Packard Bell oneTwo M3600
All-In-One Computer Service Guide
Service guide files and updates are available
on the Acer/CSD web site; for more
information, go to
http://csd.acer.com.tw
PRINTED IN TAIWAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the oneTwo M3600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Packard Bell oneTwo M3600

  • Page 1 Packard Bell oneTwo M3600 All-In-One Computer Service Guide Service guide files and updates are available on the Acer/CSD web site; for more information, go to http://csd.acer.com.tw PRINTED IN TAIWAN...
  • Page 2: Revision History

    Revision History Refer to the table below for changes made on this version of the Packard Bell oneTwo M3600 All-In-One Computer Service Guide. Date Chapter Updates Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 3 Acer is a registered trademark of Acer Incorporated. Other brand and product names are trademarks and/or registered trademarks of their respective holders. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 4 Alerts you to any physical risk or system damage that might result from doing or not doing specific actions. CAUTION Gives precautionary measures to avoid possible hardware or software problems. IMPORTANT Reminds you to do specific actions relevant to the accomplishment of procedures. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 5: Fru Information

    FRU list of this printed service guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and service of customer machines. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 6 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 7: Table Of Contents

    Removing the Mainboard ......... . .42 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 8 ..........81 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 9: Chapter 1 - Features And Specifications

    Chapter 1 Features and Specifications This chapter lists the features and specifications of the Packard Bell oneTwo M3600 AIO computer. NOTE The items listed in this section are for reference only. The exact configuration of your PC depends on the model purchased.
  • Page 10: Physical Specifications

    Standard DTX Mainboard dimensions (W × H) 190 × 175 mm Environmental Requirements Aspect Description Operating temperature 5 to 35 °C (41 to 95 °F) Operating humidity 15% to 80% RH non-condensing Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 11: System Tour

    The pictures and tables in this section illustrate the physical outlook of the computer. Front View Item Component Integrated webcam Integrated microphone Display screen Speakers Power button/indicator • Green – System is in power-on mode • Amber – System is in standby mode Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 12: Right Views

    Right Views Item Component Increase brightness key Decrease brightness key USB ports 4-in-1 card reader Microphone jack Headphone jack Reset button Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 13: Left And Rear Views

    Ventilation slots Mounting holes for wall mount option Optical disc drive (ODD) Kensington lock slot Computer stand Power jack Ethernet port (RJ-45) USB ports PS/2 mouse port PS/2 keyboard port Line-out jack Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 14: Hardware Specifications

    1 or 2 GB DIMM type 240-pin DDR3 SO-DIMM Supported brands ADATA, Hynix, Kingston, Micron, Unifosa, Samsung Population rule You can install memory modules in any combination as long as they match the above specifications. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 15: Hard Disk Drive

    • Memory Stick PRO (MS PRO) cards Ethernet Item Specification Controller Realtek RTL8111DL Gigabit Ethernet controller LAN protocol 10/100/1000 Mbps LAN connector type RJ-45 Wireless LAN Item Specification Model Lite-On WN6602RH (802.11 b/g/n) Form factor PCIe Mini Card Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 16: Audio

    65 W (Delta ADP-65JH DB A / Hipro HP-A0652R3B 1LF) Specifications • 90V to 240V and 50Hz to 60Hz AC • 19V DC Output • 3 prong ICE-320-C13 or IEC-320-C5 AC connector Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 17: Chapter 2 - System Utilities

    (BT1) may be defective. In this case, the system cannot retain configuration values in CMOS. Replace the RTC battery with a new one. NOTE For ease of reading, CMOS Setup Utility will be simply referred to as “Setup” or “Setup Utility” in this Service Guide. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 18: Accessing The Setup Utility

    Some options (marked with a ) lead to submenus that enable you to change the values for the option. Use the Up/Down/Left/Right arrow keys to scroll through the items in the submenu Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 19: Navigating Through The Setup Utility

    • The screenshots used in this section are for illustration only. The values displayed may not be the same as those in your computer. • In the descriptive tables following each of the menu screen illustrations, settings in boldface are the default and suggested settings. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 20: Product Information

