4 HMX Manager Installer/User Guide
NOTE: Menus are static and cannot be expanded or collapsed
The arrows displayed in the side navigation bar indicate that a number of sub-options are available.
You can display these items by clicking the main link. Where no arrow is displayed, clicking the
link brings you directly to the option you have selected.

Displaying pages

Multiple page windows contain menu options that may be used to navigate from one display to
another.You can click to enable the Select All checkbox to select all items on a page. Enabling this
checkbox selects all the items listed on a page regardless of whether the entire page is visible.
However, for multi-page displays, items listed on other pages will not be included in the selection.

Refreshing a window

The Units - All screen automatically refreshes every 10 seconds.

Using keyboard commands

In addition to using a mouse, you can use certain keyboard commands to select and change items
in windows.
Table 1.2: General Keyboard Commands
Key
Tab
Shift-Tab

Internet Explorer Considerations

The HMX Manager operates using the default Internet Explorer settings. In the event that the
default Internet Explorer settings have been altered, SSL and Javascript must be enabled to
successfully access the HMX Manager.

Firewalls

To access the HMX Manager through a firewall, you must ensure that the firewall uses the default
HTTPS port 443.
Description
Transfers focus to the next control in the window, including the calendar
Transfers focus to the previous HTML control
