Alphabet:
Numerals:
Underbar:
Slash:
IV-59
Chapter 7 Disk Array Configuration Setting
A to Z (a to z)
* Upper- and lower-case characters are distinguished.
0 to 9
_
/