    Official model name of the computer. System Serial Number System serial number. System BIOS Version Current system BIOS version BIOS Release Date Date when the CMOS setup utility was released. Asset Tag Number System asset tag number Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 21: Standard Cmos Features

    • All Errors - Any error detected will pause the system. • No Errors - BIOS will ignore any errors detected during POST • All, but Keyboard - If a keyboard error is detected, BIOS will pause the system. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 22: Advanced Bios Features

    Press Enter to specify the boot device priority sequence foe available network drives. Priority Bootup Num-Lock If you set this item to On, the keyboard Num Lock key will be active when the computer boots up. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 23: Advanced Chipset Features

    Select the Intel Dynamic Video Memory Technology mode. Fixed DVMT DVMT/Fixed Select to specify the maximum memory size that can be allocated 128 MB Memory Size as graphics memory using the Intel Dynamic Video Memory 256 MB Technology. Maximum Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 24: Integrated Peripherals

    Enables or disables the onboard audio controller. Enabled Controller Disabled Onboard LAN Enables or disables the onboard LAN controller. Enabled Controller Disabled Onboard LAN Enables or disables the onboard LAN option ROM function. Enabled Option ROM Disabled Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 25: Power Management Setup

    Last State • Last State - The computer reverts to the last power state before the power loss occurred. • On - The computer switches back on after the AC power loss. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 26: Pc Health Status

    CPU Fan Speed System Fan Speed CPU Core +3.30V +5.00V 5VSB VBAT Smart Fan When enabled, fan speed will speed up or slow down depending on Enabled the system temperature. Disabled Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 27 A slight jitter can introduce a temporary boost in clock speed causing the overclocked processor to lock up. Processor Multiplier This field is only visible if an engineering processor installed. It is only accessible when the EIST function is disabled. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 28: Bios Security Features

    When you are prompted to enter a password, you have three tries before the system halts. Do not forget your password. If you forget your password, you may have to return your computer to your dealer to reset Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 29 Press Enter twice without entering anything in the new and confirm password fields. You will be prompted to confirm the password removal. Press Enter. Press F10 to save the changes you made and close the Setup Utility. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 30: Load Default Settings

    Select Load Default Settings, then press Enter. You will be prompted to load the system defaults. Select OK, then press Enter. Press F10 to save the changes you made and close the Setup Utility. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 31: Exit Without Saving

    Save & Exit Setup Execute this menu to save the changes made and closes the Setup Utility. Keyboard shortcut: F10 Exit Without Saving Execute this menu to closes the Setup Utility without making any changes. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 32 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 33: Chapter 3 - System Disassembly

    Unplug the power cord from the computer. Unplug the network cable and all connected peripheral devices from the computer. Place the computer on a flat, steady surface with the rear cover facing upward. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 34: Disassembly Procedures

    Perform the “Pre-disassembly Procedure” on page 25. Remove the plastic shell covering the computer stand screws. Remove the screws securing the computer stand. Quantity Color Torque Part Number Chrome 4.0 +/- 0.3 kgf-cm 86.00J97.668 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 35: Removing The Side Bars

    Remove the computer stand. Removing the Side Bars Perform the “Pre-disassembly Procedure” on page 25. Remove the screws securing the side bars. Quantity Color Torque Part Number Black 4.0 +/- 0.3 kgf-cm 86.ZA324.8R0 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 36: Removing The Front Bezel

    Remove the side bars by following the procedure described on the previous section. Use a flat screwdriver to pry off the front bezel from the rear cover. Detach the front bezel from the rear cover and turn it over to access the webcam cable. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 37: Removing The Webcam Module

    Remove the front bezel by following the procedure described on the previous section. Disconnect the webcam cable from the webcam module. Push the tabs securing the webcam module. Remove the webcam module from the front bezel. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 38: Removing The Lcd Assembly

    4.0 +/- 0.3 kgf.cm 86.ZA324.8R0 Detach the LCD assembly from the rear cover and turn it over to access the LCD panel cables. Disconnect the LCD and inverter cables from the mainboard. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 39: Removing The Lcd Lvds Cable

