The log is a detailed record of what websites you have accessed or attempted to access. Up to 128
entries are stored in the log. Log entries will only appear when keyword blocking is enabled, and
no log entries will be made for the Trusted User.
Log entries are described in
No.
The index number of the content filter log entries. 128 entries
are available numbered from 0 to 127. The log will keep the
record of the latest 128 entries.
Time and Entry
The time the log entry was recorded. Below the time is the name
or IP address of the website visited or attempted to access.
Source IP
The IP address of the initiating device for this log entry.
Action
This field displays whether the packet was blocked, forwarded,
or neither (BLOCK, FORWARD, or NONE). "NONE" means
that no action is dictated by this rule.
Table 4-1
