Unless these items are dynamically assigned by the ISP, your ISP should give you the following
basic information for your account:
•
An IP address and subnet mask
•
A gateway IP address, which is the address of the ISP's router
•
One or more domain name server (DNS) IP addresses
•
Host name and domain suffix
For example, your account's full server names may look like this:
In this example, the domain suffix is
If any of these items are dynamically supplied by the ISP, your router automatically acquires them.
If an ISP technician configured your PC during the installation of the broadband modem, or if you
configured it using instructions provided by your ISP, you need to copy configuration information
from your PC's Network TCP/IP Properties window (or Macintosh TCP/IP Control Panel) before
reconfiguring your PC for use with the router. These procedures are described next.
As mentioned above, you may need to collect configuration information from your PC so that you
can use this information when you configure the Model RP114 router. Following this procedure is
only necessary when your ISP does not dynamically supply the account information.
To get the information you need to configure the router for Internet access:
On the Windows taskbar, click the Start button, point to Settings, and then click Control Panel.
1.
Double-click the Network icon.
2.
The Network window opens, which displays a list of installed components.
Select TCP/IP, and then click Properties.
3.
The TCP/IP Properties dialog box opens.
Select the IP Address tab.
4.
If an IP address and subnet mask are shown, write down the information. If an address is
present, your account uses a fixed (static) IP address. If no address is present, your account
uses a dynamically-assigned IP address. Click "Obtain an IP address automatically".
.