    Color Torque Part Number Chrome 4.0 +/- 0.3 kgf.cm 86.00K96.644 Detach the LCD panel bracket from the LCD panel, then turn over the inverter board bracket to access the inverter board cables. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 40 Disconnect the inverter board cables from the inverter board. Remove the screws securing the inverter board. Quantity Color Torque Part Number Chrome 4.5 +/- 0.3 kgf.cm 86.7A554.6R0 Remove the inverter board cage from its bracket. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 41: Removing The Optical Disc Drive

    Disconnect the ODD power and data cables from the mainboard, then the ODD SATA cable from the ODD. Remove the screw securing the ODD bracket to the chassis. Quantity Color Torque Part Number Chrome 4.0 +/- 0.3 kgf.cm 86.00K96.644 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 42 Slide the ODD out of the rear cover. Remove the screw securing the ODD bracket. Quantity Color Torque Part Number Chrome 2.0 +/- 0.2 kgf.cm 86.00K77.223 Detach the ODD bezel from the module. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 43: Removing The Hard Disk Drive

    Quantity Color Torque Part Number Chrome 4.5 +/- 0.3 kgf.cm 86.00K96.644 Slide the HDD assembly towards the ODD area to disengage the cage’s tabs from the chassis, then remove the HDD assembly. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 44: Removing The System Fan

    Slide the hard drive out of its cage. Removing the System Fan Remove the LCD assembly by following the procedure described on the page 30. Disconnect the system fan cable from the mainboard. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 45 Remove the screw securing the system fan. Quantity Color Torque Part Number Chrome 2.0 +/- 0.2 kgf.cm 86.7A122.4R0 Remove the system fan from the chassis. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 46: Removing The Heat Sink

    Remove the system fan by following the procedure described on the previous section. Loosen the screws securing the heat sink. Quantity Color Torque Chrome 4.5 +/- 0.3 kgf.cm Remove the heat sink. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 47: Removing The Memory Modules

    Open the holding clips securing the memory modules (a), then remove the memory modules from the DIMM slots (b). Removing the Webcam Cable Remove the LCD assembly by following the procedure described on the page 30. Disconnect the webcam cable from the mainboard. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 48: Removing The Power Button/Led Assembly

    Removing the Power Button/LED Assembly Remove the LCD assembly by following the procedure described on the page 30. Disconnect the power button/LED cable from the mainboard. Remove the power button/LED assembly from the front bezel. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 49: Removing The Speakers

    Removing the Speakers Remove the LCD assembly by following the procedure described on the page 30. Disconnect the speaker cable from the mainboard. Remove the speakers from the rear cover. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 50: Removing The Mainboard

    Follow local regulations for disposing this type of circuit board. • The RTC battery has been highlighted with a yellow circle in the above image. Detach the RTC battery and follow local regulations for disposing it. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 51: Chapter 4 - Troubleshooting

    Make sure that there is no point of contact in the system that can cause a power short. If the cause of the failure is still can not be determined, perform the “System Internal Inspection” procedure described on the next page. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 52: Checkpoints

    If memory sizing module not executed, start memory refresh and do memory sizing in bootblock code. Do additional chipset initialization. Re-enable CACHE. Verify that flat mode is enabled. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 53: Boot Block Recovery Code Checkpoints

    Erase the flash part. Program the flash part. The flash has been updated successfully. Make flash write disabled. Disable ATAPI hardware. Restore CPUID value back into register. Give control to F000 ROM at F000:FFF0h. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 54: Post Code Checkpoints

    Initializes DMAC-1 & DMAC-2. Initialize RTC date/time. Test for total memory installed in the system. Also, Check for DEL or ESC keys to limit memory test. Display total memory in the system. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 55 Uninstall POST INT1Ch vector and INT09h vector. Deinitializes the ADM module. Prepare BBS for Int 19 boot. End of POST initialization of chipset registers. Save system context for ACPI. Passes control to OS Loader (typically INT19h). Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 56: Post Error Indicators

    The base memory (memory below 1MB) size that is reported in the CMOS (offset Wrong 15h) mismatches with the actual size detected. This condition may occur when the hole is set at 512K base memory or when CMOS is corrupted. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 57: Storage Device

    The IDE/ATAPI device configured as Slave in the 4th IDE controller could not be Error properly initialized by the BIOS. This message is typically displayed when the BIOS is trying to detect and configure IDE/ATAPI devices in POST. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 58 Command Failed transaction failed. This message can be reported by an ATAPI device using the S.M.A.R.T. error reporting standard. S.M.A.R.T. failure messages may indicate the need to replace the hard disk. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 59: System Configuration

    Two or more Static Devices are trying to use the same resource space (usually Conflict Memory or I/O). PCI I/O conflict A PCI adapter generated an I/O resource conflict when configured by BIOS POST. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 60 Indicates that <INS> key is pressed during the BIOS POST. The POST will load and use default CMOS settings. Password check The password entered does not match the password set in the setup. This condition failed may occur for both Supervisor and User password verification. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 61 Mode is set to Enabled. the Control Panel. • Reload software from Recovery CD. Blinking cursor only; system does not work. • IDE drive connection/cables • IDE disk drives • See “Undetermined Problems”. • Mainboard Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 62 • CD/DVD-ROM drive. NOTE Make sure the optical disc drive is configured correctly in CMOS Setup, the cable/jumper are set correctly and the drive’s optical lens is clean before diagnosing any optical drive problems. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 63 • Missing, broken, or incorrect characters • Mainboard • Blank monitor (dark) • Blank monitor (bright) • Distorted image • Unreadable monitor Display changing colors. • Monitor signal connection/cable • Video adapter card • Mainboard Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 64 • Enter CMOS Setup and load the default settings. Windows98 Start menu does not turn off the • Reload software from Recovery CD. system. (Only pressing power button can turn off the system). No system power Mainboard Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 65: Bios Recovery

    Press Delete to run the CMOS Setup Utility. Press F9 to load the system default settings. Select Ok, then press Enter. Press F9 to save the default settings and close the Setup utility. Select Ok, then press Enter. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 66: Clearing Cmos

    13. During POST, press Delete to access the Setup Utility. 14. Press F9 to load the system default values. 15. Press F10 to save the changes you made and close the Setup Utility. Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 67: Chapter 5 - System Architecture

    Chapter 5 System Architecture This chapter shows the block diagram and board layout of the Packard Bell oneTwo M3600 AIO computer. Block Diagram The core subsystems of the Packard Bell oneTwo M3600 computer are depicted in the following block diagram.
  • Page 68: Mainboard Layout

    LVDS1 LCD cable connector CPU_FAN1 Processor fan cable connector SATA0 HDD SATA cable connector INV_CN1 Inverter cable connector TOU_CN1 Touchscreen panel connector ODD_PWR1 ODD power cable connector SATA1 ODD SATA cable connector Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 69 Clear CMOS jumper INT_SPK1 Speaker cable connector SWLED2 Power button/LED cable connector HP_JK1 Headphone jack MIC_JK1 Microphone jack MEM_CARD1 Card reader USB2 and USB3 Side USB ports BTN1 and BTN2 Brightness control keys Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 70 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 71: Chapter 6 - Field Replaceable Unit (Fru) List

    Chapter 6 Field Replaceable Unit (FRU) List This chapter gives you the FRU (Field Replaceable Unit) listing of the Packard Bell oneTwo M3600 computer global configurations. Refer to this list when ordering for repair parts or for RMA (Return Merchandise Authorization).
  • Page 72: Exploded Diagram

    Exploded Diagram Component Side bars LCD panel bracket HDD cage Rear cover assembly ODD bezel Inverter board bracket ODD bracket Power button/LED assembly LCD panel Front bezel Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 73: Fru List

    MEMORY A-DATA SO-DIMM DDRIII 1333 1GB KN.1GB0B.035 AD73I1A0873EU LF 128*8 0.065UM SODIMM 1GB DDRIII 1333MHZ UNIFOSA GU672203EP0200 KN.1GB0C.009 LF 128*8 0.065UM SODIMM 1GB DDRIII 1333MHZ SAMSUNG M471B2873FHS- KN.1GB07.004 CH9 LF 128*8 46NM Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 74 CCFL LCD LPL 18.5"W WXGA NONE GLARE LM185WH1 LK.18008.010 TLF1 LF 250NIT 5MS 1000:1 HF Speakers SPEAKER 23.VBK01.004 SPEAKER 23.VBK01.003 Modem module MODEM CARD 56K PRO-NETS PRONETS VD56UL FX.10100.023 EXTERNAL USB REV 1.0 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 75 HDD bracket HDD BRACKET 33.VBK01.002 ODD bracket ODD BRACKET 33.VBK01.001 ODD bezel DVD-RW ODD BEZEL 42.NC301.001 LCD panel bracket TOUCH PANEL BRACKET LEFT 33.NC301.002 Inverter board cover TOUCH PANEL BRACKET RIGHT 33.NC301.001 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 76 KEYBOARD CHICONY KU-0906 USB 85KEY BLACK KB.USB03.319 KOREAN KEYBOARD CHICONY KU-0906 USB 85KEY BLACK KB.USB03.293 RUSSIAN KEYBOARD CHICONY KU-0906 USB 85KEY BLACK KB.USB03.304 SIMPLIFIED CHINESE KEYBOARD CHICONY KU-0906 USB 85KEY BLACK KB.USB03.245 TRADITIONAL CHINESE Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 77 KEYBOARD CHICONY KU-0906 USB 86KEY BLACK KB.USB03.278 SPANISH KEYBOARD CHICONY KU-0906 USB 86KEY BLACK KB.USB03.283 SWEDISH KEYBOARD CHICONY KU-0906 USB 86KEY BLACK SWISS/ KB.USB03.285 KEYBOARD CHICONY KU-0906 USB 86KS BLACK TURKISH KB.USB03.298 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 78 SCREW M4*8-B FAH MSN+N 86.VBK01.001 SCREW MACH CAP M3*L6 NI NYLOK 86.VBK01.004 SCREW MACH PAN M3*L4 NI NYLOK 86.VBK01.003 SCREW M2 CAP L4 NI 86.NBY01.003 SCRW MS/P2*3NBX 86.VBK01.002 SCRW TAP PAN M3L8 ZN 86.VBK01.005 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 79: Appendix A - Model Definitions And Configurations

    Appendix A Model Definitions and Configurations This appendix provides features summary for each of the Packard Bell oneTwo M3600 computer model configurations. Item Specification Specification Project name pMarr Model name oTM3600 Acer part number PW.U6EE8.001 PW.U6E08.001 Description oTM3600 CH EMEA001...
  • Page 80 Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 81: Appendix B - Test Compatible Components

    Refer to the following lists for components, adapter cards, and peripherals which have passed these tests. Regarding configuration, combination and test procedures, please refer to the Packard Bell oneTwo M3600 Vista Compatibility Test Report released by the Acer Mobile System Testing Department.
  • Page 82 SanDisk MicroSDHC 4 GB Card with Adapter SanDisk Kingston SDHC SD4 32 GB Card Kingston xD Card Olympus xD-Picture Card M+ 2GB Speed Card Olympus Fujifilm xD-Picture Card Type M 2 GB Fujifilm Packard Bell oneTwo M3600 AIO Computer Service Guide...
  • Page 83: Approved Vendor List (Avl)

    Approved Vendor List (AVL) Component Vendor Type Description Part Number Mainboard kit Wistron pMarr Mainboard oTM3600 Intel NM10 RTL8111DL AIO 18.5 W/O 1394 LF MB.U6E01.001 WINM10_1394(N)_Logo(N)_ Eup(Y) Front bezel Wistron PAIO1018 Wistron PB Bezel PAIO1018 for 18.5" w/i HX101D chassis PZ.11900.229 Chassis Wistron...
  • Page 84 Component Vendor Type Description Part Number Card reader Wireless LAN kit Lite-On 802.11 b/g/n (mini-card)(half Lite-On WN6602RH, Ralink RT3090 WLAN Lite-On WN6602RH, Ralink RT3090, NI.10200.034 size) 802.11b/g/n 1x1 WLAN (mini-card) Half Size 802.11 b/g/n (mini-card)(half Lite-On WN6602RH Kit WLAN ANTENNA MAIN WLAN 680mm+ANTENNA AUX NI.10200.043 size) Kit WLAN 600mm...
